Table 13: Signia™ Stapler Special Use Controls –
Disabling and re-enabling the rotation button controls.
1
Deactivation Sequence
Re-activation Sequence
NOTE
Positive audible tones will notify when settings have been changed.
Manually Changing Firing Speeds
When fully clamped on tissue and in fire mode, the rotation buttons are turned off and
are mapped into speed selection controls. Based on the force measured, the device
will program the appropriate speed selection and faster speeds will not be available.
To adjust to slower speeds, use the following steps:
1. Double click either lower rotation button to enter a slower speed setting. There are
only three speed settings (Standard, Medium and Slow).
2
Current Status
11
System Overview
