Atop EH9711 Series User Manual

Industrial managed ethernet switch
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Industrial Managed
User Manual
Ethernet Switch – EH9711
Atop Technologies, Inc.
Industrial Managed
Ethernet Switch
User Manual
V0.4
th
October 21
, 2022
Series covered by this manual:
EH9711
This PDF Document contains internal hyperlinks for ease of navigation.
For example, click on any item listed in the Table of Contents to go to that page.
Page 1 of 223

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EH9711 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Atop EH9711 Series

Summary of Contents for Atop EH9711 Series

  • Page 1 Industrial Managed User Manual Ethernet Switch – EH9711 Atop Technologies, Inc. Industrial Managed Ethernet Switch User Manual V0.4 October 21 , 2022 Series covered by this manual: EH9711 This PDF Document contains internal hyperlinks for ease of navigation. For example, click on any item listed in the Table of Contents to go to that page.
  • Page 2 Industrial Managed User Manual Ethernet Switch – EH9711 Published by: Atop Technologies, Inc. 2F, No. 146, Sec. 1, Tung-Hsing Rd, 30261 Chupei City, Hsinchu County Taiwan, R.O.C. Tel: +886-3-550-8137 Fax: +886-3-550-8131 www.atoponline.com Page 2 of 223...
  • Page 3 Ethernet Switch – EH9711 Important Announcement The information contained in this document is the property of Atop Technologies, Inc., and is supplied for the sole purpose of operation and maintenance of Atop Technologies, Inc., products. No part of this publication is to be used for any other purposes, and it is not to be reproduced, copied, disclosed, transmitted, stored in a retrieval system, or translated into any human or computer language, in any form, by any means, in whole or in part, without the prior explicit written consent of Atop Technologies, Inc.,...

  • Page 4: Table Of Contents

    Industrial Managed User Manual Ethernet Switch – EH9711 Table of Contents Introduction ........................13 Introduction to Industrial Managed Switch....................13 Software Features ..........................14 Introduction to the Document ......................... 14 Configuring with a Web Browser..................15 System ..............................17 2.1.1 Information ............................. 17 2.1.2 IP ................................
  • Page 5 Industrial Managed User Manual Ethernet Switch – EH9711 2.14.6 Port Tag Remarking ..........................125 2.14.7 Port DSCP ............................126 2.14.8 DSCP-Based QoS ..........................127 2.14.9 DSCP Translation ..........................129 2.14.10 DSCP Classification ........................130 2.14.11 QoS Control List ........................... 130 2.14.12 Storm Policing ..........................
  • Page 6 Industrial Managed User Manual Ethernet Switch – EH9711 3.10.1 PTP............................... 201 3.10.2 802.1AS Statistics ..........................202 3.11 MAC Table ............................203 3.12 VLANs ..............................203 3.12.1 Membership ............................203 3.12.2 Ports ..............................204 3.13 DDMI ..............................206 3.13.1 Overview .............................. 206 3.13.2 Detailed ..............................
  • Page 7 Industrial Managed User Manual Ethernet Switch – EH9711 Figure 2.24 Configuration-> Security Menu ........................37 Figure 2.25 Configuration-> Security -> Switch Menu ....................38 Figure 2.26 Webpage to Configure Security Switch Users ....................38 Figure 2.27 Webpage to Configure Security Switch Users – After Clicked Add New User Button ........39 Figure 2.28 Webpage to Edit User ...........................
  • Page 8 Industrial Managed User Manual Ethernet Switch – EH9711 Figure 2.84 Webpage to Configure LLDP ........................102 Figure 2.85 Webpage to Configure SyncE ........................104 Figure 2.86 Webpage to Configure MAC Table ......................107 Figure 2.87 Example of VLAN Configuration ......................109 Figure 2.88 Webpage for Basic Configuration of VLANs .....................
  • Page 9 Industrial Managed User Manual Ethernet Switch – EH9711 Figure 3.24 Webpage to Monitor Network Access Server Switch Status .............. 177 Figure 3.25 Webpage to Monitor NAS Statistics Port 1 ..................178 Figure 3.26 Webpage to Monitor ACL Status ......................179 Figure 3.27 Webpage to Monitor Dynamic ARP Inspection Table ................
  • Page 10 Industrial Managed User Manual Ethernet Switch – EH9711 Figure 5.14 Activating New Configuration Webpage ..................... 222 Figure 5.15 Webpage to Delete a Configuration File ..................... 222 Figure 5.16 Confirmation for deleting a configuration file ..................222 Table of Tables Table 2.1 Description of the System Information Configuration ................17 Table 2.2 Description of Basic Settings ........................
  • Page 11 Industrial Managed User Manual Ethernet Switch – EH9711 Table 2.53 Descriptions of ARP Inspection Dynamic Table ..................82 Table 2.54 Descriptions of AAA RADIUS ......................... 83 Table 2.55 Comparison of Authentication Server Settings between RADIUS and TACACS+ ........ 84 Table 2.56 Descriptions of AAA RADIUS ......................... 85 Table 2.57 Descriptions of Common Aggregation Configuration ................
  • Page 12 Industrial Managed User Manual Ethernet Switch – EH9711 Table 3.5 Monitoring Descriptions of System Log ....................164 Table 3.6 Monitoring Descriptions of System Detailed Log..................165 Table 3.7 Monitoring Descriptions of Traffic Overview of Ports ................166 Table 3.8 Monitoring Descriptions of Queuing Counters..................167 Table 3.9 Monitoring Descriptions of QoS Control List Status ................

  • Page 13: Introduction

    Introduction to Industrial Managed Switch Atop’s EH (Ethernet Hub) 9711 series are product lines of powerful industrial managed switch which are referred to as Open Systems Interconnection (OSI) Layer 2 bridging devices. Unlike an “unmanaged” switch, which is normally found in homes or in Small Office/Home Office (SOHO) environments and runs in “auto-negotiation”...

  • Page 14: Software Features

    These features enable Atop’s switches to be used in safety applications, and factory and process automation. The followings are the list of protocols and software features.

  • Page 15: Configuring With A Web Browser

    2 Configuring with a Web Browser There are three ways to configure Atop’s Industrial Managed Ethernet Switch: Web browser, Telnet console, and Serial console. How to access the industrial managed switch through web browser is explained in Chapter 2 through Chapter 5. There are only a few differences among these three methods.

  • Page 16: Figure 2.2 Login Page

    Industrial Managed User Manual Ethernet Switch – EH9711 Figure 2.2 Login page If the user entered wrong passwords, users can try to re-enter the new username and password again until it is correct. Or users can simply click the Cancel button to forfeit the process. If the login process was success, the user will be presented with the Port State Overview webpage which shows the front panel of the managed switch as shown in Figure 2.3.

  • Page 17: System

    2.1.1 Information This subsection describes how users can assign system’s details to the Atop’s switch. There are three fields in this System Information Configuration webpage: System Contact, System Name, and System Location. By entering this unique and relevant system information, it will help identifying one specific switch among all the others in the network. However, the switch must support a SNMP protocol.

  • Page 18: Figure 2.6 Webpage To Configure System's Ip Information

    Industrial Managed User Manual Ethernet Switch – EH9711 Label Description Factory Default 9), minus sign (-). No space characters are permitted as part of a name. The first character must be an alpha character. And the first or last character must not be a minus sign.

  • Page 19: Figure 2.7 Webpage To Configure System's Ip Configuration

    Industrial Managed User Manual Ethernet Switch – EH9711 Figure 2.7 Webpage to Configure System’s IP Configuration Table 2.2 Description of Basic Settings Label Description Mode Configure the IP stack to act as a Host, where IP traffic between interfaces will not be routed. This setting controls the DNS name resolution done by the switch.
  • Page 20 Industrial Managed User Manual Ethernet Switch – EH9711 Label Description The VLAN associated with the IP interface. Only ports in this VLAN will be able to access the IP interface. This field is only available for input when creating a new interface Enable the DHCPv4 client by checking this box.

  • Page 21: Ntp

    2.1.3 Atop’s industrial managed switch has internal calendar (date) and clock (or system time) which can be set manually or automatically. Figure 2.10 shows the Network Time Protocol (NTP) configuration webpage. Here, users can automatically set the device’s time by first selecting Enabled from the drop-down menu of Mode field. Then, users must enter the IP or Domain address of up to the total of five NTP servers: Server1, Server2, Server3, Server4, and Server 5.

  • Page 22: Time

    Industrial Managed User Manual Ethernet Switch – EH9711 Figure 2.10 Webpage to Configure System NTP The detailed description of each field is provided in Table 2.5. Table 2.5 Descriptions of the NTP Settings Label Description Factory Default Select to enable or disable an automatically setting of the device time.

  • Page 23: Figure 2.11 Webpage To Configure System Time

    Industrial Managed User Manual Ethernet Switch – EH9711 The third part : Daylight-Saving Time Configuration, if the switch is deployed in a region where daylight saving time is practiced (see note below for explanation), please select the Recurring or Non-Recurring options for Daylight Saving Time field within the Daylight-Saving Time Configuration box.

  • Page 24: Log

    Industrial Managed User Manual Ethernet Switch – EH9711 Table 2.7 Description of Time Zone Configuration Label Description Lists various Time Zones worldwide. Select appropriate Time Zone from the drop down and click Save to Time Zone set. The 'Manual Setting' options is used for the specific time zone which is excluded from the options list. Hours Number of hours offset from UTC.

  • Page 25: Dip Switch

    Industrial Managed User Manual Ethernet Switch – EH9711 Figure 2.12 Webpage to Configure System Log Table 2.9 Descriptions of the System Zone Configuration Field Detailed description of mode Default value Indicates the server mode operation. When the mode operation is enabled, the syslog Disabled message will send out to syslog server.

  • Page 26: Alert

    Industrial Managed User Manual Ethernet Switch – EH9711 Figure 2.13 Webpage to Configure System DIP Switch 2.1.7 Alert This webpage allows the users to configure how each type of the power status alarm events will be sent or notify the users. Power Status Alarms keep track of power status of the switch based on the available input connectors.

  • Page 27: Figure 2.15 Webpage To Configure System Smtp Setting

    Industrial Managed User Manual Ethernet Switch – EH9711 Figure 2.15 Webpage to Configure System SMTP Setting An example of SMTP Setting is shown in Figure 2.16. When users select the box behind the Authentication field, TLS field as well as User Name and Change Password fields are enabled. Users can configure e-mail address of sender, so that the recipient can reply back to the correct person in charge.

  • Page 28: Ports

    Industrial Managed User Manual Ethernet Switch – EH9711 Authentication By checking on the box, users Enable or disable an authentication login. If enabled, users need an authentication to access the SMTP Disable (Unchecked) server. Thus, the users will also need to setup User Name and Password to connect to the SMTP server Enable or disable Transport Layer Security (TLS)/ Secure Sockets TLS/SSL...

  • Page 29: Figure 2.17 Webpage To Configure Ports

    Industrial Managed User Manual Ethernet Switch – EH9711 Figure 2.17 Webpage to Configure Ports Table 2.12 Descriptions of Port Configuration Field Label Subfield Label Description Factory Default Indicate port number. e.g., ranging from 1 to 11. In the first Port row, port * will show all possible configurable options for the device.

  • Page 30: Erps

    ERPS provides highly reliable and stable protection in the ring topology, and it never forms loops, which can affect network operation and service availability. Figure 2.18 depicts an example of ring topology forming by four Atop’s managed switch series. Page 30 of 223...

  • Page 31: Figure 2.18 An Example Of Ring Topology (A) Major Ring, And (B) Sub-Ring (Example Made On Eh7520)

    Industrial Managed User Manual Ethernet Switch – EH9711 Figure 2.18 An Example of Ring Topology (a) Major Ring, and (b) Sub-Ring (Example made on EH7520) An ERPS ring consists of interconnected Layer 2 switching devices configured with the same control VLAN. An ERPS ring can be a major ring or a sub-ring, as shown in Figure 2.18.

  • Page 32: Figure 2.19 Webpage To Configure Erps

    Industrial Managed User Manual Ethernet Switch – EH9711 Figure 2.19 Webpage to Configure ERPS Table 2.13 Description of EPRS Configuration Table Label Description The ID of ERPS. Valid range 1 - 64. ERPS # RPL Mode Ring Protection Link mode. Possible values: Ring Protection Link mode.

  • Page 33: Figure 2.20 After Clicking To Configure Erps

    Industrial Managed User Manual Ethernet Switch – EH9711 Figure 2.20 After Clicking to Configure ERPS Table 2.14 shows the descriptions of each field and subfields in the ERPs configuration webpage in details. Table 2.14 Descriptions of ERPS Configuration Webpage Field Label Subfield Description Factory Default...

  • Page 34: Dhcpv4

    DHCPv4 Atop’s EH9711 managed switch can act as a DHCPv4 (Dynamic Host Configuration Protocol over IP version 4) server in the local network. By enabling this function in the managed switch, an IPv4 addresses and related fields will be automatically assigned and delivered by the DHCPv4 server running inside the managed switch to other network devices connected to the managed switch.

  • Page 35: Relay

    Industrial Managed User Manual Ethernet Switch – EH9711 To enable the DHCP Snooping feature, select the Enabled option from the dropdown menu behind the Snooping Mode option under the DHCP Snooping Configuration webpage as shown in Figure 2.22. By default, all interfaces of EH9711 are untrusted for DHCP Snooping.

  • Page 36: Figure 2.23 Webpage To Configure Dhcpv4 Relay

    Industrial Managed User Manual Ethernet Switch – EH9711 Users also have a choice to enable the DHCP Relay Information Mode. If it is enabled, the switch will insert information about the client’s network location into the packet header of the DHCP request, which is coming from the client on an untrusted interface.

  • Page 37: Security

    Ethernet Switch – EH9711 Security Security Configuration of Atop’s EH9711 managed switch consists of three main parts: Switch, Network, and AAA. There are a number of submenus for each of these main security configuration parts as shown in Figure 2.24.

  • Page 38: Figure 2.25 Configuration-> Security -> Switch Menu

    Industrial Managed User Manual Ethernet Switch – EH9711 Figure 2.25 Configuration-> Security -> Switch Menu 2.5.1.1 Switch Users A simple way of providing terminal access control in your network device (managed switch) is to use passwords and assign privilege levels. Password protection restricts access to a network or network device. Privilege levels define what commands users can enter after they have logged into a network device.

  • Page 39: Figure 2.27 Webpage To Configure Security Switch Users - After Clicked Add New User Button

    Industrial Managed User Manual Ethernet Switch – EH9711 Field Label Description can be used for an administrator account, privilege level 10 for a standard user account and privilege level 5 for a guest account. There is also a hyperlink to Add/Edit User in each username. Users can also click Add New User button to add a new user. After clicked, the webpage in Figure 2.27 will be shown.

  • Page 40: Table 2.19 Examples Of Group Name

    Industrial Managed User Manual Ethernet Switch – EH9711 2.5.1.2 Switch Privilege Levels This subsection describes on the Privilege Level Configuration webpage as shown in Figure 2.29. The user can customize the privilege level in the table on this webpage. Group Name is the name identifying the privilege group. In most cases, a privilege level group consists of a single module (e.g., LACP, RSTP or QoS), but a few of them contains more than one.

  • Page 41: Figure 2.29 Webpage To Configure Privilege Levels Of The Switch

    Industrial Managed User Manual Ethernet Switch – EH9711 Figure 2.29 Webpage to Configure Privilege Levels of the Switch 2.5.1.3 Switch Auth Method The authentication section allows you to configure how a user is authenticated when he/she logs into the switch via one of the management client interfaces.

  • Page 42: Figure 2.30 Webpage To Configure Switch Authentication Method

    Industrial Managed User Manual Ethernet Switch – EH9711 Figure 2.30 Webpage to Configure Switch Authentication Method Table 2.20 Descriptions of Switch Authentication Method Label Description Factory Default Authentication Method Configuration The management client for which the configuration below applies, which consists Client of console, telnet, ssh.

  • Page 43: Figure 2.31 Webpage To Configure Ssh

    Industrial Managed User Manual Ethernet Switch – EH9711 Label Description Factory Default Enable accounting of all commands with a privilege level higher than or equal to Cmd Lvl this level. Valid values are in the range 0 to 15. Leave the field empty to disable NULL command accounting.

  • Page 44: Figure 2.32 Webpage To Https Configuration

    Industrial Managed User Manual Ethernet Switch – EH9711 Figure 2.32 Webpage to HTTPS Configuration Figure 2.33 Webpage to HTTPS Configuration with Certificate Uploading Table 2.21 Description of HTTPS Configuration Webpage Label Description Factory Default Indicate the HTTPS mode operation. Mode Enabled: Enable HTTPS mode operation.

  • Page 45: Figure 2.34 Webpage To Configure Snmp System

    The SNMP is used by network management system or third-party software to monitor devices such as managed switches in a network to retrieve network status information and to configure network parameters. The Atop’s managed switch support SNMP and can be configured in this section.

  • Page 46: Figure 2.35 Webpage To Configure Snmp Trap Destinations

    Industrial Managed User Manual Ethernet Switch – EH9711 Figure 2.35 Webpage to Configure SNMP Trap Destinations Figure 2.36 Adding New Entry to SNMP Trap Destination Table Table 2.22 Descriptions of SNMP Trap Destination Configurations Label Description Delete Users are allowed to delete each entry separately. Indicates the trap Configuration's name.

  • Page 47: Figure 2.37 Webpage To Configure Snmp Trap Sources

    Industrial Managed User Manual Ethernet Switch – EH9711 2.5.1.8 SNMP Trap Sources This page provides SNMP Trap Source configurations. A trap is sent for the given trap source if at least one filter with filter type included matches the filter, and no filters with filter type excluded matches. Figure 2.37 shows the webpage when there is no entry in the trap source configurations.

  • Page 48: Figure 2.39 Webpage To Configure Snmp Communities

    Industrial Managed User Manual Ethernet Switch – EH9711 Label Description 4294967295) or asterisk (*) which are separated by dots (.). The first character must not begin with asterisk (*) and the maximum of OID count must not exceed 128. 2.5.1.9 SNMP Communities This submenu allows users to configure SNMP community table as shown in Figure 2.39.

  • Page 49: Figure 2.41 Webpage To Configure Snmp Users

    Industrial Managed User Manual Ethernet Switch – EH9711 2.5.1.10 SNMP Users This submenu allows users to configure SNMPv3 user table on this page. The entry index keys are Engine ID and User Name. As mentioned earlier, SNMPv3 is a more secure SNMP protocol than earlier versions. In this part, the users will be able to set a password and an encryption key to enhance the data security.

  • Page 50: Figure 2.42 Webpage To Configure Snmp Groups

    Industrial Managed User Manual Ethernet Switch – EH9711 Label Description Factory Default The value of security level cannot be modified if entry already exists. That means must first ensure that the value is set correctly. A string identifying the authentication password phrase. For MD5 authentication protocol, the allowed string length is 8 to 32.

  • Page 51: Figure 2.43 Webpage To Configure Snmp Views

    Industrial Managed User Manual Ethernet Switch – EH9711 2.5.1.12 SNMP Views Figure 2.43 shows SNMPv3 View Configuration webpage. It contains SNMPv3 view table. The entry index keys are View Name and OID Subtree. Click Add New Entry button to add a new view entry to the table. Table 2.27 describes the column labels of the SNMPv3 view table.

  • Page 52: Figure 2.44 Webpage To Configure Snmp Access

    2.5.1.14 RMON Statistics Figure 2.45 shows RMON (Remote Network Monitoring) Statistics Configuration. Atop’s managed switch can monitoring network traffic on remote Ethernet segment to detect problem inside the network. The entry index key is ID for RMON Statistics table. Click Add New Entry button to add a new RMON Statistics entry to the table as shown in Figure 2.46. Table 2.29 describes the column labels of the RMON Statistics table.

  • Page 53: Figure 2.45 Webpage To Configure Rmon Statistics

    Industrial Managed User Manual Ethernet Switch – EH9711 Figure 2.45 Webpage to Configure RMON Statistics Figure 2.46 Adding New Entry to RMON Statistics Configuration Table 2.29 Descriptions of RMON Statistics Label Description Factory Default Check to delete the entry. It will be deleted during the next save. Delete Indicates the index of the entry.

  • Page 54: Figure 2.48 Adding New Entry To Rmon History Table

    Industrial Managed User Manual Ethernet Switch – EH9711 Figure 2.48 Adding New Entry to RMON History Table Table 2.30 Descriptions of RMON History Label Description Factory Default Check to delete the entry. It will be deleted during the next save. Delete Indicates the index of the entry.

  • Page 55: Figure 2.50 Webpage To Configure Rmon Event

    Industrial Managed User Manual Ethernet Switch – EH9711 Label Description Factory Default packets are normal. InErrors: The number of inbound packets that contained errors preventing them from being deliverable to a higher-layer protocol. InUnknownProtos: the number of the inbound packets that were discarded because of the unknown or un-support protocol.

  • Page 56: Network

    Industrial Managed User Manual Ethernet Switch – EH9711 Table 2.32 Descriptions of RMON Event Label Description Factory Default Check to delete the entry. It will be deleted during the next save. Delete Indicates the index of the entry. The range is from 1 to 65535. Null Desc Indicates this event, the string length is from 0 to 127, default is a null string.

  • Page 57: Figure 2.52 Webpage To Configure Network Port Security

    Industrial Managed User Manual Ethernet Switch – EH9711 Figure 2.52 Webpage to Configure Network Port Security Table 2.33 Descriptions of Port Security Configuration Label Description Factory Default Global Configuration If checked, secured MAC addresses are subject to aging as discussed under Aging Disabled Aging Enabled...
  • Page 58 Industrial Managed User Manual Ethernet Switch – EH9711 Label Description Factory Default The port number to which the configuration below applies. Port no. 1 ~ 11 Port Controls whether Port Security is enabled on this port. Notice that other modules Mode may still use the underlying port security features without enabling Port Security Disabled...

  • Page 59: Figure 2.53 Webpage To Configure Network Port Security Mac Addresses

    Industrial Managed User Manual Ethernet Switch – EH9711 Static entries are part of the running-config and will survive interface link state changes and reboots if saved to startup- config. Static entries can be added to the running-config at any time whether or not Port Security is enabled. ...

  • Page 60: Figure 2.54 Webpage To Configure Network Nas

    Industrial Managed User Manual Ethernet Switch – EH9711 This feature provides access control on a port basis. There are two types of authentications: IEEE 802.1X and MAC-based. The 802.1X supports Port-based 802.1X authentication type. The following three terms are used in the 802.1X context: Supplicant, Authenticator, and the Authentication server.
  • Page 61 Industrial Managed User Manual Ethernet Switch – EH9711 Label Description Factory Default device is plugged into a switch port or if a supplicant is no longer attached. For MAC-based ports, reauthentication is only useful if the RADIUS server configuration has changed. It does not involve communication between the switch and the client, and therefore doesn't imply that a client is still present on a port (see Aging Period below).
  • Page 62 Industrial Managed User Manual Ethernet Switch – EH9711 Label Description Factory Default The "RADIUS-Assigned VLAN Enabled" checkbox provides a quick way to globally enable/disable RADIUS-server assigned VLAN functionality. When checked, the individual ports' ditto setting determines whether RADIUS-assigned VLAN is enabled on that port. When unchecked, RADIUS-server assigned VLAN is disabled on all ports.
  • Page 63 Industrial Managed User Manual Ethernet Switch – EH9711 Label Description Factory Default and TLS. The important thing is that the authenticator (the switch) doesn't need to know which authentication method the supplicant and the authentication server are using, or how many information exchange frames are needed for a particular method.
  • Page 64 Industrial Managed User Manual Ethernet Switch – EH9711 Label Description Factory Default This option is only available for single-client modes, i.e. • Port-based 802.1X • Single 802.1X RADIUS attributes used in identifying a QoS Class: The User-Priority-Table attribute defined in RFC4675 forms the basis for identifying the QoS Class in an Access-Accept packet.
  • Page 65 Industrial Managed User Manual Ethernet Switch – EH9711 Label Description Factory Default VLAN configuration. Guest VLAN Operation: When a Guest VLAN enabled port's link comes up, the switch starts transmitting EAPOL Request Identity frames. If the number of transmissions of such frames exceeds Max. Reauth. Count and no EAPOL frames have been received in the meanwhile, the switch considers entering the Guest VLAN.

  • Page 66: Figure 2.55 Access Control List's Submenus

    Industrial Managed User Manual Ethernet Switch – EH9711 ACL implementations can be quite complex, for example, when the ACEs are prioritized for the various situation. In networking, the ACL refers to a list of service ports or network services that are available on a host or server, each with a list of hosts or servers permitted or denied to use the service.
  • Page 67 Industrial Managed User Manual Ethernet Switch – EH9711 Label Description Factory Default Select which rate limiter to apply on this port. The allowed values are Disabled Rate Disabled Limiter ID or the values 1 through 16. The default value is "Disabled". Select which port frames are redirected on.

  • Page 68: Figure 2.57 Webpage To Configure Network Acl Rate Limiters

    Industrial Managed User Manual Ethernet Switch – EH9711 Figure 2.57 Webpage to Configure Network ACL Rate Limiters Table 2.37 Descriptions of Network ACL Rate Limiters Label Description Factory Default The rate limiter ID for the settings contained in the same Limiter ID 1 to 16 Rate Limiter row and its range is 1 to 16.

  • Page 69: Figure 2.58 Webpage To Configure Network Acl Access Control

    Industrial Managed User Manual Ethernet Switch – EH9711 Figure 2.58 Webpage to Configure Network ACL Access Control Table 2.38 Summary of Label, Description, and Factory Default for ACL (Access Control List) Label Description Factory Default ACE Configuration Indicates the ACE ID. Disabled Indicates the ingress port of the ACE.

  • Page 70: Figure 2.59 Webpage To Configure Network Acl Access Control After Clicked + To Add New Entry

    Industrial Managed User Manual Ethernet Switch – EH9711 : Deletes the ACE. : The lowest plus sign adds a new entry at the bottom of the ACE listings After clicking on the plus sign to insert a new ACE (Access Control Entry), the users can configure an ACE on the webpage as shown in Figure 2.59.

  • Page 71: Table 2.40 Description Of Acl Configuration With Mac Parameters

    Industrial Managed User Manual Ethernet Switch – EH9711 Label Description ARP: Only ARP frames can match this ACE. Notice the ARP frames won't match the ACE with ethernet type. IPv4: Only IPv4 frames can match this ACE. Notice the IPv4 frames won't match the ACE with ethernet type.

  • Page 72: Table 2.41 Description Of Acl Configuration With Vlan Parameters

    Industrial Managed User Manual Ethernet Switch – EH9711 Label Description When "Specific" is selected for the DMAC filter, you can enter a specific destination MAC address. The DMAC Value legal format is "xx-xx-xx-xx-xx-xx" or "xx.xx.xx.xx.xx.xx" or "xxxxxxxxxxxx" (x is a hexadecimal digit). A frame that hits this ACE matches this DMAC value.

  • Page 73: Table 2.43 Description Of Acl Configuration With Ipv4 Parameters

    Industrial Managed User Manual Ethernet Switch – EH9711 Label Description Factory Default Host: Target IP filter is set to Host. Specify the target IP address in the Target IP Address field that appears. Network: Target IP filter is set to Network. Specify the target IP address and target IP mask in the Target IP Address and Target IP Mask fields that appear.

  • Page 74: Table 2.44 Description Of Acl Configuration With Ipv6 Parameters

    Industrial Managed User Manual Ethernet Switch – EH9711 Label Description Factory Default IP Protocol When "Specific" is selected for the IP protocol value, you can enter a specific value. The allowed range is 0 to 255. A frame that hits this ACE matches this IP protocol value. Value IP TTL Specify the Time-to-Live settings for this ACE.

  • Page 75: Table 2.45 Description Of Acl Configuration With Icmp Parameters

    Industrial Managed User Manual Ethernet Switch – EH9711 Label Description Factory Default value. A field for entering an IPv6 next header filter appears. ICMP: Select ICMP to filter IPv6 ICMP protocol frames. Extra fields for defining ICMP parameters will appear. These fields are explained later in this help file. UDP: Select UDP to filter IPv6 UDP protocol frames.
  • Page 76 Industrial Managed User Manual Ethernet Switch – EH9711 Label Description Factory Default care"). Specific: If you want to filter a specific TCP/UDP source filter with this ACE, you can enter a specific TCP/UDP source value. A field for entering a TCP/UDP source value appears.

  • Page 77: Figure 2.60 Webpage To Ip Source Guard Configuration

    Industrial Managed User Manual Ethernet Switch – EH9711 Label Description Factory Default 1: TCP frames where the URG field is set must be able to match this entry. Any: Any value is allowed ("don't-care") Table 2.47 Description of ACL Configuration with Ethernet Type Parameters Label Description Factory...

  • Page 78: Figure 2.61 Webpage To Configure Network Ip Source Guard Static Table

    Industrial Managed User Manual Ethernet Switch – EH9711 Table 2.48 Descriptions of Network IP Source Guard Configuration Label Description Factory Default IP Source Guard Configuration Enable the Global IP Source Guard or disable the Global IP Source Guard. All Mode Disabled configured ACEs will be lost when the mode is enabled.

  • Page 79: Figure 2.62 Arp Inspection Menu

    Industrial Managed User Manual Ethernet Switch – EH9711 list of submenus under the SecurityNetworkARP Inspection. It contains Port Configuration, VLAN Configuration, Static Table and Dynamic Table. Figure 2.62 ARP Inspection Menu 2.5.2.8.1 Port Configuration To configure ARP Inspection for port(s) on the managed switch, the users can use the webpage shown in Figure 2.63. First, enable the ARP Inspection by selecting the Mode option.

  • Page 80: Figure 2.64 Webpage To Configure Network Arp Inspection Vlan

    Industrial Managed User Manual Ethernet Switch – EH9711 Label Description Factory Default setting of "Check VLAN" is enabled, the log type of ARP Inspection will refer to the VLAN setting. Possible setting of "Check VLAN" are: Enabled: Enable check VLAN operation. Disabled: Disable check VLAN operation.

  • Page 81: Figure 2.65 Webpage To Configure Network Arp Inspection Static Table

    Industrial Managed User Manual Ethernet Switch – EH9711 port. Second, you can specify which VLAN will be inspected on VLAN mode configuration web page. The log type also can be configured on per VLAN setting. Possible types are: None: Log nothing. None Log Type Deny: Log denied entries.

  • Page 82: Aaa

    Industrial Managed User Manual Ethernet Switch – EH9711 Each webpage can show up to 99 entries from the Dynamic ARP Inspection table. The default maximum entries per page is 20. This can be selected through the "entries per page" input field. When first visited, the web page will show the first 20 entries from the beginning of the Dynamic ARP Inspection Table.

  • Page 83: Figure 2.67 Webpage To Configure Aaa Radius

    Industrial Managed User Manual Ethernet Switch – EH9711  Authorization—Provides access control. AAA authorization is the process of assembling a set of attributes that describe what the user is authorized to perform. Authorization in EH9711 switches is provided by attributes that are downloaded from AAA servers.

  • Page 84: Table 2.55 Comparison Of Authentication Server Settings Between Radius And Tacacs

    Industrial Managed User Manual Ethernet Switch – EH9711 Label Description Factory Default Specify to change the secret key or not. When "Yes" is selected for the option, you can change the secret key - up to 63 characters long - shared between the Change Secret Key RADIUS server and the switch.

  • Page 85: Aggregation

    Aggregation is a technique to use multiple ports in parallel to increase the link speed beyond the limits of a port and to increase the redundancy for higher availability. Atop’s EH9711 allows the aggregation on its ports. Figure 2.69 lists the submenus under the ConfigurationAggregation.

  • Page 86: Common

    Industrial Managed User Manual Ethernet Switch – EH9711 Figure 2.69 Aggregation Submenus 2.6.1 Common The webpage in Figure 2.70 is used to configure the Aggregation hash mode. The configured mode is applied to the whole network elements. Four contributors can be selected and used to create the hash code which are Source MAC Address, Destination MAC Address, IP Address, and TCP/UDP Port Number.

  • Page 87: Lacp

    Industrial Managed User Manual Ethernet Switch – EH9711 Figure 2.71 Webpage to Configure Group Aggregation Table 2.58 Descriptions of Aggregation Group Configuration Label Description Factory Default Indicates the aggregation group ID for the settings contained in the same row. Group ID Group ID "Normal"...

  • Page 88: Spanning Tree

    RSTP (Rapid Spanning Tree Protocol), IEEE 802.1W, is also supported in Atop’s managed switches. It is an evolution of the STP, but it is still backwards compatible with standard STP. RSTP has the advantage over the STP. When there is a topology change such as link failure in the network, the RSTP will converge significantly faster to a new spanning tree topology.

  • Page 89: Bridge Settings

    Industrial Managed User Manual Ethernet Switch – EH9711 MSTP (Multiple Spanning Tree Protocol) is also a standard defined by the IEEE 802.1s that allows multiple VLANs to be mapped to a single spanning tree instance called MST Instance, which will provide multiple pathways across the network. It is compatible with STP and RSTP.

  • Page 90: Msti Mapping

    Industrial Managed User Manual Ethernet Switch – EH9711 Label Description Factory Default Controls the bridge priority. Lower numeric values have better priority. The bridge priority plus the MSTI instance number, concatenated with the 6-byte MAC address of the switch forms a Bridge Identifier. 32768 Bridge Priority For MSTP operation, this is the priority of the CIST.

  • Page 91: Figure 2.74 Webpage To Configure Msti Mapping Of Spanning Tree

    Industrial Managed User Manual Ethernet Switch – EH9711 Figure 2.74 Webpage to Configure MSTI Mapping of Spanning Tree Table 2.61 Descriptions of Bridge Priorities Configuration of Spanning Tree Label Description Factory Default Configuration Identification The name identifying the VLAN to MSTI mapping. Bridges must DUT’s Configuration share the name and revision (see below), as well as the VLAN-to-...

  • Page 92: Msti Priorities

    Industrial Managed User Manual Ethernet Switch – EH9711 2.7.3 MSTI Priorities MSTI Priorities webpage is shown in Figure 2.75. This page allows the user to inspect and/or change the current STP MSTI bridge instance priority configurations. Table 2.62 summarizes the description of parameters under MSTI Configuration. Figure 2.75 Webpage to Configure Bridge Priorities of Spanning Tree Table 2.62 Descriptions of Bridge MSTI Priorities Configuration of Spanning Tree Label...

  • Page 93: Figure 2.76 Webpage To Configure Cist Ports Of Spanning Tree

    Industrial Managed User Manual Ethernet Switch – EH9711 Figure 2.76 Webpage to Configure CIST Ports of Spanning Tree Table 2.63 Descriptions of CIST Ports Configuration of Spanning Tree Label Description Factory Default CIST Aggregated Port Configuration The switch port number of the logical STP port. Port STP Enabled Controls whether STP is enabled on this switch port.
  • Page 94 Industrial Managed User Manual Ethernet Switch – EH9711 Label Description Factory Default region, possibly because those bridges are not under the full control of the administrator or the physical link state of the attached LANs transits frequently. If enabled, causes the port to disable itself upon receiving valid BPDU's. Contrary to the similar bridge setting, the port Edge status does not affect this setting.

  • Page 95: Msti Ports

    Industrial Managed User Manual Ethernet Switch – EH9711 2.7.5 MSTI Ports The MSTI Ports webpage as shown in Figure 2.77 allows the user to inspect and/or change the current STP MSTI port configurations. An MSTI port is a virtual port, which is instantiated separately for each active CIST (physical) port for each MSTI instance configured on and applicable to the port.

  • Page 96: Ipmc

    Industrial Managed User Manual Ethernet Switch – EH9711 as forwarding ports in favour of higher path cost ports. Valid values are in the range 1 to 200000000. Controls the port priority. This can be used to control priority of ports Priority having identical port cost.

  • Page 97: Figure 2.80 Basic Configuration Webpage To Igmp Snooping Of An Ipmc Profile

    Industrial Managed User Manual Ethernet Switch – EH9711 Figure 2.80 Basic Configuration Webpage to IGMP Snooping of an IPMC Profile Table 2.65 Descriptions of IGMP Snooping of an IPMC Profile Label Description Factory Default IGMP Snooping Configuration Snooping Enabled Enable the Global IGMP Snooping. Clicked Enable unregistered IPMCv4 traffic flooding.

  • Page 98: Figure 2.81 Webpage To Configure Igmp Snooping's Vlan For An Ipmc Profile

    Industrial Managed User Manual Ethernet Switch – EH9711 2.8.1.2 VLAN Configuration IGMP Snooping VLAN Configuration is shown in Figure 2.81. Note that the user needs to enter IP configuration page (SystemIPAdd IP interface) to setup IP interface first before the creation of IGMP VLAN interface. The IGMP Snooping VLAN table is also displayed on this webpage.

  • Page 99: Mld Snooping

    Industrial Managed User Manual Ethernet Switch – EH9711 Label Description Factory Default Count. The allowed range is 0 to 31744 in tenths of seconds, default last member query interval is 10 in tenths of seconds (1 second). Unsolicited Report Interval. The Unsolicited Report Interval is the time between URI (sec) repetitions of a host's initial report of membership in a group.

  • Page 100: Figure 2.83 Webpage To Configure Mld Snooping's Vlan For An Ipmc Profile

    Industrial Managed User Manual Ethernet Switch – EH9711 Label Description Factory Default MLD Snooping Configuration SSM (Source-Specific Multicast) Range allows the SSM-aware hosts and routers run the SSM service model for the groups in the address range. MLD SSM Range ff3e::/96 Assign valid IPv6 multicast address as prefix with a prefix length (from 8 to 128) for the range.

  • Page 101: Lldp

    Industrial Managed User Manual Ethernet Switch – EH9711 Table 2.68 Descriptions of MLD Snooping’s VLAN Configuration for an IPMC Profile Label Description Factory Default VLAN ID The VLAN ID of the entry. MLD Snooping Unclicked Enable the per-VLAN MLD Snooping. Up to 8 VLANs can be selected for MLD Snooping. Enabled Querier Clicked...

  • Page 102: Lldp

    Industrial Managed User Manual Ethernet Switch – EH9711 2.9.1 LLDP The LLDP webpage allows the user to inspect and configure the current LLDP interface settings as shown in Figure 2.84. The page consists of LLDP Parameters and LLDP Interface Configuration. Table 2.69 summarizes the descriptions of the LLDP Configuration.

  • Page 103: 2.10 Synce

    Industrial Managed User Manual Ethernet Switch – EH9711 Label Description Factory Default Select LLDP mode. Rx only The switch will not send out LLDP information, but LLDP information from neighbour units is analysed. Tx only The switch will drop LLDP information received from neighbours, but will Mode send out LLDP information.

  • Page 104: Figure 2.85 Webpage To Configure Synce

    Industrial Managed User Manual Ethernet Switch – EH9711 Network elements use synchronization status messages (SSM) to inform the neighbouring elements about the quality level (QL) of the clock. SSM is used by non-Ethernet interfaces, such as the optical interfaces and the SONET/T1/E1 SPA framers. SSM functionality provides the following key benefits.

  • Page 105: Table 2.70 Description Of Clock Source Nomination And State Under Synce

    Industrial Managed User Manual Ethernet Switch – EH9711 Table 2.70 Description of Clock Source Nomination and State under SyncE Label Description Factory Default This is the instance number of the clock source. This has to be referenced when selecting Clock Source 'Manual' Mode When a clock source is nominated, the clock output from the related PHY (Port) is enabled against the clock controller.

  • Page 106: Table 2.72 Description Of Station Clock Configuration Under Synce

    Industrial Managed User Manual Ethernet Switch – EH9711 Label Description Factory Default Force Free Run: Clock Selector is forced to Free Run State. Source Only relevant if Manual mode is selected (see above). WTR is the Wait-To-Restore timer value in minutes. The WTR time is activated on the WTR Time falling edge of a clock source failure (in Revertive mode).

  • Page 107: 2.11 Mac Table

    Industrial Managed User Manual Ethernet Switch – EH9711 Label Description Monitoring of the received SSM QL on this port. If link is down on port, QL_LINK is indicated. If no SSM is Rx SSM received, QL_FAIL is indicated. PSFP is an acronym for Per Stream Filtering and Policing. PSFP functions allow filtering and policing decisions, and subsequent frame queuing decisions on a per-stream PTSF basis.

  • Page 108: 2.12 Vlans

    Industrial Managed User Manual Ethernet Switch – EH9711 Label Description Factory Default Learning is done automatically as soon as a frame with unknown Auto SMAC is received. Disable No learning is done. Only static MAC entries are learned, all other frames are dropped.

  • Page 109: Configuration

    Industrial Managed User Manual Ethernet Switch – EH9711 Figure 2.87 Example of VLAN Configuration 2.12.1 Configuration VLANConfiguration webpage allows the user to control VLAN configuration on the switch. The page is divided into a global section and a per-port configuration section as shown in Figure 2.88.

  • Page 110: Table 2.76 Description Of Global Vlan Configuration

    Industrial Managed User Manual Ethernet Switch – EH9711 Table 2.76 Description of Global VLAN Configuration Label Description Factory Default This field shows the allowed Access VLANs, i.e. it only affects ports configured as Access ports. Ports in other modes are members of the VLANs specified in the Allowed VLANs field.
  • Page 111 Industrial Managed User Manual Ethernet Switch – EH9711 Label Description Factory Default On egress, frames classified to the Port VLAN do not get tagged if Egress Tagging configuration is set to untagged Port VLAN. The Port VLAN is called an "Access VLAN" for ports in Access mode and Native VLAN for ports in Trunk or Hybrid mode.

  • Page 112: Svl

    Industrial Managed User Manual Ethernet Switch – EH9711 Label Description Factory Default of are accepted and forwarded to the switch engine. However, the port will never transmit frames classified to VLANs that it is not a member of. Hybrid ports allow for changing the type of frames that are accepted on ingress. Tagged and Untagged Both tagged and untagged frames are accepted.

  • Page 113: Figure 2.89 Webpage To Svl Configuration

    Industrial Managed User Manual Ethernet Switch – EH9711 Figure 2.89 Webpage to SVL Configuration Table 2.78 Description of Shared VLAN Learning Configuration Label Description Factory Default A previously allocated FID can be deleted by the use of this button. Delete The Filter ID (FID) is the ID that VLANs get learned on in the MAC table when SVL is in effect.

  • Page 114: 2.13 Vcl

    Industrial Managed User Manual Ethernet Switch – EH9711 2.13 VCL 2.13.1 MAC-based VLAN The MAC address to VLAN ID mappings can be configured in Figure 2.90. This page allows adding and deleting MAC- based VLAN Classification List entries and assigning the entries to different ports. Figure 2.77 summarizes the descriptions of MAC-based VLAN Membership Configuration.

  • Page 115: Figure 2.91 Webpage To Configure Protocol To Group Mapping Table

    Industrial Managed User Manual Ethernet Switch – EH9711 Figure 2.91 Webpage to Configure Protocol to Group Mapping Table Table 2.80 Descriptions of Protocol to Group Mapping Table Configuration Label Description Factory Default Delete To delete a Protocol to Group Name map entry, check this box. The entry will be deleted from the switch during the next Save.

  • Page 116: Ip Subnet-Based Vlan

    Industrial Managed User Manual Ethernet Switch – EH9711 2.13.2.2 Group to VLAN This page allows the user to map a Group Name, which is already configured or going to be configured in the future, to a VLAN for the managed switch. Figure 2.92 shows the Group Name to VLAN mapping Table. Description of each column’s label can be found in Table 2.81.

  • Page 117: 2.14 Qos

    Industrial Managed User Manual Ethernet Switch – EH9711 Figure 2.93 Webpage to Configure IP Subnet-based VLAN of VCL Table 2.82 Descriptions of IP Subnet-based VLAN Configuration Label Description Factory Default To delete a mapping, check this box and press save. The entry will be deleted in the Delete stack.

  • Page 118: Figure 2.94 Webpage To Configure Port Classification Of Qos

    Industrial Managed User Manual Ethernet Switch – EH9711 Figure 2.94 Webpage to Configure Port Classification of QoS Table 2.83 Descriptions of Port Classification Configuration of QoS Label Description Factory Default Port The port number for which the configuration below applies. Controls the default class of service (CoS) value.

  • Page 119: Port Policing

    Industrial Managed User Manual Ethernet Switch – EH9711 Label Description Factory Default Click to Enable Differentiated Services Code Point (DSCP) Based QoS Ingress Port Unclicked DSCP Based Classification. It is a field in the header of IP packets for packet classification purposes. The key type specifying the key generated for frames received on the port.

  • Page 120: Queue Policing

    Industrial Managed User Manual Ethernet Switch – EH9711 Label Description Factory Default Controls the rate for the port policer. This value is restricted to 100-3276700 when Rate "Unit" is kbps or fps, and 1-3276 when "Unit" is Mbps or kfps. The rate is internally rounded up to the nearest value supported by the port policer.

  • Page 121: Port Scheduler

    Industrial Managed User Manual Ethernet Switch – EH9711 2.14.4 Port Scheduler This webpage provides an overview of QoS Egress Port Schedulers for all switch ports as shown in Figure 2.97. Table 2.86 describes the labels in the QoS Egress Port Schedulers. Figure 2.97 Webpage to Configure Port Scheduler of QoS Table 2.86 Descriptions of Port Scheduler Configuration of QoS Label...

  • Page 122: Figure 2.98 Webpage To Configure Qos Egress Port Scheduler And Shapers Port

    Industrial Managed User Manual Ethernet Switch – EH9711 Figure 2.98 Webpage to Configure QoS Egress Port Scheduler and Shapers Port Table 2.87 Descriptions of QoS Egress Port Scheduler and Shapers Port Configuration Label Description Factory Default Scheduler Mode Controls how many of the queues are scheduled as strict and how many Strict are scheduled as weighted on this switch port.

  • Page 123: Port Shaping

    Industrial Managed User Manual Ethernet Switch – EH9711 Rate Controls the rate for the port shaper. This value is restricted to 100-3281943 when "Unit" is kbps, and 1-3281 when "Unit" is Mbps. The rate is internally rounded up to the nearest value supported by the port shaper.

  • Page 124: Figure 2.100 Webpage To Detailed Configure Qos Egress Port Scheduler And Shapers Port

    Industrial Managed User Manual Ethernet Switch – EH9711 Figure 2.100 Webpage to Detailed Configure QoS Egress Port Scheduler and Shapers Port Table 2.89 Descriptions of Detaled QoS Egress Port Scheduler and Shapers Port Configuration Label Description Factory Default Scheduler Mode Controls how many of the queues are scheduled as strict and how Strict many are scheduled as weighted on this switch port.

  • Page 125: Port Tag Remarking

    Industrial Managed User Manual Ethernet Switch – EH9711 Enable Controls whether the port shaper is enabled for this switch port. Unclicked Rate Controls the rate for the port shaper. This value is restricted to 100- 3281943 when "Unit" is kbps, and 1-3281 when "Unit" is Mbps. The rate is internally rounded up to the nearest value supported by the port shaper.

  • Page 126: Port Dscp

    Industrial Managed User Manual Ethernet Switch – EH9711 Figure 2.102 Webpage to Configure Each Port Tag Remarking of QoS Table 2.91 Descriptions for Port Tag Remarking Configuration of Mode Label Description Mode Controls the tag remarking mode for this port. Classified Use classified PCP/DEI values.

  • Page 127: Dscp-Based Qos

    Industrial Managed User Manual Ethernet Switch – EH9711 Label Description Factory Default • DSCP=0: Classify if incoming (or translated if enabled) DSCP is 0. • Selected: Classify only selected DSCP for which classification is enabled as specified in DSCP Translation window for the specific DSCP. •...

  • Page 128: Figure 2.104 Webpage To Configure Dscp-Based Of Qos

    Industrial Managed User Manual Ethernet Switch – EH9711 Figure 2.104 Webpage to Configure DSCP-Based of QoS Table 2.93 Descriptions of DSCP-Based Configuration of QoS Label Description Factory Default Maximum number of supported DSCP values is 64. DSCP Trust Controls whether a specific DSCP value is trusted. Only frames with trusted DSCP values are mapped to a specific QoS class and Drop Unchecked Precedence Level (DPL).

  • Page 129: Dscp Translation

    Industrial Managed User Manual Ethernet Switch – EH9711 2.14.9 DSCP Translation DSCP Translation webpage as shown in Figure 2.105 allows you to configure the basic QoS DSCP Translation settings for the managed switch. DSCP translation can be done in Ingress or Egress. Table 2.94 describes the setting options for DSCP Translation.

  • Page 130: 2.14.10 Dscp Classification

    Industrial Managed User Manual Ethernet Switch – EH9711 2.14.10 DSCP Classification The DSCP Classification webpage as shown in Figure 2.106 allows you to configure the mapping of Class of Service (CoS) or QoS Class and Drop Precedence Level (DPL) to DSCP value. Table 2.95 explains the options for DSCP Classification. Figure 2.106 Webpage to Configure DSCP Classification of QoS Table 2.95 Descriptions of DSCP Classification Configuration of QoS Label...

  • Page 131: Figure 2.107 Webpage To Configure Qos Control List

    Industrial Managed User Manual Ethernet Switch – EH9711 Figure 2.107 Webpage to Configure QoS Control List Table 2.96 Descriptions of QoS Control List Configuration Label Description Factory Default Indicates the QCE id. Indicates the list of ports configured with the QCE or 'Any'. Port DMAC Indicates the destination MAC address.

  • Page 132: Figure 2.108 Adding New Qce Configuration

    Industrial Managed User Manual Ethernet Switch – EH9711 Label Description Factory Default Possible actions are: CoS: Classify Class of Service. DPL: Classify Drop Precedence Level. DSCP: Classify DSCP value. PCP: Classify PCP value. DEI: Classify DEI value. Policy: Classify ACL Policy number. The user can modify each QCE (QoS Control Entry) in the table using the following buttons: : Inserts a new QCE before the current row.

  • Page 133: Table 2.97 Description Of Frame Type

    Industrial Managed User Manual Ethernet Switch – EH9711 Label Description Factory Default Tag Value of Tag field can be 'Untagged', 'Tagged', 'C-Tagged', 'S-Tagged' or 'Any'. VID Valid value of VLAN ID can be any value in the range 1-4095 or 'Any'; user can enter either a specific value or a range of VIDs.

  • Page 134: 2.14.12 Storm Policing

    Industrial Managed User Manual Ethernet Switch – EH9711 Frame Type Description UDP/TCP. Dport Destination TCP/UDP port:(0-65535) or 'Any', specific or port range applicable for IP protocol UDP/TCP. Click Save button to save the configuration and move to main QCL page. Click Reset button to undo any changes made locally and revert to previously saved values.

  • Page 135: Figure 2.110 Traffic Mirroring Operation

    Industrial Managed User Manual Ethernet Switch – EH9711 network traffic can be analysed by a network analyser or a sniffer for network performance or security monitoring purposes. Figure 2.111 shows the Mirror Port webpage. The descriptions of port mirroring options are summarized in Table 2.100. Port mirroring or traffic mirroring enables users to monitor network traffic passing in, or out of, a set of ports.

  • Page 136: Figure 2.111 Webpage To Configure Mirroring

    Industrial Managed User Manual Ethernet Switch – EH9711 Figure 2.111 Webpage to Configure Mirroring Table 2.100 Descriptions of Mirroring Webpage Label Description Factory Default Session ID Display Mirror feature session id. Mode To Enabled/Disabled the Mirroring function. Disabled Display switch mirroring type. Mirror Type Mirror: The switch is running on mirror mode.

  • Page 137: 2.16 Ptp

    Industrial Managed User Manual Ethernet Switch – EH9711 Figure 2.112 Webpage to Detailed Configure Mirroring for Session ID 2.16 PTP Precision Time Protocol (PTP) is defined in IEEE 1588 as Precision Clock Synchronization for Networked Measurements and Control Systems, and was developed to synchronize the clocks in packet-based networks that include distributed device clocks of varying precision and stability.

  • Page 138: Figure 2.113 Webpage To Configure Ptp

    Industrial Managed User Manual Ethernet Switch – EH9711 They are broadly categorized into ordinary clocks and boundary clocks. The primary clock and the client clock are known as ordinary clocks. The boundary clock can operate as either a primary clock or a client clock. The following list explains these clocks in detail: ...

  • Page 139: 2.17 Gvrp

    Industrial Managed User Manual Ethernet Switch – EH9711 Table 2.101 Descriptions of PTP Clock Configuration Label Description Factory Default Check this box and click on 'Save' button to delete the clock instance. Delete Clock Instance Indicates the Instance of a particular Clock Instance [0…3]. Click on the Clock Instance number to edit the Clock details.

  • Page 140: Global Config

    Industrial Managed User Manual Ethernet Switch – EH9711 GVRP can be used to keep VLAN configurations on trunk interfaces organized across the network on large networks that consist of dozens or even hundreds of VLAN segments. There are three benefits for administrators that enable GVRP on a network: ...

  • Page 141: Port Config

    Industrial Managed User Manual Ethernet Switch – EH9711 Click Save button to save the setting configuration. Click Refresh box to refresh the page immediately. Note that unsaved changes will be lost. 2.17.2 Port config The GVRP Port Config webpage shown in Figure 2.116 allows the user to enable or disable a port for GVRP operation. This configuration can be performed either before or after GVRP is configured globally;...

  • Page 142: 2.19 Udld

    Industrial Managed User Manual Ethernet Switch – EH9711 Figure 2.117 Webpage to Configure DDMI Table 2.105 Descriptions of DDMI Configuration Label Description Factory Default Mode Indicates the DDMI mode operation. Possible modes are: Enabled: Enable DDMI mode operation. Disabled Disabled: Disable DDMI mode operation. Click Save button to save changes.
  • Page 143 Industrial Managed User Manual Ethernet Switch – EH9711 be bi-directional and the UDLD information times out while the link on the port is still up, UDLD tries to re-establish the state of the port. If not successful, the port is put into the errdisable state. Aging of UDLD information happens when the port that runs UDLD does not receive UDLD packets from the neighbor port for duration of hold time.

  • Page 144: 2.20 Sd Backup

    Industrial Managed User Manual Ethernet Switch – EH9711 Figure 2.118 Webpage to Configure UDLD Table 2.106 Descriptions of UDLD Port Configuration Label Description Factory Default Port Port number of the switch. 1-11 UDLD Mode Configures the UDLD mode on a port. Valid values are Disable, Normal and Aggressive.

  • Page 145: 2.21 Modbus Setting

    2.21 Modbus Setting Atop’s managed switch can be connected to a Modbus network using Modbus TCP/IP protocol which is an industrial network protocol for controlling automation equipment. The managed switch’s status and settings can be read and written through Modbus TCP/IP protocol which operates similar to a Management Information Base (MIB) browser.

  • Page 146: Figure 2.120 Webpage To Configure Modbus Setting

    The Modbus Poll 64-bit version 9.2.2, Build 1343 was used in this document. Atop does not provide this software to the users. Tutorial of Modbus read and write examples are illustrated below. Note: The switch only supports Modbus function code 03, 04 (for Read) and 06 (for Write).
  • Page 147 Industrial Managed User Manual Ethernet Switch – EH9711 Click Connect button on the top toolbar to enter Connection Setup dialog by selecting Connect… menu as shown in Figure 2.120 Figure 2.120 Entering Connection Setup Menu of the Modbus Poll 4. Select Modbus TCP/IP as the Connection mode and enter the switch’s IP address inside the Remote Modbus Server’s IP Address or Node Name field at the bottom as shown in Figure 2.121.
  • Page 148 Industrial Managed User Manual Ethernet Switch – EH9711 Figure 2.122 Multiple Cell Section in Modbus Poll Set Display mode of the selected cells in previous step to HEX (hexadecimal) by selecting Display pull-down menu and choosing the Hex as shown in Figure 2.123. Figure 2.123 Set Display Mode to Hex in Modbus Poll Click on the Setup pull-down menu and choose Read/Write Definition…...
  • Page 149 Industrial Managed User Manual Ethernet Switch – EH9711 Figure 2.124 Modbus Poll Setup Read/Write Definition Enter the Slave ID in the Modbus Poll function as shown in Figure 2.125, which should match the Modbus Address = 1 entered in Figure 2.118. Figure 2.125 Slave ID in the Modbus Poll Function is set to 1 Select Function 03 or 04 because the managed switch supports function code 03 and 04 as shown in Figure 2.126.
  • Page 150 Industrial Managed User Manual Ethernet Switch – EH9711 Figure 2.126 Set Code 03 in the Modbus Poll Function 10. Set starting Address to 81 and Quantity to 2 as shown in Figure 2.127. Figure 2.127 Setup Starting Address and Quantity in Modbus Poll 11.
  • Page 151 Industrial Managed User Manual Ethernet Switch – EH9711 Figure 2.128 Modbus Memory Address 81 and 82 are the location of EH9711's IP Address 12. Modbus Poll will get the values 0x0A, 0x00, 0x32, 0x01, which means that the switch’s IP is 10.0.50.1 as shown in Figure 2.128.
  • Page 152 Industrial Managed User Manual Ethernet Switch – EH9711 Click function 06 on the toolbar as shown in Figure 2.131. Figure 2.131 Click on Function 06 in the Modbus Poll Set Address to 256 and Value (HEX) to 1 as shown in Figure 2.132, then click “Send” button. Figure 2.132 Use Modbus Poll to Clear Switch's Port Count Check Port Statistics in the managed switch’s Web UI as shown in Figure 2.133.

  • Page 153: 2.22 Modbus Memory Map

    Industrial Managed User Manual Ethernet Switch – EH9711 2.22 Modbus Memory Map 1. Read Registers (Support Function Code 3, 4). 2. Write Register (Support Function Code 6). 3. 1 Word = 2 Bytes. Address Data Type Read/Write Description System Information 0x0000 (0) 32 words System Description = "Managed Switch EH9711"...
  • Page 154 Industrial Managed User Manual Ethernet Switch – EH9711 Console Information 0x0030 (48) 1 word Baud Rate 0x0000: 4800 0x0001: 9600 0x0002: 14400 0x0003: 19200 0x0004: 28800 0x0005: 38400 0x0006: 57600 0x0007: 144000 0x0008: 115200 0x0031 (49) 1 word Data Bits 0x0007: 7 0x0008: 8 0x0032 (50)
  • Page 155 Industrial Managed User Manual Ethernet Switch – EH9711 0x0055 (85) 2 words Gateway Address of switch Ex: IP = 192.168.1.254 Word 0 Hi byte = 0xC0 Word 0 Lo byte = 0xA8 Word 1 Hi byte = 0x01 Word 1 Lo byte = 0xFE 0x0057 (87) 2 words DNS1 of switch...
  • Page 156 Industrial Managed User Manual Ethernet Switch – EH9711 0x1020 (4128) 5 words Port Negotiation Status, force = 0x00 Status, auto = 0x01 Word 0 Hi byte = Port 1 Status Word 0 Lo byte = Port 2 Status Word 1 Hi byte = Port 3 Status Word 1 Lo byte = Port 4 Status Word 2 Hi byte = Port 5 Status Word 2 Lo byte = Port 6 Status...
  • Page 157 Industrial Managed User Manual Ethernet Switch – EH9711 0x10A0 (4256) 5 words Port Link Status Status, down = 0x00 Status, up = 0x01 Word 0 Hi byte = Port 1 Status Word 0 Lo byte = Port 2 Status Word 1 Hi byte = Port 3 Status Word 1 Lo byte = Port 4 Status Word 2 Hi byte = Port 5 Status Word 2 Lo byte = Port 6 Status...
  • Page 158 Industrial Managed User Manual Ethernet Switch – EH9711 Word 4,5,6,7 = Port 2 good packets Word 8,9,10,11 = Port 3 good packets Word 12,13,14,15 = Port 4 good packets Word 16,17,18,19 = Port 5 good packets Word 20,21,22,23 = Port 6 good packets Word 24,25,26,27 = Port 7 good packets Word 28,29,30,31 = Port 8 good packets Word 32,33,34,35 = Port 9 good packets...

  • Page 159: Monitor

    3 Monitor The Atop’s EH9711 managed switch has an extensive set of status monitoring features on the WebUI. The user can select the submenus under the Monitor menu to check for the information or current status of the operations and protocols running on the Atop’s EH9711 managed switch.

  • Page 160: Cpu Load

    Industrial Managed User Manual Ethernet Switch – EH9711 Check the Auto-refresh box to refresh the page automatically. The automatic refresh occurs every 3 seconds. Otherwise, click Refresh box to refresh the page immediately. After Clicking Licenses, users will be directed to the summary of software license as shown in Figure 3.2. Figure 3.2 Summary of Software License 3.1.2 CPU Load...

  • Page 161: Ipv4 Routing Info. Base

    Industrial Managed User Manual Ethernet Switch – EH9711 Figure 3.4 Webpage to Monitor System’s IP Status Table 3.2 Monitor Descriptions of System’s IP Status Label Description Factory Default IP Interfaces The name of the interface. VLAN 1 Interface Type The address type of the entry. This may be LINK, IPv4 or IPv6. LINK, IPv4, IPv6 DUT’s MAC address/ IPv4 The current address of the interface (of the given type).

  • Page 162: Ipv6 Routing Info. Base

    Industrial Managed User Manual Ethernet Switch – EH9711 Figure 3.5 Webpage to Monitor System’s IPv4 Routing Information Base Table 3.3 Monitoring Descriptions of System’s IPv4 Routing Information Base Label Description Protocol The protocol that installed this route. DHCP: The route is created by DHCP. Connected: The destination network is connected directly.

  • Page 163: Log

    Industrial Managed User Manual Ethernet Switch – EH9711 Figure 3.6 Webpage to Monitor System’s IPv6 Routing Information Base Table 3.4 Monitoring Descriptions of System’s IPv6 Routing Information Base Label Description Protocol The protocol that installed this route. DHCP: The route is created by DHCP. Connected: The destination network is connected directly.

  • Page 164: Detailed Log

    Industrial Managed User Manual Ethernet Switch – EH9711 Figure 3.7 Webpage to Monitor System Log Table 3.5 Monitoring Descriptions of System Log Label Description The identification of the system log entry. The level of the system log entry. Level Informational: The system log entry is belonged information level. Warning: The system log entry is belonged warning level.

  • Page 165: Power Status

    Industrial Managed User Manual Ethernet Switch – EH9711 Table 3.6 Monitoring Descriptions of System Detailed Log Label Description The severity level of the system log entry. Level Informational: The system log entry is belonged information level. Warning: The system log entry is belonged warning level. Error: The system log entry is belonged error level.

  • Page 166: Traffic Overview

    Industrial Managed User Manual Ethernet Switch – EH9711 Figure 3.11 Webpage to Monitor Port State Check the Auto-refresh box to refresh the page automatically. Automatic refresh occurs every 3 seconds. Click Refresh button to refresh the page immediately. 3.2.2 Traffic Overview This Traffic Overview webpage provides an overview of general traffic statistics for all ports of managed switch as shown in Figure 3.12.

  • Page 167: Qos Statistics

    Industrial Managed User Manual Ethernet Switch – EH9711 3.2.3 QoS Statistics QoS Statistics webpage in Figure 3.13 provides statistics for different queues on all managed switch’s ports. The labels of the Queueing Counters are described in Table 3.8. Figure 3.13 Webpage to Monitor Queuing Counters Table 3.8 Monitoring Descriptions of Queuing Counters Label Description...

  • Page 168: Detailed Statistics

    Industrial Managed User Manual Ethernet Switch – EH9711 SNAP: Match (SNAP) frames. IPv4: Match IPv4 frames. IPv6: Match IPv6 frames. Action Indicates the classification action taken on ingress frame if parameters configured are matched with the frame's content. Possible actions are: CoS: Classify Class of Service.

  • Page 169: Name Map

    Industrial Managed User Manual Ethernet Switch – EH9711 Table 3.10 Monitoring Descriptions of Detailed Port Statistics Label Description Receive Total and Transmit Total Rx and Tx Packets The number of received and transmitted (good and bad) packets. The number of received and transmitted (good and bad) bytes. Includes FCS, but excludes Rx and Tx Octets framing bits.

  • Page 170: Erps

    Industrial Managed User Manual Ethernet Switch – EH9711 ERPS ERPS is an abbreviation for Ethernet Ring Protection Switching defined in ITU/T G.8032. It provides fast protection and recovery switching for Ethernet traffic in a ring topology while also ensuring that the Ethernet layer remains loop-free. This ERPS webpage reports the current status of ERPS instances on the managed switch as shown in Figure 3.17.

  • Page 171: Figure 3.18 Webpage To Erps Detailed Status

    Industrial Managed User Manual Ethernet Switch – EH9711 Figure 3.18 Webpage to ERPS Detailed Status Table 3.12 Description of ERPS Detailed Status Label Description This table shows the current configuration for this ERPS instance. Go to the ERPS Configuration Configuration help page for further explanation.

  • Page 172: Dhcpv4

    Industrial Managed User Manual Ethernet Switch – EH9711 DHCPv4 3.4.1 Snooping Table This Snooping Table webpage shown in Figure 3.19 displays the dynamic IP assigned information after DHCP Snooping mode is disabled. All DHCP clients obtained the dynamic IP address from the DHCP server will be listed in this table except for local VLAN interface IP addresses.

  • Page 173: Detailed Statistics

    Industrial Managed User Manual Ethernet Switch – EH9711 Figure 3.20 Webpage to Monitor DHCP Relay Statistics Table 3.14 Monitoring Descriptions of DHCP Relay Statistics Label Description Server Statistics Transmit To Server The number of packets that are relayed from client to server. The number of packets that resulted in errors while being sent to clients.

  • Page 174: Security

    Industrial Managed User Manual Ethernet Switch – EH9711 Figure 3.21 Webpage to Monitor DHCP Server Statistics Table 3.15 Monitoring Descriptions of DHCP Detailed Statistics Port 1 Label Description The number of discover (option 53 with value 1) packets received and transmitted. Rx and Tx Discover Rx and Tx Offer The number of offer (option 53 with value 2) packets received and transmitted.

  • Page 175: Figure 3.22 Webpage To Monitor Dhcp Server Statistics

    Industrial Managed User Manual Ethernet Switch – EH9711 address to forward. If only one chooses to block it, it will be blocked until that user module decides otherwise. The status page is divided into two sections - one with a legend of user modules and one with the actual port status. Table 3.16 summarizes the descriptions of Port Security Switch Status.

  • Page 176: Figure 3.23 Webpage To Monitor Port Security Port Status All Ports

    Industrial Managed User Manual Ethernet Switch – EH9711 reached. Shut down: The Port Security service is administratively enabled and the port is shut down. No MAC addresses can be learned on the port until it is administratively re- opened by administratively taking the port down and then back up on the "Configuration→Ports"...

  • Page 177: Figure 3.24 Webpage To Monitor Network Access Server Switch Status

    Industrial Managed User Manual Ethernet Switch – EH9711 State Indicates whether the corresponding MAC address is blocked or forwarding. In the blocked state, it will not be allowed to transmit or receive traffic. If at least one user module has decided to block this MAC address, it will stay in the blocked state until Age/Hold the hold time (measured in seconds) expires.

  • Page 178: Figure 3.25 Webpage To Monitor Nas Statistics Port 1

    Industrial Managed User Manual Ethernet Switch – EH9711 Check Auto-refresh box to refresh the page automatically. Automatic refresh occurs every 3 seconds. Click Refresh button to refresh the page immediately. 3.5.1.4 NAS Port This page provides detailed NAS statistics for a specific switch port running EAPOL-based IEEE 802.1X authentication. For MAC-based ports, it shows selected backend server (RADIUS Authentication Server) statistics, only.

  • Page 179: Figure 3.26 Webpage To Monitor Acl Status

    Industrial Managed User Manual Ethernet Switch – EH9711 VLAN ID This column holds the VLAN ID that the corresponding client is currently secured through the Port Security module. The client can either be authenticated or unauthenticated. In the authenticated state, it is allowed State to forward frames on the port, and in the unauthenticated state, it is blocked.

  • Page 180: Figure 3.27 Webpage To Monitor Dynamic Arp Inspection Table

    Industrial Managed User Manual Ethernet Switch – EH9711 Counter The counter indicates the number of times the ACE was hit by a frame. Conflict Indicates the hardware status of the specific ACE. The specific ACE is not applied to the hardware due to hardware limitations.

  • Page 181: Aaa

    Industrial Managed User Manual Ethernet Switch – EH9711 point in the Dynamic IP Source Guard Table. Clicking the Refresh button will update the displayed table starting from that or the closest next Dynamic IP Source Guard Table match. In addition, the two input fields will - upon a Refresh button click - assume the value of the first displayed entry, allowing for continuous refresh with the same start address.

  • Page 182: Figure 3.30 Webpage To Monitor Each Port's Radius Server Status

    Industrial Managed User Manual Ethernet Switch – EH9711 Authentication Port UDP port number for authentication. Authentication Status The current status of the server. This field takes one of the following values: Disabled: The server is disabled. Not Ready: The server is enabled, but IP communication is not yet up and running. Ready: The server is enabled, IP communication is up and running, and the RADIUS module is ready to accept access attempts.
  • Page 183 Industrial Managed User Manual Ethernet Switch – EH9711 authentication server packet counter, there are seven receive and four transmit counters. Receive Packets The number of RADIUS Access-Accept packets (valid or invalid) Access Accepts received from the server. The number of RADIUS Access-Reject packets (valid or invalid) Access Rejects received from the server.

  • Page 184: Figure 3.31 Webpage To Monitor Radius Authentication And Accounting Statistics

    Industrial Managed User Manual Ethernet Switch – EH9711 Figure 3.31 Webpage to Monitor RADIUS Authentication and Accounting Statistics Table 3.25 Monitoring Descriptions of RADIUS Authentication and Accounting Statistics Label Description RADIUS Authentication Statistics for Server#1 RADIUS Authentication Statistics map closely to those specified in RFC4668 – RADIUS Authentication Client MIB.

  • Page 185: Switch

    Industrial Managed User Manual Ethernet Switch – EH9711 Access Retransmission The number of RADIUS Access-Request packets retransmitted to the RADIUS authentication server. The number of RADIUS Access-Request packets destined for the Pending Requests server that have not yet timed out or received a response. This variable is incremented when an Access-Request is sent and decremented due to receipt of an Access-Accept, Access-Reject, Access-Challenge, timeout, or retransmission.

  • Page 186: Figure 3.32 Webpage To Monitor Rmon Statistics Status Overview

    Industrial Managed User Manual Ethernet Switch – EH9711 Figure 3.32 Webpage to Monitor RMON Statistics Status Overview Table 3.26 Monitoring Descriptions of RMON Statistics Status Overview Label Description Indicates the index of Statistics entry. The port ID which wants to be monitored. Data Source(ifIndex) The total number of events in which packets were dropped by the probe due to lack of resources.

  • Page 187: Figure 3.33 Webpage To Monitor Rmon History Overview

    Industrial Managed User Manual Ethernet Switch – EH9711 match. The will use the last entry of the currently displayed entry as a basis for the next lookup. When the end is reached the text "No more entries" is shown in the displayed table. Use the button to start over.

  • Page 188: Figure 3.34 Webpage To Monitor Rmon Alarm Overview

    Industrial Managed User Manual Ethernet Switch – EH9711 Figure 3.34 Webpage to Monitor RMON Alarm Overview Table 3.28 Monitoring Descriptions of RMON Alarm Overview Label Description Check to delete the entry. It will be deleted during the next save. Delete Indicates the index of the entry.

  • Page 189: Aggregation

    Industrial Managed User Manual Ethernet Switch – EH9711 Figure 3.35 Webpage to Monitor RMON Event Table 3.29 Monitoring Descriptions of RMON Event Label Description Event Index Indicates the index of the event entry. Indicates the index of the log entry. Log Index LogTime Indicates Event log time...

  • Page 190: Lacp

    Industrial Managed User Manual Ethernet Switch – EH9711 3.6.2 LACP 3.6.2.1 System Status This page provides a status overview for all LACP instances. LACP is an IEEE 802.3ad standard protocol. The Link Aggregation Control Protocol, allows bundling several physical ports together to form a single logical port. Figure 3.37 Webpage to Monitor LACP System Status Table 3.31 Monitoring Descriptions of LACP System Status Label...

  • Page 191: Figure 3.39 Webpage To Monitor Lacp Neighbour Port Status

    Industrial Managed User Manual Ethernet Switch – EH9711  Standby: The port is in standby state. The key assigned to this port. Only ports with the same key can aggregate together. The priority assigned to this aggregation group. Priority Activity The LACP mode of the group (Active or Passive).

  • Page 192: Spanning Tree

    Industrial Managed User Manual Ethernet Switch – EH9711 Collecting Show if collection of incoming frames on this link is enabled. Distributing Show if distribution of outgoing frames on this link is enabled. Show if the partners Receive machine is using Defaulted operational Partner Defaulted information.

  • Page 193: Port Status

    Industrial Managed User Manual Ethernet Switch – EH9711 Table 3.35 Monitoring Descriptions of STP Bridges Label Description Bridge ID The Bridge ID of this Bridge instance. Root ID The Bridge ID of the currently elected root bridge. The switch port currently assigned the root port role. Root Port Root Cost Root Path Cost.

  • Page 194: Ipmc

    Industrial Managed User Manual Ethernet Switch – EH9711 Figure 3.43 Webpage to Monitor STP Statistics Table 3.37 Monitoring Descriptions of STP Statistics Label Description The switch port number of the logical STP port. Port Transmitted/Received MSTP The number of MSTP BPDU's received/transmitted on the port. Transmitted/Received RSTP The number of RSTP BPDU's received/transmitted on the port.

  • Page 195: Figure 3.45 Webpage To Monitor Dhcp Server Statistics

    Industrial Managed User Manual Ethernet Switch – EH9711 Figure 3.45 Webpage to Monitor DHCP Server Statistics Table 3.38 Descriptions of DHCP Server Statistics Monitoring Label Description Statistics The VLAN ID of the entry. VLAN ID Querier Version Working Querier Version currently. Host Version Working Host Version currently.

  • Page 196: Figure 3.46 Webpage To Monitor Igmp Snooping Group Information

    Industrial Managed User Manual Ethernet Switch – EH9711 for the next lookup. When the end is reached the text "No more entries" is shown in the displayed table. Use the button to start over. Figure 3.46 Webpage to Monitor IGMP Snooping Group Information Table 3.39 Monitoring Descriptions of IGMP Snooping Group Information Label Description...

  • Page 197: Mld Snooping

    Industrial Managed User Manual Ethernet Switch – EH9711 Table 3.40 Monitoring Descriptions IGMP SFM Information Label Description VLAN ID VLAN ID of the group. Group Group address of the group displayed. Switch port number. Port Mode Indicates the filtering mode maintained per (VLAN ID, port number, Group Address) basis.

  • Page 198: Figure 3.49 Webpage To Monitor Mld Snooping Group Information

    Industrial Managed User Manual Ethernet Switch – EH9711 V2 Reports Received The number of Received V2 Reports. V1 Leaves Received V1 Leaves Received The number of Received V1 Leaves. Router Port: Display which ports act as router ports. A router port is a port on the Ethernet switch that leads towards the Layer 3 multicast device or MLD querier.

  • Page 199: Lldp

    Industrial Managed User Manual Ethernet Switch – EH9711 Figure 3.50 Webpage to Monitor Table 3.43 Monitoring Descriptions of MLD SFM Information Label Description VLAN ID of the group. VLAN ID Group Group address of the group displayed. Port Switch port number. Indicates the filtering mode maintained per (VLAN ID, port number, Group Address) Mode basis.

  • Page 200: Port Statistics

    Industrial Managed User Manual Ethernet Switch – EH9711 System Capabilities Describes the neighbour unit's capabilities. The possible capabilities are: 1. Other 2. Repeater 3. Bridge 4. WLAN Access Point 5. Router 6. Telephone 7. DOCSIS cable device 8. Station only 9. Reserved When a capability is enabled, the capability is followed by (+).

  • Page 201: Ptp

    Industrial Managed User Manual Ethernet Switch – EH9711 Rx Errors The number of received LLDP frames containing some kind of error. Frames Discarded If a LLDP frame is received on an interface, and the switch's internal table has run full, the LLDP frame is counted and discarded. This situation is known as "Too Many Neighbours"...

  • Page 202: 802.1As Statistics

    Industrial Managed User Manual Ethernet Switch – EH9711 Table 3.46 Monitoring Descriptions of PTP External Clock Mode and Clock Configuration Label Description PTP Clock Configuration Inst Indicates the Instance of a particular Clock Instance [0..3]. Click on the Clock Instance number to monitor the Clock details.

  • Page 203: 3.11 Mac Table

    Industrial Managed User Manual Ethernet Switch – EH9711 PdelayResponseFollowUpCount A counter that increments every time a Pdelay_Resp_Follow_Up message is transmitted. A counter that increments every time an Announce message is AnnounceCount transmitted. A counter that increments every time when a PTP message is discarded. PTPPacketDiscardCount A counter that increments every time when sync receipt timeout occurs.

  • Page 204: Ports

    Industrial Managed User Manual Ethernet Switch – EH9711 The following describes how to navigate the VLAN Membership Status page. Each page shows up to 99 entries from the VLAN table (default being 20), selected through the "entries per page" input field. When first visited, the web page will show the first 20 entries from the beginning of the VLAN Table.

  • Page 205: Figure 3.58 Webpage To Monitor Vlan Port Status For Combined Users

    Industrial Managed User Manual Ethernet Switch – EH9711 Figure 3.57 Webpage to Monitor VLAN Port Status for Combined Users Table 3.50 Monitoring Descriptions of VLAN Port Status for Combined Users Label Description VLAN User Various internal software modules may use VLAN services to configure VLAN port configuration on the fly.

  • Page 206: 3.13 Ddmi

    Industrial Managed User Manual Ethernet Switch – EH9711 Click Buttons to select VLAN Users from this drop-down list. Check the Auto-refresh box to refresh the page automatically. Automatic refresh occurs every 3 seconds. Click Refresh button to refresh the page immediately 3.13 DDMI 3.13.1 Overview...

  • Page 207: 3.14 Udld

    Industrial Managed User Manual Ethernet Switch – EH9711 Figure 3.59 Webpage to Monitor DDMI Detailed Table 3.52 Monitoring Descriptions of DDMI Detailed Label Description Transceiver Information Vendor Indicates SFP vendor name. Indicates part number provided by SFP vendor. Part Number Indicates serial number provided by SFP vendor.

  • Page 208: Figure 3.61 Webpage To Monitor Detailed Udld Status For Port 1 And Neighbour Status

    Industrial Managed User Manual Ethernet Switch – EH9711 Figure 3.60 Webpage to Monitor Detailed UDLD Status for Port 1 and Neighbour Status Table 3.53 Monitoring Descriptions of Detailed UDLD Status for Port 1 and Neighbour Status Label Description Detailed UDLD Status The current port state of the logical port.

  • Page 209: Diagnostics

    Figure 4.1 Diagnostics Menu Ping (IPv4) Atop’s managed switch provides a network tool called Ping for testing network connectivity in this subsection. Ping is a network diagnostic utility for testing reachability between a destination device and the managed switch. It utilizes ICMP (Internet Control Message Protocol) packet to troubleshoot IP connectivity issues.

  • Page 210: Figure 4.3 Result Of Successful Ipv4 Ping

    Industrial Managed User Manual Ethernet Switch – EH9711 Label Description Payload Data Pattern Determines the data pattern used in the ICMP data payload in single byte value. The default value is 0. The valid range is 0-255. Packet Count Determines the number of PING requests (ICMP packets) to be sent to the destination. The default value is 5.

  • Page 211: Ping (Ipv6)

    Industrial Managed User Manual Ethernet Switch – EH9711 Figure 4.4 Result of failure IPv4 ping Ping (IPv6) This page allows you to issue ICMPv6 PING packets to troubleshoot IPv6 connectivity issues. The user can enter an IP address or a domain name into the Hostname or IP Address field to verify network connectivity for IP version 6 network as shown in Figure 4.5.

  • Page 212: Traceroute (Ipv4)

    Industrial Managed User Manual Ethernet Switch – EH9711 Figure 4.7 Result of failure IPv6 ping Table 4.2 Descriptions of Options for Ping (IPv6) Diagnostic Tool Label Description The address of the destination host, either as a symbolic hostname or an IP Address. Hostname or IP Address Payload Size Determines the size of the ICMP data payload in bytes (excluding the size of Ethernet,...

  • Page 213: Figure 4.8 Diagnostics Webpage Using Ipv4 Traceroute

    Industrial Managed User Manual Ethernet Switch – EH9711 Figure 4.8 Diagnostics Webpage using IPv4 Traceroute Table 4.3 Description of each parameter for Traceroute (IPv4) Label Description Hostname or IP Address Specifies the hostname or IP Address of the destination Specifies the DSCP (DiffServ Code Point) priority (value) in packets. The value is DSCP Value an integer that has a range from 0 to 63.

  • Page 214: Traceroute (Ipv6)

    Industrial Managed User Manual Ethernet Switch – EH9711 Figure 4.9 Example of traceroute (IPv4) output Traceroute (IPv6) Traceroute (IPv6) is another diagnostic tool that allows the user to check the path or route that packets take from the managed switch to a destination host or IP address in IP version 6 network. This tool could provide information about host or gateway along the path to the specified destination.
  • Page 215 Industrial Managed User Manual Ethernet Switch – EH9711 Label Description configured on a local interface. Leave this field empty for automatic selection based on routing configuration. Note: You may only specify either the VID or the IP Address for the source interface.

  • Page 216: Maintenance

    Industrial Managed User Manual Ethernet Switch – EH9711 5 Maintenance Maintenance menu is the last main menu on the WebUI on the EH9711 Industrial Managed Ethernet Switch. Figure 5.1 shows all submenus under the Maintenance menu. Under this menu, the user can restart the device through the WebUI, reset the configuration of the device to the original factory default settings, upload new firmware image to update the device, and manage the configuration of the device.

  • Page 217: Factory Defaults

    Industrial Managed User Manual Ethernet Switch – EH9711 Figure 5.3 System restart in progress webpage Factory Defaults When the managed switch is not working properly, the user can reset it back to the original factory default settings by selecting MaintenanceFactory Defaults menu. Note that the IP configuration will not be changed after using this menu. The Factory Defaults webpage is shown in Figure 5.4.

  • Page 218: Software

    The users can update the device firmware via web interface using Upload menu as shown in Figure 5.6. To update the firmware, the users can download a new firmware from Atop’s website and save it on a local computer. Then, the users can click Select File…...

  • Page 219: Configuration

    Industrial Managed User Manual Ethernet Switch – EH9711 Figure 5.7 Webpage to Select an Active Firmware Table 5.1 Descriptions of Software Image Selection Label Description The file name of the firmware image, from when the image was last updated. Image The version of the firmware image.

  • Page 220: Download

    Industrial Managed User Manual Ethernet Switch – EH9711 Figure 5.9 Webpage to Save the Start-up Configuration Figure 5.10 Message indicates the saving of startup-configuration file successfully 5.4.2 Download The user can download different configuration files from the managed switch to the local computer using the web browser. There are running-config, default-config, and startup-config files that can be chosen as shown in Figure 5.11.

  • Page 221: Activate

    Industrial Managed User Manual Ethernet Switch – EH9711 switch. The last option for the File Name is to create a new file by selecting the radio button in front of Create new file option in which the user can enter the new file name in the text field under the Parameters column. Finally click on the Upload Configuration button to start the upload process.

  • Page 222: Delete

    Industrial Managed User Manual Ethernet Switch – EH9711 Figure 5.14 Activating New Configuration Webpage 5.4.5 Delete The last submenu under the MaintenanceConfiguration menu is Delete. This webpage allows the user to delete user- created configuration file stored in flash memory, including startup-config, as shown in Figure 5.15. Note that default-config cannot be deleted by this menu.

  • Page 223: Diagnostics

    Industrial Managed User Manual Ethernet Switch – EH9711 Diagnostics Atop Technologies, Inc. www.atoponline.com TAIWAN HEADQUARTER and ATOP CHINA BRANCH: INTERNATIONAL SALES: 2F, No. 146, Sec. 1, Tung-Hsing Rd, 3F, 75 , No. 1066 Building, 30261 Chupei City, Hsinchu County Qingzhou North Road, Taiwan, R.O.C.

Table of Contents
