TV Mount for STAND-RACE1B
Instruction Manual
SKU: STAND-RACE1TV
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/stand-race1tv
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
309-278-5303
Chat live with an agent!
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Vivo STAND-RACE1TV
Summary of Contents for Vivo STAND-RACE1TV
- Page 1 TV Mount for STAND-RACE1B Instruction Manual SKU: STAND-RACE1TV Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/stand-race1tv GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com www.vivo-us.com...
-
Page 2: Package Contents
WARNING! If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. -
Page 3: Assembly Steps
ASSEMBLY STEPS STEP 1 Remove existing four screws from STAND-RACE1B front frame support as shown below using 5mm Allen Wrench (T-A). Install Support Bars (A) to the front frame support using the previously removed screws. - Page 4 STEP 2 Assemble Support Plate (B) to Support Bars (A) using M8x16mm Screws (S-A) and provided 5mm Allen Wrench (T-A).
- Page 5 STEP 3 Assemble Left TV Bracket (D) and Right TV Bracket (C) to the back of the television using Screws (M-A through M-E) with Washers (M-F) and Spacer (M-G, M-H).
- Page 6 STEP 4 Hang Left TV Bracket (D) and Right TV Bracket (C) with display onto Support Plate (B). Turn the security screws on the underside of the brackets clockwise to secure them in place.
- Page 7 STEP 5 Secure cables using Cable Clips (E) and Cable Ties (F).
