Merrick
Assembly Instructions
Dimensions
Width - 87,5cm
Depth - 57,5cm
Height - 190cm
Important
– Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline:
14-3B-243_01
2 Door 1 Drawer Wardrobe
- Please keep for future reference
204/7267
0845 077 8888
Issue 2 - 14/04/15
Advertisement
Related Manuals for HOME RETAIL GROUP Merrick 204/7267
Summary of Contents for HOME RETAIL GROUP Merrick 204/7267
- Page 1 2 Door 1 Drawer Wardrobe Merrick Assembly Instructions - Please keep for future reference 204/7267 Dimensions Width - 87,5cm Depth - 57,5cm Height - 190cm Important – Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 0845 077 8888 14-3B-243_01 Issue 2 - 14/04/15...
-
Page 2: Care And Maintenance
Safety and Care Advice Important – Please read these instructions fully before starting assembly • Do not stand or put weight on • Check you have all the • To reduce the components and tools listed on the product, this could cause likelihood of the following pages. - Page 3 If you have damaged or missing commponents, Components - Panels call the Customer Helpline: 0845 077 8888 Please check you have all the panels listed below Top panel x 1 (57,5 x 87,5cm) Leg x 4 Left side panel x 1 Right side panel x 1 (4,6 x 15,7cm) (57,5 x 171cm)
- Page 4 Components - Fittings Please check you have all the fittings listed below Note : The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required. 6/30mm Wooden dowel x 2 8/30mm Wooden dowel x 12 Spanner 13mm x 1 Nail x 60...
- Page 5 Assembly Instructions Step 1 Attaching legs Position the leg shown on the picture, place the washer U and fix the nut T using the spanner. Repeat assembly for the remaining legs. Step 2 Preparation for the Preparation for the attaching of side panels attaching of side panels Insert screws E into the...
- Page 6 Assembly Instructions Step 3 Preparation for the attaching of horizontal partition shelf Insert screws into the drilled holes of the left and right side panels , top panel and fix them. Step 4 Attaching the horizontal partition shelf Insert wooden dowels B into the horizontal partition shelf 14 and place the the horizontal...
- Page 7 Assembly Instructions Step 5 Attaching base and top panel Insert wooden dowels B into the side panels 1 and 2 from the bottom and from the top and Place the side panels 1 and 2 onto the base 4 and the top panel 3 onto the side panels 1 and 2 .
- Page 8 Assembly Instructions Step 7 Attaching runners Position left runner A L and right runner A R onto the drilled holes of the side panels 1 and 2 . Fix through holes shown using screws F. Fix the runners using screws Step 8 Stick the self-adhesive caps V onto the holes as...
- Page 9 Assembly Instructions Step 9 Fixing to wall It is recomended that the wardrobe is fixed to a wall. Mark fixing hole onto wall. Drill a hole and insert a suitable wall plug. Fix wall strap using a suitable screw. Warning: Before drilling, check wall for hidden pipes and...
- Page 10 Assembly Instructions Step 10 Drawer assembly a: Insert screws into drawer front b: Insert wooden dowels into left and right drawer sides c: Insert plastic dowels into left drawer side and drawer back and fix it together using the hammer. d: Insert plastic dowels into right drawer side...
- Page 11 Assembly Instructions Step 10 - continued g: Align correctly and insert small locking nuts into left and right drawer sides turn them clockwise to lock. h: Position left and right runners B to left and right drawer sides , fix using screws continued on next page...
- Page 12 Assembly Instructions Step 11 i: Position the reinforcing metal strap onto the large drawer as shown. Fix using supplied screws k: Attach knobs drawer front using screws Step 12 Placing shelf With help, carefully stand wardrobe upright. Warning: The wardrobe is heavy.
- Page 13 Assembly Instructions Step 15 Position 3 door hinges into left and right doors , fix using upplied screws. Step 16 Attaching knobs to the doors Attach knobs doors , using screws Repeat this step with all doors Step 17 Hanging doors With help, slot door hinges onto hinge plates and click into position.
- Page 14 Assembly is complete. If you need help or have damaged or missing parts, call the Customer Helpline: 0845 077 8888 Home Retail Group Plc, 489 - 499 Avebury Boulevard, Milton Keynes, MK9 2NW...
- Page 15 A Guide to Wall Mounting & Fixings IMPORTANT: When drilling into walls always check that there are no hidden wires or pipes etc. Make sure that the screws and wall plugs being used are suitable for supporting your unit. Consult a qualified tradesperson if you are unsure. HINTS: 1) General Rule Always use a larger screw and wall plug if you are not sure.
