3 GATEWAY RECEIVER
3.1 GATEWAY RECEIVER POSITION
The boiler mounted Gateway is fitted in the receiver component of the boiler control panel (visible after opening the control
panel, see Fig. 3.1). Refer to the specific boiler model instructions for further details on the fitment and wiring,
LEDs
3.2 DESCRIPTION OF RECEIVER LEDs
LED
PWR Solid green: 230V present, the receiver is on.
Bluetooth connection of the receiver with the Smartech:
• 1 flash every 4 seconds: the receiver is connected to the Smartech and is
BLE
• 5 flashes per second: the receiver is trying to connect to the Smartech, if this
BUS
It is a service LED managed separately from the receiver, its operation is independent
from any receiver status.
Shows Smartech connection to home WiFi network:
• Off: the receiver is not connected to any Wi-Fi network or no account has been
CLOUD
• 1 flash per second: the receiver is connecting to the Wi-Fi network or associated
• Steady on: the receiver is connected to the Wi-Fi network and Internet and is working
4
Alpha Smartech Plus - Gateway Receiver
Receiver
communicating normally.
happens frequently, move the Smartech closer to the boiler/receiver.
connected to this receiver. The Smartech works regularly even without a Wi-Fi
connection, through the Bluetooth connection.
account, if the flashing persists check that the Wi-Fi network is active and verify that
you have entered the correct password in the receiver.
normally.
Fig. 3.1
Description
