System Overview
System Indicators
(1) LED INDICATOR
During use, the stapler uses an LED light, housed within the safety button, to indicate
fully clamped status, readiness to fire, and fire-enabled status.
GREEN LED INDICATOR
(2) OLED DISPLAY SCREEN INDICATORS
Graphical display indicators provide additional device status and operative readiness
for use in separate zones within the status border indicator frame.
OLED SYSTEM INDICATORS
1
OFF
ON
BLINKING
A.
B.
C.
D.
E.
F.
A.
2
D. E. F.
INDICATES
Stapling reload is not loaded or fully clamped
Stapling reload is fully clamped
The green LED / safety button is pressed; device
is entering firing mode
INDICATES
System status
Power status
Reload recognition status
Power handle and power shell status
Adapter status
Reload status
