  • Page 1 Owners & Instruction Manual 1/2021...
  • Page 2 1-800-752-9787 Customer Service available 9-5pm EST Mon-Fri call 1-800-752-9787 or Email-Info@easternjunglegym.com...

  • Page 4: Site Location

    Site Location Our exclusive leveling system was developed through more then 26 years of installation experience. This unique leveling system ensures safe installation on un-level properties. While your jungle gym will be level and safe some of the activities will be affected by the sloping property (Diagram A ).
  • Page 6 Accessories Identification (2) Easy 1-2-3 bracket (6) Snap Hooks (2) Green Sling Swings (6) Heavy Duty Swing Hangers Wood Identification Classic Swing 1 @ SWING BEAM SBHG46120 4 @ Side Support Part #SSP4496...
  • Page 7 Note: If you have purchased only the Eastern Jungle Gym hardware kit, EJG recommends that the beam size should be 4x6x120”. The side supports should be 4x4x96”. Please prepare the swing beam using the dimensions shown in the diagram below.

  • Page 8: Hardware Identification

    Hardware Identification H6- 3/8” x 6 ½” Hex Bolt B3- 5/16” x 3” Lag Bolt N- Nut W 3/8” Washer W 5/16” Washer W3/8 W5/16...
  • Page 10 Step #1 Swing Beam Assembly Classic Place swing hangers on beam using hardware provided. (12)-3/8 Hex Bolt (6½”) (24)-3/8 Washer (12)-3/8 Nut (6)-Swing Hangers 3/8” Nut 3/8” washer Step #2 Swing Beam Bracket Classic Layout SBHG46120 on the ground with swing brackets facing up. Slide Easy 1-2-3 Bracket onto beam.

  • Page 11: Step #3-Post Install

    Step #3-Post Install Classic Install (4)-SS4496 Posts into Easy 1-2-3 Bracket. Predrill (4)-1/4” pilot holes. Install posts to bracket using B3 bolts.
  • Page 12 Step #4- Swing Set Leveling Classic With the help of another person turn swing beam assembly upright. Level swing beam as needed by digging the side support legs into the ground. Check with level Two metal stakes are provided for added stability.
  • Page 13 Step #4- Accessories Install Classic Hang swings and trapeze bar. Make sure chains are the same length on each piece to ensure the swing is level. 10’ 8’-6”...
  • Page 15 Customer Service available 9-5pm EST Mon-Fri call 1-800-752-9787...
