Hygena Cubic Wood/Glass Coffee/Nest
Assembly Instructions
453/1939D
- Please keep for future reference
Dimensions
Width - 95cm
Depth - 48cm
Height - 45.6cm
Important
– Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 03456 400800
Issue 1 - 16/09/15
Advertisement
Table of Contents
Related Manuals for HOME RETAIL GROUP 453/1939D
Summary of Contents for HOME RETAIL GROUP 453/1939D
- Page 1 Hygena Cubic Wood/Glass Coffee/Nest Assembly Instructions 453/1939D - Please keep for future reference Dimensions Width - 95cm Depth - 48cm Height - 45.6cm Important – Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 03456 400800...
- Page 2 Safety and Care Advice Important – Please read these instructions fully before starting assembly • Check you have all the • Do not stand or put weight on • We do not components and tools listed on the product, this could cause recommend the pages 2 &...
- Page 3 Components - Panels Please check you have all the panels listed below Large table Large table Large table cross bar x 2 top panel side frame x 2 (476 x 435 mm) (825 x 58mm) (950 x 480 mm) Small table Long bolt x 4 Small table side frame x 4...
- Page 4 Components - Fittings If you have damaged or missing components, call the Customer Helpline: 03456 400800 Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required.
- Page 5 Assembly Instructions Step 1 Lay Large table side frames on a flat soft surface. Insert Wood dowels into the indicated holes. Screw 4 Metal dowels into the threaded holes in the Large table side frames as shown. Step 2 Firmly push the Large table side frames onto the ends of Large table cross bars...
- Page 6 Assembly Instructions Step 3 Note: Longer leg of the cross on the Insert the 4 Metal Cams Metal Cams must into the 4 holes on face towards metal the Cross bars cams. push in firmly. Note: Longer leg of the cross on the Metal Cams must face towards metal cams (as shown).
- Page 7 Assembly Instructions Step 5 Firmly place the unit from Step 3 onto the Bolts Put one Washer onto each bolt head, screw on the head of bolt, tighten with Wrench Note: Align legs with metal blocks before tightening. Step 6 Peel off the cover of the Foot pad , attach to...
- Page 8 , Cross bars , Top panels and Bolts Assembly is complete. If you need help or have damaged or missing parts, call the Customer Help Line: 03456 400800 Home Retail Group plc. Avebury, 489-499 Avebury Boulevard. Milton Keynes. MK9 2NW...
