UG-1757
OUT
+VSENSE
VI_OUT IN
GND
-VSENSE
OUT
IN
C_HART
+VSENSE
1 BLK
THROUGH-HOLE COMPONENTS USED FOR SERIES RESIS TORS
R10
1kΩ
JP8
VIOUT
1 BLK
R11
10Ω
C24
0.1µF
DNI PLACEHOLDER TO EXPERIMENT WITH SETTLING TIME
–VSENSE
1 BLK
R13
1kΩ
C_HART
1 BLK
C25
0.15µF
GND
Figure 17.
Figure 18. AD5413
EVAL-AD5413SDZ
VIOUT_TERMINAL
1 BLK
P6
1
P7
1
THROUGH-HOLE LOAD RESISTOR
OPTION IN GOLD PINS
GND
C26
0.047µF
AD5413 Output Stage
Evaluation Board Silkscreen, Primary
Rev. 0 | Page 14 of 17
Evaluation Board User Guide
P3
1
+VSENSE
2
VI_OUT
3
RETURN
4
–VSENSE
5
P8
C_HART
1
1727049
P9
1
