Case/Base Aisle Rack
Assembly GUIDE
Screwless Connectors
Standard
Connector
Standard Base
Connector
End Ladder (left)
*Please verify that you have the correct number of parts before proceeding.
Depending on the model you purchased, your bundle should contain the following:
MIDDLE SUPPORT (X16)
WOOD SCREWS
STANDARD SUPPORT (X2)
SCREWLESS SUPPORT (X2)
FINISH NAILS
STANDARD CONNECTOR (X1)
SCREWLESS CONNECTOR (X3)
STANDARD BASE CONNECTOR (X1)
SCREWLESS BASE CONNECTOR (X1)
Standard
Supports
Inside Ladder (left)
Middle Ladder
Package Contents
END LADDER
END LADDER
LEFT (X1)
RIGHT (X1)
WOOD PUTTY
MIDDLE LADDER
INSIDE LADDER
(X2)
LEFT (X1)
Questions?
888.373.6057
or visit
wineracksamerica.com
Page 1
Inside Ladder (right)
End Ladder (right)
Middle Ladder
Make sure notched
supports are facing
inwards
Middle
Screwless
Supports
Supports
Screwless
Connector
Screwless Base
Connector
tools for assembly
INSIDE LADDER
RIGHT (X1)
Cordless Drill
Finish Nailer
Wood Glue
Utility Knife
Hammer
Nail Setter
