Assembly GUIDE
Single Deep
*Please verify that you have the correct number of parts before proceeding.
Depending on the model you purchased, your bundle should contain the following:
DOUBLE DEEP SIDE PANEL (x2)
TOP PANEL (x1)
RAIL SCREWS
WOOD SCREWS
*Follow the same assembly procedure for all Top Label Out Display models
Package Contents
FINISH NAILS
WOOD PUTTY
Double Deep
SINGLE DEEP SIDE PANEL (x2)
METAL RODS
DOUBLE DEEP (x32)
SINGLE DEEP (x16)
TRIM PIECE (x1)
Questions?
888.373.6057
or visit
wineracksamerica.com
Page 1
tools for assembly
Required
Allen Wrench
Screwdriver
Wood Glue
Suggested
Finish Nailer
Cordless Drill
Nail Setter
Hammer
