Winchester - Chest of 4+4 Drawers
Assembly Instructions
Dimensions
Width - 126.3cm
Depth - 42.5cm
Height - 90.8cm
Important
– Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline:
- Please keep for future reference
656/7004
656/6957
0870 160 1490
Issue 1 - 10/03/10
Advertisement
Related Manuals for HOME RETAIL GROUP Winchester 656/7004
Summary of Contents for HOME RETAIL GROUP Winchester 656/7004
- Page 1 Winchester - Chest of 4+4 Drawers Assembly Instructions 656/7004 - Please keep for future reference 656/6957 Dimensions Width - 126.3cm Depth - 42.5cm Height - 90.8cm Important – Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 0870 160 1490 Issue 1 - 10/03/10...
-
Page 2: Care And Maintenance
Safety and Care Advice Important – Please read these instructions fully before starting assembly • Check you have all the • Do not stand or put weight on • We do not components and tools listed on the product, this could cause recommend the pages 2 and 3. - Page 3 Components - Panels If you have damaged or missing components, call the Customer Helpline: 0870 160 1490 Please check you have all the panels listed below Top panel x 1 (126.3 x 42.5cm) Right side panel x 1 Left side panel x 1 (39.5 x 88.5cm) (39.5 x 88.5cm) Bottom panel x 1...
- Page 4 Components - Fittings Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required. Feet x 4 8/30mm Wooden dowel x 24 6/30mm Wooden dowel x 32 Nail x 50 9mm Screw x 32...
- Page 5 Assembly Instructions Step 1 Attaching runners Position left runners and right runners A on to the drilled holes of the left and right side panels the left side of vertical partition wall Fix through holes shown using screws Turn over the vertical partition wall attach runners A shown using screws...
- Page 6 Assembly Instructions Step 2 Preparation for the attaching of top panel and bottom panel Insert screws into the drilled holes of the left and right side panels , top panel Insert wooden dowels into the bottom panel as shown on the picture. Step 3 Attaching the bottom panel and vertical...
- Page 7 Assembly Instructions Step 4 Frame assembly Insert screws in to the frames Step 5 Insert wooden dowels as shown, align correctly and insert large locking Attaching runners nuts in to the frame Position runners , place the frames 15mm in from front edge and turn locking nuts of the left side panel clockwise to lock.
- Page 8 Assembly Instructions Step 6 Attaching the frame Insert wooden dowels into the edge of the left and right side panels Align correctly and insert large locking nuts into left and right side panels and bottom panel , place the frame and turn locking nuts clockwise to lock.
- Page 9 Assembly Instructions Step 9 Drawer assembly Insert screws into large or small drawer front Insert wooden dowels in to large or small drawer front and place left and right drawer sides Slide large or small drawer base into the grooves. Place large or small drawer back onto sides.
- Page 10 Assembly Instructions Step 9 - continued Large drawers only: Position 2 drawer base supports onto the underside of the large drawers as shown. Fix using supplied screw. All drawers: Attach handles to drawer fronts using screws Step 10 Note: Wall fixings are not Fixing to wall supplied with this unit.
- Page 11 Slide top of the runners back. Fix through holes shown using screws If you need help or have damaged or missing parts, call the Customer Helpline: 0870 160 1490 Home Retail Group Plc, 489 - 499 Avebury boulevard, Milton Keynes, MK9 2NW...
