Owners & Instruction
Manual
Monkey Bar
ADD ~ ON
This instruction booklet is to be used exclusively for Eastern Jungle Gym
customers only. It is not to be handed out to the general public. Any duplication of
this booklet will be subject to copyright protection and federal laws.
Advertisement
Related Manuals for Eastern Jungle Gym Monkey Bar
Summary of Contents for Eastern Jungle Gym Monkey Bar
- Page 1 Monkey Bar ADD ~ ON This instruction booklet is to be used exclusively for Eastern Jungle Gym customers only. It is not to be handed out to the general public. Any duplication of this booklet will be subject to copyright protection and federal laws.
- Page 2 Wood Identification 2 @ 4”x4”x78” (Monkey Bar Uprights) Part # M4478 1 @ 4”x4”x78” (Monkey Bar Over Head LEFT) Part # M4478L 1 @ 4”x4”x78” (Monkey Bar Over Head RIGHT) Part # M4478R 1 @ 2”x4”x12 ” (Monkey Bar Ties LEFT) Part # MT2412L 1 @ 2”x4”x12 ”...
- Page 3 NOTE: Make sure that all square sides and angled cut sides are Measure from the square side of all 4 monkey bar supports and facing in the same direction. make a line using measurements above (as shown in the photo).
- Page 4 Level Monkey bar overhead as needed. Upright From inside of clubhouse install Monkey bar Install GS2422 stakes to bottom of each overhead with 2 - 5” lag bolts into post and upright leg by digging into ground and install 2 - 5”...
