LT-3070-8A
LED CV Power Repeater
LED power repeater is suitable for all of our company's power-output
power expansion, it accepts PWM control, the control quantity of LED lights would be
twice as much by adding one more power repeater, unlimited quantity of power repeater
to be connected theoretically.
1. Product parameter:
LT-3070-8A (Common anode)
Input signal:
PWM (200Hz-2000Hz)
Input voltage:
12～48Vdc
Current load:
8A×3CH Max. 24A
Output power:
(0~96W...384W)×3CH Max. 1152W
2. Product size:
136
148
LT-3070-8A Power Repeater
warranty
5 years
style controllers'
℃
~65 ℃
Working temp.:
-30
Dimension:
L148×W87×H23(mm)
Package size:
L158×W94×H31(mm)
Weight (G.W.):
380g
126.6
1
3. Wiring diagram:
Signal input
3.1 Repeaters connected to RGB controller as follow:
220V/110Vac
Power supply
RGB controller
24Vdc
-
+
LT-3070-8A
LT-3070-8A
LT-3070-8A Power Repeater
LED lamps connection
12 48Vdc
~
Power input
RGB strip
72W/5m
220V/110Vac
Power supply
RGB strip
72W/5m
220V/110Vac
Power supply
2
www.ltech-led.com
-
+
-
+
