Bureau writing desk
Assembly Instructions -
Please keep for future reference
244/8811
Dimensions
Width - 80cm
Depth - 42cm
Height - 104cm
Important -
Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 0345 6400 800
Issue 1 -23/05/14
Advertisement
Related Manuals for HOME RETAIL GROUP 244/8811
Summary of Contents for HOME RETAIL GROUP 244/8811
- Page 1 Bureau writing desk Assembly Instructions - Please keep for future reference 244/8811 Dimensions Width - 80cm Depth - 42cm Height - 104cm Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 0345 6400 800...
-
Page 2: Care And Maintenance
Safety and Care Advice Important - Please read these instructions fully before starting assembly • Keep these instructions for • Do not use this item if any • Dispose of all packaging carefully and responsibly. future use. components are missing of damaged. -
Page 3: Components - Parts
Components - Parts Please check you have all the parts listed below Top frame Leg x 4 (80 x 41 x 9cm) (4 x 4 x 74.5cm) Side panel (right) (27.6 x 41 x 1.5cm) Side panel (left) (27.6 x 41 x 1.5cm) Shelf (76.7 x 16x 1.5cm ) Divider x 2... -
Page 4: Tools Required
Components - Fittings If you have damaged or missing components, call the Customer Helpline: 0345 6400 800 Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required. - Page 5 Assembly Instructions Step 1 Preparing panels Place back panel shelf and side panels flat on the floor with the fixing holes facing up. Screw metal dowels into each panel as shown. Note: Screw metal dowels as far as shown. Do not overtighten. Step 2 Assembling shelf Fit wooden dowels...
- Page 6 Assembly Instructions Step 3 Attaching dividers Fit wooden dowels into the holes in the underside of shelf as shown. Locate dividers into position,with the holes facing outwards. Insert locking nuts into the holes in dividers Turn locking nuts clockwise to secure. Step 4 Attaching side panels Fit wooden dowels...
- Page 7 Assembly Instructions Step 5 Attaching legs With help, place top frame upside down onto a clean flat surface. Assemble legs to top using fixings Step 6 Attaching desk top With help, carefully turn the desk frame upright. Align folding desk top onto the frame as shown.
- Page 8 Assembly Instructions Step 7 Pull out the wooden runners from the top frame Open out desk top and lay it down onto the wooden runners .
- Page 9 Assembly Instructions Step 8 Assembling shelf assembly Screw metal dowels into the holes in top panel as shown. Fit wooden dowels into the remaining holes. With help, carefully locathe the shelf assembly into position. Insert locking nuts into the corresponding holes as shown.
- Page 10 Note: Screws are not supplied. Assembly is complete. If you need help or have damaged or missing parts, call the Customer Helpline: 0345 6400 800 Home Retail Group. 489-499 Avebury Boulevard. Saxon Gate West. Central Milton Keynes. MK9 2NW...
