1. Align the proximal end of the adapter with the quick release button facing up and in
the same orientation as the stapling handle.
2. Simultaneously, press the two components together until the adapter is fully seated
into the stapling handle and tactile feedback is registered.
3. Confirm secure attachment by pulling the adapter and power handle in opposite
directions. The stapler will automatically begin to calibrate the adapter and the status
indicator light on the display screen will illuminate as shown in Table 10.
Loading A Stapling Reload
WARNING
Always select a reload with the appropriate staple size for the tissue thickness.
Overly thick or thin tissue may result in unacceptable staple formation.
PRECAUTION
Do not attempt to remove the shipping wedge until the reload is loaded onto
the adapter.
IMPORTANT
When using compatible stapling reloads, refer to the indications,
contraindications, warnings, and precautions described in the associated
Instructions for Use.
When using the linear adapters and Endo GIA™ single-use reloads or Endo GIA™
single-use reloads with Tri-Staple™ Technology:
1. Insert the pin located at the distal end of the adapter into the stapling reload. Ensure
that the LOAD alignment indicator on the reload aligns with the LOAD alignment
indicator on the shaft.
2. Lock the reload in place by pushing it in and twisting clockwise 45 degrees (relative to
the adapter). When loaded properly into the adapter, the reload unload button is seated
in place without any red showing underneath.
