- Page 1 BRIZA 26 MANUAL...
-
Page 2: Table Of Contents
11. WARRANTY .........................20 12. DISSASSEMBLY INSTRUCTIONS ................20 13. REFERENCE STANDARDS ..................21 DECLARATION OF CONFORMITY JAGA N.V. - Verbindingslaan 16 - B 3590, declares under its sole responsibility that the CEO JAGA N.V. product to which this declaration relates: BRIZA 12, BRIZA 22, BRIZA 26... -
Page 3: Used Symbols
- access to the unit has been restricted due to on-site conditions. - the initial start-up has been carried out before a general cleaning of both the fan and the coil. JAGA CANADA | BRIZA 26 | MANUEL | 2022.09.27 | V.01... -
Page 4: Warnings And Safety
– installation of acoustic insulation in hollow acoustic spaces. Avoid cavities between insulation and pipes. JAGA CANADA | BRIZA 26 | MANUEL | 2022.09.27 | V.01... -
Page 5: General Information
– it is advisable to run the unit at maximum speed and to check for abnormalities. 5.1. OPERATIONAL LIMITS: An installation that does not meet the specified operational limits releases Jaga NV from all liability with respect to damage to objects or people. -
Page 6: Electrical Connection - General
The electrical connection of the unit must be carried out by qualified personnel, in compliance with the regulations applicable in the country where the unit is installed. Non-conforming electrical con- nections releases Jaga N.V. from liability concerning damage to objects and persons. DANGER! – ... -
Page 7: Operating Limits
80 % °F °F °F °F °F 39.2 42.8 46.4 90 % °F °F °F °F 42.8 46.4 100 % °F °F °F 42.8 46.4 Permitted minimum water temperature JAGA CANADA | BRIZA 26 | MANUEL | 2022.09.27 | V.01... -
Page 8: Wall Mounted Model
AIR OUTLET the top of the unit the front of the unit the top of the unit the front of the unit JAGA CANADA | BRIZA 26 | MANUEL | 2022.09.27 | V.01... -
Page 9: Dimensions
22 ¹/₄ 22 ¹/₄ WIDTH 10 ¹⁹/₃₂ 10 ¹⁹/₃₂ 10 ¹⁹/₃₂ LENGTH 52 ¹/₆₄ 63 ¹³/₁₆ 77 ¹⁹/₃₂ 62 ⁶³/₆₄ 74 ⁵¹/₆₄ 88 ³⁷/₆₄ 60 ³/₆₄ 71 ²⁷/₃₂ 85 ⁵/₈ JAGA CANADA | BRIZA 26 | MANUEL | 2022.09.27 | V.01... - Page 10 ≥6 ¹¹/₁₆ ≥5 ²⁹/₃₂ ≥10 ⁵/₈ ≥6 ¹¹/₁₆ ≥5 ²⁹/₃₂ ≥5 ²⁹/₃₂ ≥5 ²⁹/₃₂ ≥9 ²⁷/₃₂ ≥9 ²⁷/₃₂ ≥5 ²⁹/₃₂ ≥5 ²⁹/₃₂ ≥7 ⁷/₈ ≥7 ⁷/₈ Dimensions in Inches JAGA CANADA | BRIZA 26 | MANUEL | 2022.09.27 | V.01...
-
Page 11: Installation
Without casing : Mark and drill the mounting holes for the the device. The type of wall determines which type of screw or plug must be used. Make sure that the wall is level and has sufficient loadbearing capacity! JAGA CANADA | BRIZA 26 | MANUEL | 2022.09.27 | V.01... - Page 12 1. Place the screws of the device(5-8) and let them stick out 1 cm. [1] 2. Place the device in the correct position. 3. Tighten the screws. [2] NOT USED 0-10V 120V / 60Hz Speed control input Connect the device electrically. JAGA CANADA | BRIZA 26 | MANUEL | 2022.09.27 | V.01...
- Page 13 Position the drain pipes without mechanical stress on the drain connection of the unit. JAGA CANADA | BRIZA 26 | MANUEL | 2022.09.27 | V.01...
- Page 14 Secure the casing by tightening the stay bolts. [2] WITH CASING Install the grille. Put the screws in the mounting holes. Ideally, the air is blown towards the wall. JAGA CANADA | BRIZA 26 | MANUEL | 2022.09.27 | V.01...
-
Page 15: Ceiling-Mounted-Model
Electrical connection 8.2. CONFIGURATION BABW/BT BABW/FT SUCTION the bottom of the unit the front of the unit AIR OUTLET the top of the unit the top of the unit JAGA CANADA | BRIZA 26 | MANUEL | 2022.09.27 | V.01... -
Page 16: Dimensions
8.3.1. Installation dimensions ≥ 12 ¹³/₆₄ ≥ 12 ¹³/₆₄ 5 ²⁹/₃₂ 5 ²⁹/₃₂ 5 ²⁹/₃₂ 5 ²⁹/₃₂ ≥6 ¹¹/₁₆ ≥6 ¹¹/₁₆ max. 118 ⁷/₆₄ max. 118 ⁷/₆₄ Dimensions in Inches JAGA CANADA | BRIZA 26 | MANUEL | 2022.09.27 | V.01... -
Page 17: Installation
Make sure that the wall is level and has sufficient loadbearing Threaded rods: mount the unit on the threaded rods. Use a capacity! washer between screw head and the appliance. The installer should provide sound dampening material. JAGA CANADA | BRIZA 26 | MANUEL | 2022.09.27 | V.01... - Page 18 If the unit is used for cooling, the hydraulic pipes must be insulated. When using devices for cooling: iron couplings prohibited. Connect the condensate pump. NOT USED 0-10V 120V / 60Hz Speed control input Connect the device electrically. JAGA CANADA | BRIZA 26 | MANUEL | 2022.09.27 | V.01...
-
Page 19: Initial Start
– remove dust using an air compressor – wash with water and brush gently – dry by using compressed air – keep the condensate drain free from any obstructions that may prevent normal water flow JAGA CANADA | BRIZA 26 | MANUEL | 2022.09.27 | V.01... -
Page 20: Electrical Circuit
– the electronic components are considered special waste, and must be recycled as such – the pipe insulation and the sound-absorbing lining must be removed and processed as urban waste Please follow and file these instructions! JAGA CANADA | BRIZA 26 | MANUEL | 2022.09.27 | V.01... -
Page 21: Reference Standards
ISO 5135 source nonpunctiform, lied on a surface that reflects acoustically. EUROVENT 8/2-1992 Electromagnetic compatibility, generic emission standard. Part 1: resi- EN 50081-1:1992 dential, commercial and light industry. JAGA CANADA | BRIZA 26 | MANUEL | 2022.09.27 | V.01... - Page 22 Jaga Canada Climate Systems www.jaga-canada.com 27200.20000056 2022.09.27. - Jaga Inc.
