Standard Tasting Table
Assembly GUIDE
Standard
Connector
End Ladder
*Please verify that you have the correct number of parts before proceeding.
Depending on the model you purchased, your bundle should contain the following:
END LADDER (X2)
35 3/4"
MIDDLE LADDER (X7)
35 3/4"
Middle Ladder
Package Contents
STANDARD 8 COLUMN CONNECTOR (X2)
SCREWLESS 8 COLUMN CONNECTOR (X2)
SOLID TOP (OPTIONAL)
WOOD PUTTY
Page 1
End Ladder
End Ladder
Middle Ladder
WOOD SCREWS
FINISH NAILS
Questions?
888.373.6057
or visit
wineracksamerica.com
Screwless
Connector
tools for assembly
Required
Wood Glue
Screwdriver
Suggested
Cordless Drill
Finish Nailer
+
Nail Setter
Hammer
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Wine racks America Standard Tasting Table
Summary of Contents for Wine racks America Standard Tasting Table
- Page 1 Standard Tasting Table Questions? 888.373.6057 Assembly GUIDE or visit wineracksamerica.com Page 1 End Ladder End Ladder Middle Ladder Standard Connector Screwless Connector Middle Ladder End Ladder Package Contents tools for assembly *Please verify that you have the correct number of parts before proceeding.
- Page 2 Standard Tasting Table Questions? 888.373.6057 Assembly GUIDE or visit wineracksamerica.com Page 2 1. Find an open, flat area in which to work. Carefully remove all components from the box and remove banding with a utility knife. Check the parts list to verify package contents.
- Page 3 Flip rack over. Attach a screwless 8 column connector to the top and bottom of your rack. Make sure the rack is flat on the floor while attaching screwless connectors. (figure 3) Standard Tasting Table kits are designed to show no visible hardware on the front of the rack. Use of of these following methods to install the screwless connectors: For no visible hardware, add wood glue to the inside of each connector notch.
- Page 4 Standard Tasting Table Questions? 888.373.6057 Assembly GUIDE or visit wineracksamerica.com Page 4 5. If you purchased a Solid Top with your rack, secure it by adding wood glue to the tops of each vertical riser. Clamp the top to the frame using standard wood clamps until fully dry. (figure 4) For extra support, use a nail gun to tack a nail through the top of the risers into the solid top support pieces.
