Table of Contents

Base Horizontal Display
Assembly GUIDE
*Please verify that you have the correct number of parts before proceeding.
Depending on the model you purchased, your bundle should contain the following:
SIDE PANEL (x2)
TOP PANEL (x1)
RAIL SCREWS
WOOD SHIM
*Follow the same assembly procedure for all Base Label Out Display models

Package Contents

WOOD SCREWS
FINISH NAILS
Page 1
BOTTOM PANEL (x1)
METAL RODS (x28)
TRIM PIECE (x1)
WOOD PUTTY
Questions?
888.373.6057
or visit
wineracksamerica.com
tools for assembly
Required
Allen Wrench
Screwdriver
Wood Glue
Suggested
Finish Nailer
Cordless Drill
Nail Setter
Hammer
