- Page 1 5” B&W 2-CHANNEL OBSERVATION SYSTEM WITH TV TUNER Instruction Manual English Version1.0 MODEL: SG5S1025C-A www.lorexcctv.com Copyright © 2006 Lorex Technology Inc.
- Page 2 CAUTION RISK OF ELECTRIC SHOCK. DO NOT OPEN. CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. Explanation of two Symbols The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated "dangerous voltage"...
- Page 3 SAFETY INSTRUCTIONS IMPORTANT SAFEGUARDS All the safety and operating instructions should be read before the appliance is operated and retained for future reference. 1. HEED WARNINGS - All warnings on the appliance and in the operating instructions should be adhered to. 2.
-
Page 4: Table Of Contents
To learn more about this product and for a complete listing of Lorex Video Security products, please visit us at: http://www.lorexcctv.com CHAPTER TABLE OF CONTENTS PAGE INTRODUCTION & FEATURES…………………………………………………….….1 SYSTEM INCLUDES………………………………………………………………...…..2 CONTROLS AND FUNCTIONS MONITOR …..........………………………..…..…..3 CAMERA ...….……………........……….………….……...……4 INSTALLATION CAMERA ............………………………..….....5 MONITOR ................…......5... - Page 5 INTRODUCTION: Thank you for purchasing the Lorex 5” 2-Channel B&W Observation System / TV which is ideal for monitoring your business, office, home or valuables. The system allows you to automatically scan up to 2 cameras. View the locations Sequentially or in Full Screen.
-
Page 6: System Includes
SYSTEM INCLUDES 5” – 2 CHANNEL BLACK & WHITE MONITOR 1 - 1/4” CMOS BLACK & WHITE CAMERA WITH STAND AND 57 FT CABLE (1 camera included with Model SG5S1025C-A) OWNER’S MANUAL... - Page 7 MONITOR CONTROLS – FRONT PANEL 1) Volume Control- Turn the dial to adjust the volume 2) TV/Monitor Switch – Allows you to switch from TV mode to live camera video 3) UHF/VHF-H/VHF-L Switch – You can switch between 3 selectable TV Bands when the monitor is set to TV (Band selection depends on the channel you are looking for) 3) Select TV Band –...
- Page 8 MONITOR CONTROLS – BACK PANEL 1) DC Input Jack - Power source to the monitor. Connect one end to the monitor; the other end to an electrical outlet. 2) EXT – To connect an external antenna (standard) 3) Video/Audio Output – Use an RCA audio/video cable (not supplied) to connect to a recording device (eg.
- Page 9 WIRED CAMERA INSTALLATION 1. Attach the stand base to the wall or ceiling where you want to install the camera. Locate a wall stud or ceiling joist and secure bracket using the supplied mounting screws. 2. Attach the camera to the stand and firmly tighten the swivel. 3.
-
Page 10: Monitor
Make sure the camera is not facing any Exposed direct light or sunlight FOR MORE INFORMATION http://www.lorexcctv.com As our products are subject to continuous improvement, LOREX and its subsidiaries reserve the right to modify product design, specifications and prices, without notice and without incurring any obligation. E&OE... -
Page 11: Optional Accessories
OPTIONAL ACCESSORIES The following accessories are available to add to your existing system. CABLE TIME LAPSE VCR NIGHTVISION Weatherproof night vision Extends viewing length Used to record key events. accessory. Allows you to from camera to monitor. Select from a 40 hour real see in the dark up to Available in 65, 100 and time or 960 Hour time... -
Page 12: Technical Specifications
TECHNICAL SPECIFICATIONS WIRED WEATHER RESISTANT CAMERA Image sensor 1/4” B&W CMOS Camera Lens 3.6mm Picture Elements 320 H X 240 V Scanning system 2:1 interlace Resolution Horizontal 240 TV Lines Min. illuminations 0.1 Lux @ F2.0 Video Output 1.0Vp-p/75 Ohm Gamma characteristics 0.45 Auto Iris... - Page 13 CARE AND MAINTENANCE: Please follow these instructions to ensure proper care and maintenance of this system Keep your monitor and camera dry. If it gets wet, wipe it dry immediately. Use and store your unit in normal temperature environment. Extreme temperatures can shorten the life of the electronic devices.
