10:00
Step 1 should take approximately 5-10 minutes
Step 1 - Set Up Your Camera First
System Contents
- Color Camera
- Power Supply
- Camera Stand (with screws)
- Ethernet Cable
- Quick Setup Guide
- Lorex Application Software CD
Not Included: Broadband Router & Computer
Connect one end of the ethernet
1
cable to the color camera
* This set-up guide is intented for users using Internet Explorer as their Internet browser
Information in this document is subject to change without notice. As our products are subject to continuous improvement, Lorex Technology and our subsidiaries reserve the right to
Page
modify product design, specifications and prices, without notice and without incurring any obligation. E&OE © 2006 LOREX. All rights reserved.
IPSC240P
Power Supply
Color Camera
Connect the other end of the ethernet cable
2
to your broadband router (not included)
SETTING UP YOUR SYSTEM
Ethernet Cable
Connect the 2V AC power supply to
3
the color camera and electrical outlet
WWW.LOREXINTERNATIONAL.COM
