Full Height Label-OUT Display
Questions?
888.373.6057
Assembly GUIDE
or visit
wineracksamerica.com
Page 1
Package Contents
tools for assembly
Required
*Please verify that you have the correct number of parts before proceeding.
Depending on the model you purchased, your bundle should contain the following:
SIDE PANEL (x2)
Screwdriver
BOTTOM PANEL (x1)
TOP PANEL (x1)
Wood Glue
Suggested
TRIM PIECE (x1)
METAL RODS (x64)
Finish Nailer
Cordless Drill
RAIL SCREWS
WOOD SCREWS
FINISH NAILS
WOOD PUTTY
Nail Setter
Hammer
