Magnum Aisle Rack
Assembly GUIDE
Screwless Connector
Standard Connector
Standard Base
Connector
*Please verify that you have the correct number of parts before proceeding.
Depending on the model you purchased, your bundle should contain the following:
STANDARD CONNECTOR (X1)
SCREWLESS CONNECTOR (X2)
SCREWLESS BASE CONNECTOR (X1)
STANDARD BASE CONNECTOR (X1)
End Ladder (left)
Package Contents
END LADDER
LEFT (X1)
End Ladder (right)
Middle Ladder
END LADDER
MIDDLE LADDER
RIGHT (X1)
(X8)
Questions?
888.373.6057
or visit
wineracksamerica.com
Page 1
IMPORTANT!
Make sure the slanted
bottle supports are
facing the front of the rack
Screwless Base Connector
Base Connectors are
2" in height.
tools for assembly
Cordless Drill
WOOD PUTTY
Finish Nailer
WOOD SCREWS
FINISH NAILS
Wood Glue
Utility Knife
Hammer
Nail Setter
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Wine racks America Magnum Aisle Rack
Summary of Contents for Wine racks America Magnum Aisle Rack
- Page 1 Magnum Aisle Rack Questions? 888.373.6057 Assembly GUIDE or visit wineracksamerica.com Page 1 End Ladder (right) Screwless Connector Standard Connector Middle Ladder Standard Base Connector IMPORTANT! Make sure the slanted bottle supports are facing the front of the rack Screwless Base Connector Base Connectors are 2”...
