Lorex SG8840 Quick Setup Manual

4. Specifications
Camera Specifications:
Image Sensor 1/3" CMOS
Minimum Illumination 1.5 Lux / F1.5
Transmission Frequency ISM 2.4~2.483 MHz (4 CH*)
Battery Type/Capacity Lithium Battery / 500 mAh
Charge Time 2 hr. charge
Up to 5 hrs (less in IR mode)
Work Time
Power Supply +5V (DC), 700 mA
Camera Dimensions 3.5" x 1.25" x 1.25"
(W x D x H) 10cm x 3cm x 3cm(
°
Operating 14 F ~ 122
°
Temperature Range -10 C ~ 50
Wireless Receiver Specifications:
Receiving Frequency ISM 2.4~2.483 MHz (4 CH*)
Video Output Level 1 Vp-p@75OHM,S/N>38DB
Audio Output Level 1 Vp-p@600OHM
Power Supply 8V (DC)
Consumption Current 180 mA
Unobstructed Range Up to 328 ft. / 100 meters **
Receiver Dimensions 4" x 0.75" x 3.25"
(W x D x H) 10cm x 2cm x 8.5cm(
°
Operating Temperature 14 F ~ 122
°
-10 C ~ 50
Operating Humidity 85% RH
* 4 Available channels for optimal signal.
** Maximum open space transmission range. Actual range dependent upon
building materials and other obstructions in path of wireless signal.
Dimensions:
It's all on the web
Product Information
User Manuals
Quick Start Guides
°
F
°
C
°
F
°
C
VISIT
www.lorexcctv.com
LOREX Technology Inc.
Copyright © 2006 LOREX Technology Inc. As our
products are subject to continuous improvement,
LOREX and its subsidiaries reserve the right to mod-
ify product design, specifications and prices, without
notice and without incurring any obligation. E&OE
Specification Sheets
Software Upgrades
Firmware Upgrades
This product broadcasts over public airways and its video and audio
H O M E & B U S I N E S S S E C U R I T Y
2.4 GHz Wireless Color
Video System
with Rechargable Lithium Battery
Model SG8840
Quick Setup Guide
Wireless Disclaimer
signals may be intercepted without your consent.
