UG-1757
AD5413 BLOCK DIAGRAM AND FUNCTIONS
The EVAL-AD5413SDZ plugin is organized to appear similar to
the block diagram shown in the
user interface (GUI) correlates the functions of the EVAL-
AD5413SDZ with the descriptions in the
A B C D E
F
G
H
I
V
Table 3. AD5413 Block Diagram Label Functions (See Figure 8)
Figure Label Function
A To apply any changes made to the block diagram or to register values in the memory map to the device, click Apply Changes.
B To read back all of the registers of the device, click Read All.
C Click Reset Chip to reset the AD5413. The Reset Chip button has the same functionality as the software reset of the AD5413.
D
Click Diff to show the registers that are different from the data stored on the device. This function shows what has changed
since the last register read.
E
Click Software Defaults to load the software defaults of the device. These values are not written to the hardware. Click
Apply Changes (Label A) to write the software default values to the hardware.
F The AD0 and AD1 check boxes set the
the hardware. If either check box is selected, this represents a high state. If either box is not selected, this represents a low
state.
G If the /RESET check box is selected, the
H If the /LDAC check box is selected, the
I The EVAL-AD5413SDZ plugin monitors the FAULT pin. If the FAULT pin is low, the /FAULT indicator LED lights up red.
J VI_OUT displays the calculated output at VI
Kx GUI access on several registers. Pop-ups, dropdown menus, and hexadecimal text boxes are available in the GUI to configure
several registers of the AD5413. To write the changes to the device, click Apply Changes (Label A). The functions within this
GUI that control various registers are described in Table 4.
L The Calibration Memory Refresh button initiates a write to the key register to perform a calibration memory refresh.
M The SW LDAC button initiates a write to the key register to perform a software LDAC command.
N The NOP Command button initiates a write to Address 0x00 for a no operation (NOP) command.
O Two Stage Readback menu. A 2-stage readback is initiated through the 2-stage readback select register. Click Readback to
initiate a write to the 2-stage readback select register and issue a NOP command.
AD5413 data sheet. This graphical
AD5413 data sheet.
U
K1
K5
K2
K6
K3
K4
K7
K8
K12
P Q
Figure 8. AD5413
AD5413
SDP-S
SDP-S
OUT
EVAL-AD5413SDZ
Full descriptions of each block and register setting are available
in the AD5413
diagram with labels is shown in Figure 8. Table 3 and Table 4
describe the functionality of each block.
L
K10
K9 K11
M
N
R
Block Diagram with Labels
address of the device and must correspond to the JP12 and JP14 links on
board sets the RESET pin high. Otherwise, the
board sets the LDAC pin high. Otherwise, the
, and displays if the output is in voltage, milliamps, or is high impedance (high-Z).
Rev. 0 | Page 6 of 17
Evaluation Board User Guide
data sheet. The full screen AD5413
S
SDP-S board pulls the RESET pin low.
SDP-S board pulls the LDAC pin low.
block
J
T
