Repair instructions
Pneumatic-Controller PCB
Dräger Medical AG & Co. KGaA • EvitaXL
1
General
In case of repair, replace the complete Pneumatic-
Controller PCB. After replacement, install the device
software on the Pneumatic-Controller PCB.
Electrostatic discharge may damage electrostatic
sensitive devices. When handling electrostatic
sensitive devices, use a static-dissipative mat
and a static dissipative wrist strap.
Risk of burns when operating the system with the
rear panel (heat sink) disassembled. Do not
operate the device for longer periods of time with
the rear panel removed.
General
1
Advertisement
Table of Contents
Related Manuals for Dräger Medical X2
Summary of Contents for Dräger Medical X2
- Page 1 Repair instructions General Pneumatic-Controller PCB General In case of repair, replace the complete Pneumatic- Controller PCB. After replacement, install the device software on the Pneumatic-Controller PCB. Electrostatic discharge may damage electrostatic sensitive devices. When handling electrostatic sensitive devices, use a static-dissipative mat and a static dissipative wrist strap.
- Page 2 Repair instructions Power supply Power supply Assignment Pin Assignment +15 V 11c AGND -15 V 12c DGND +24 V +5 V Fig. 1 Pneumatic-Controller PCB Dräger Medical AG & Co. KGaA • EvitaXL...
- Page 3 Repair instructions Replacing the Pneumatic-Controller PCB Replacing the Pneumatic-Controller PCB 1 Switch off the device. 2 Unplug the power plug of the device from the socket- outlet. Electrostatic discharge may damage electrostatic sensitive devices. When handling electrostatic sensitive devices, use a static-dissipative mat and a static dissipative wrist strap.
- Page 4 Repair instructions Replacing the Pneumatic-Controller PCB Fig. 4 Rear view of the device (with open pneumatic Fig. 3 Rear view of the device assembly) 6 Remove the rear panel of the pneumatic assembly and put it aside. A faulty Pneumatic-Controller PCB is special waste. 7 Remove the faulty Pneumatic-Controller PCB (Fig.
- Page 5 Repair instructions Replacing the Pneumatic-Controller PCB 10 Secure the rear panel to the device using the screws (Fig. 5/1 and 2). Fig. 5 Rear view of the device 11 Install the respective Pneumatic-Controller PCB software. 12 Calibrate the PEEP/PIP valve, see chapter “Repair Instructions”, section “PEEP/PIP valve”.
