- Page 1 Grandstream Networks, Inc. GRP260X Essential IP Phones BroadWorks BLF Configuration Guide...
- Page 2 Table of Content INTRODUCTION ........................... 3 OVERVIEW OF FUNCTIONS ....................... 4 PROVISION THE BLF LIST ON THE PHONE ................4 VISUAL INDICATORS ........................7 DIRECTED CALL PICKUP ......................7 Table of Figures Figure 1: Configure Account Settings .................... 4 Figure 2: Configure Network Settings .................... 5 Figure 3: Configure Special Feature Option ..................
- Page 3 INTRODUCTION Grandstream GRP260X SIP phones support BroadWorks Busy Lamp Field (BLF) feature. BLF feature allows an end user, such as attendant, to monitor the hook status of a list of users. This document serves as an end user guide on how to configure Grandstream GRP260X SIP phones for BroadWorks Busy Lamp Field feature.
- Page 4 OVERVIEW OF FUNCTIONS Grandstream GRP260X SIP phones support the BroadWorks Busy Lamp Filed feature. GRP260x phones support this feature by changing the LED keys color and/or icon status of the VPK/MPK associated with the monitored users. Additionally, the phone system is also able to pick up the calls to the monitored extensions.
- Page 5 NAT Traversal should be set to “STUN”, and input a STUN server IP in web UI > Phone Settings > General Settings > STUN Server. • DNS mode needs to be set to “SRV”. Figure 2: Configure Network Settings 3. Set “Special Feature” to “BroadSoft”, set “Feature Key Synchronization” to enabled, under Account X >...
- Page 6 Figure 5: Configure Eventlist BLF URI 6. Configure “Auto Provision List Starting Point” to “MPK” or “VPK” under Programmable Keys > Advanced Settings. Default setting is “MPK”. Figure 6: Auto Provision List Starting Point After completing the configuration, the phone will start to monitor the extensions status using MPK.
- Page 7 VISUAL INDICATORS GRP260X Line key LEDs provide visual indications of the monitored extension by changing the LED colors and the icon status. The following table shows the BLF indicator status in different scenarios, it requires the monitored extension to enable the BLF feature on BroadWorks server: Table 1: Indicator Status BLF Indicator Status Monitored Extension Behavior...
