Projecta INTELLI-CHARGE IC25 Manual page 19

P/No. IC25, IC25W, IC25RV
CHARGE CONTROL – 7 STAGE
Desulphation High frequency
Pulse charge
up to 11V
Soft Start Half the rated set
current up to 12V
Bulk Set current up to:
14.1V (GEL),
14.4V (AGM),
14.7V (WET),
14.7V (CALCIUM)
Absorption Constant voltage until current drops to the following set points:
2 Amp setting: 0.3A
6 Amp setting: 0.9A
12 Amp setting: 1.8A
25 Amp setting: 3.75A
Equalization Constant current
(Calcium mode only) (2.0–3.75A) up to 16V
then hold for 1 hour
or 12 hour timeout
Analysis
Recondition Constant current
(0.3–3.75A) for
4 hours limited to:
14.1V (GEL),
14.4V (AGM),
16.0V (WET),
16.0V (CALCIUM)
Float 13.7V
CHARGE CONTROL – 5 STAGE LITHIUM
Soft Start 1
Soft Start 2
Bulk
Absorption
Float
BATTERY RANGE
Automotive 80–3000CCA
Marine 110–4200MCA
Deep Cycle 14–500Ah
Lithium 4–250Ah
Types of Batteries
Size (mm) IC25:
IC25W:
Weight IC25:
IC25W:
IC35
High frequency
Pulse charge
up to 11V
Half the rated set
current up to 12V
Set current up to:
14.1V (GEL),
14.4V (AGM),
14.7V (WET),
14.7V (CALCIUM)
2 Amp setting: 0.3A
8 Amp setting: 1.2A
16 Amp setting: 2.4A
35 Amp setting: 5.25A
Constant current
(2.0–5.25A) up to 16V
then hold for 1 hour
or 12 hour timeout
Monitors battery for 90 sec
Constant current
(0.3–5.25A) for
4 hours limited to:
14.1V (GEL),
14.4V (AGM),
16.0V (WET),
16.0V (CALCIUM)
13.7V
Charge at 5% of set current, until the battery reaches 8.0V
Charge at 25% of set current, until the battery reached 10.0V
Set rate of current, up to 14.2V
10% of the set rate of current
80–4200CCA
110–5800MCA
14–700Ah
4–350Ah
Lithium, GEL, AGM, WET, CALCIUM
210 x 81 x 168 250 x 81 x 168
218 x 86 x 174
2.0 kg 2.6 kg
2.0 kg
IC50
High frequency
Pulse charge
up to 11V
Half the rated set
current up to 12V
Set current up to:
14.1V (GEL),
14.4V (AGM),
14.7V (WET),
14.7V (CALCIUM)
2 Amp setting: 0.3A
6 Amp setting: 0.9A
12 Amp setting: 1.8A
25 Amp setting: 3.75A
50 Amp setting: 7.5A
Constant current
(2.0–7.5A) up to 16V
then hold for 1 hour
or 12 hour timeout
Constant current
(0.3–7.5A) for
4 hours limited to:
14.1V (GEL),
14.4V (AGM),
16.0V (WET),
16.0V (CALCIUM)
13.7V
13.5V
80–6000CCA
110–8300MCA
14–1000Ah
4–500Ah
270 x 81 x 168
3.0 kg
IC8-24
High frequency
Pulse charge
up to 22V
Half the rated set
current up to 24V
Set current up to:
28.2V (GEL),
28.8V (AGM),
29.4V (WET),
29.4V (CALCIUM)
2 Amp setting: 0.3A
4 Amp setting: 0.6A
6 Amp setting: 0.9A
8 Amp setting: 1.2A
Constant current
(2.0A) up to 32V
then hold for 1 hour
or 12 hour timeout
Constant current
(0.3–1.2A) for
4 hours limited to:
28.2V (GEL),
28.8V (AGM),
32.0V (WET),
32.0V (CALCIUM)
27.4V
80–1000CCA
110–1300MCA
14–160Ah
8–200Ah
190 x 81 x 168
1.8 kg
19
