2
MAIN SCREEN
2.1
MAIN SCREEN SYMBOLS
FRI 12:08
5
20
6
15°
7
2.2
NAVIGATION
Navigation through the various windows and settings may be carried out by rotating and pressing the outer body of the
thermostat as shown in Fig. 2.2.
Fig. 2.2
1
.
4
4
21.5
9
8
Fig. 2.1
Item
Text message (for example: date, connection status,
1
error)
°
Temperature degree symbol
2
Heating request
2
3
DHW request
3
Detected room temperature
4
Set room temperature
5
Weather (if connected to internet)
6
Outdoor temperature (if connected to internet)
7
8
9
Rotate
Press
Press for three seconds
Wait five seconds
Main screen display
STAND-BY operating mode
SUMMER operating mode
WINTER operating mode
Battery level 100%
Battery level 75%
Battery level 50%
Battery level 25%
Battery flat
Automatic mode with programming
Temporary manual mode (until next time
slot) - semi automatic
Manual mode
Alpha Smartech Plus - Main Screen
