NOTE: The function related to pressing the key briefly is performed by pressing the key which will activate
the function assigned to it.On the other hand, to perform the function carried out when the key is held down
longer, press the key until the relative function is started. The buzzer will ring shortly to signal the function
has started.
NOTE: Warm-up: When the equipment has not been used for a prolonged period (more than 3 months) or
when turned on for the first time, a number of emissions with short times (0.01-0.02 sec.) and some pictures
with 0.1 sec are recommended to better stabilize the operation of the x-ray tube before its normal use.

3.4. CHECKING THE PARAMETERS

Before actually taking an exposure, make sure the exposure parameters for the examination in progress are correctly
set:
- Checking the selected body build.
- "CHILD" selected: indicates the x-ray unit is set for patients with small builds.
- "ADULT" selected: indicates the x-ray unit is set for patients with average-large builds.
Average/large build (ADULT) selected
NOTE: After the change has been made, the preset exposure times will automatically be modified.
- Checking the selected type of intraoral exam.
Upper molars
Upper canines/bicuspids or rear
"bite-wing"
Upper incisors
or front "bitewing"
12
Small build (CHILD) selected
OPERATOR'S MANUAL
Lower incisors
Lower canines/bicuspids
Lower molars
