Spinhawk Professional 360° Rolling Video Camera Head
(GH-SPHK-01)
A s s e m b l y M a n u a l
What's In The Box
Please inspect the contents of your shipped package to ensure you have received everything that
is listed below.
Top Plate
2 x T-Type Allen Keys
Base Plate
(Sizes: 3/16mm, 6mm)
Spinhawk Camera Head
4 x Camera Bolts
(Sizes: 3/8" x 18mm)
2 x Camera Bolts
(Sizes: 3/8" x 12mm)
Rod Adapter
All rights reserved.
No part of this document may be reproduced, stored in a retrieval system, or transmitted by any form or by any means,
electronic, mechanical, photo-copying, recording, or otherwise, except as may be expressly permitted by the applicable copyright
statutes or in writing by the Publisher.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for PROAIM Spinhawk Professional
Summary of Contents for PROAIM Spinhawk Professional
- Page 1 Spinhawk Professional 360° Rolling Video Camera Head (GH-SPHK-01) A s s e m b l y M a n u a l What’s In The Box Please inspect the contents of your shipped package to ensure you have received everything that is listed below.
- Page 2 Safety Hints • Do not start operating the head until you have read and understood the operating instruction. • The assembly of the head should be done with extreme caution. • Lack of attention while assembling the head can cause substantial damage to equipment/operator. •...
- Page 3 Spinhawk Camera Head Setup Assembling of Top & Bottom plate • Push the locking lever on the both side of the Spinhawk camera head upwards. • Properly insert the base plate in the Spinhawk camera head. NOTE: There are strategically placed 3/8"-16 threaded holes for endless mounting capabilities .
- Page 4 Assembling of Rod Adapter • Attach the Rod Adapter by properly matching it with the threads of the top plate and properly tighten it using the screw driver (Not Included). NOTE: There are 15mm rods support complete your setup with accessories like a matte box and follow focus &...
- Page 5 • Properly slide the camera on the Fluid Head. NOTE: It securely mounts your film video camera equipped with 3/8"-16 mounting holes to a tripod or fluid head; you can even bolt the head to the table, suiting the availability. 360°...
- Page 6 Camera Mounting Setup • Insert the camera bolt in the base plate and mount the camera by matching the camera with the threads of the bolt. • After mounting the camera, tighten it properly using the screw driver (Not Included). •...
- Page 7 Alexa mini/LF, Alexa LF, Alexa65, RED DSMC2 cameras, Sony Venice, Panavision cameras, and of course, with your small or huge lenses. YOUR PROAIM SPINHAWK PROFESSIONAL ROLLING CAMERA HEAD ALL DRESSED UP AND READY TO GO! (SHOWN WITH OPTIONAL ACCESSORIES) Warranty: We offer one year warranty for our products from date of purchase. Within this period of time, we will repair it without charge for labor or parts.
