EVAL-AD7766/AD7767
Reference Designator Part Type
R3 RES
R4 RES
R5 RES
R6 RES
R7 RES
R8 RES
R9 RES
R10 RES
R11 RES
R12 RES
R13 RES
R14 RES
R15 RES
R16 RES
R17 RES
R18 RES
R19 RES
R20 RES
R22 RES
R23 RES
R24 RES
R25 RES
R28 RES
R30 RES
R31 RES
R32 RES
R33 RES
R34 RES
R35 RES
R36 RES
R37 RES
R38 RES
R39 RES
R40 RES
R41 RES
R42 RES
R43 RES
R44 RES
S2 SW-PUSH-SMD
SL1 JP2\SOLDER-Link
SL2 JP2\SOLDER-Link
SL3 JP2\SOLDER-Link
SL4 JP2\SOLDER-Link
SL5 JP3\SOLDER-BRIDGE
SL6 JP2\SOLDER-Link
SL7 JP2\SOLDER-Link
SL8 JP4\SOLDER-Link
SL9 JP2\SOLDER-Link
SL11 JP4\SOLDER-Link
U1 AD7766_67
U2 ADA4841-1YRZ
Value Footprint
1K (0.001) 603
1K (0.001) 603
3R3 (1%) 603
3R3 (1%) 603
0r 603
0r R0402
1K (0.001) 603
1K (0.001) 603
1K (0.001) 603
1K (0.001) 603
100r (0.01) 603
0r 603
51r (1%) 805
0R 603
0r 603
51r (1%) 805
51r (1%) 805
51r (1%) 805
0R 603
1K (0.001) 603
0r R0402
0r 603
0r 603
0r 603
51r (1%) 603
51r (1%) 603
10k R0603
0r 603
10k (0.01) R0603
0r 603
0r 603
0r 603
0r R0402
10k (0.01) R0603
0r 603
10k (0.01) R0603
1K (0.001) 603
0r 603
TSSOP-16
SO8NB
Rev. PrA | Page 18 of 20
Preliminary Technical Data
Supplier No.
FEC 4628846
FEC 4628846
FEC 3571130
FEC 3571130
FEC 9331662
Do not insert
FEC 4628846
FEC 4628846
FEC 4628846
FEC 4628846
FEC 9239111
FEC 9331662
FEC 9333355
Do Not Insert
FEC 9331662
FEC 9333355
FEC 9333355
FEC 9333355
FEC 9331662
FEC 4628846
Do not insert
Do not insert
Do Not insert
FEC 9331662
FEC 4627623
FEC 4627623
FEC 9330399
Do not insert
FEC 9330399
Do Not Insert
FEC 9331662
FEC 9331662
Do not insert
FEC 9330399
FEC 9331662
FEC 9330399
FEC 4628846
FEC 9331662
B3S-1000
Solder to Link A
Solder to Link A
Solder to Link B
Solder to Link A
Solder to Link C
Solder to Link B
Do Not Insert
Solder to link C
Solder to Link B
Solder to Link B
ADA4841-1YRZ
