Kitchen Trolley with Wine Rack
Assembly Instructions
842/8976
- please keep for future reference
Dimensions
Width - 65cm
Depth - 35cm
Height - 79cm
Important
– Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 0845 640 0800
Issue 1 - 25/06/12
Advertisement
Related Manuals for HOME RETAIL GROUP 842/8976
Summary of Contents for HOME RETAIL GROUP 842/8976
- Page 1 Kitchen Trolley with Wine Rack Assembly Instructions 842/8976 - please keep for future reference Dimensions Width - 65cm Depth - 35cm Height - 79cm Important – Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 0845 640 0800...
-
Page 2: Care And Maintenance
Safety and Care Advice Important – Please read these instructions fully before starting assembly • Check you have all the • Do not stand or put weight on • We do not components and tools listed the product, this could cause recommend the below and on pages 1 and 2. - Page 3 Components - Panels Please check you have all the panels listed below 1 Left side x 1 2 Right side x 1 3 Bottom shelf x 1 4 Middle shelf x 1 (72.5(h) x 32(d)cm) (72.5(h) x 32(d)cm) (53.8(w) x 32(d)cm) (53.8(w) x 32(d)cm) 5 Wine rack left upright 6 Wine rack middle...
- Page 4 Components - Fittings If you have damaged or missing components, call the Customer Helpline: 0845 640 0800 Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required.
- Page 5 Assembly Instructions Step 1 Fix 2 x cambolt and 2 x wooden dowel into rear of drawer front as shown. Fix 1 x handle drawer front using 2 x 16mm bolt as shown. Step 2 Insert 1 x camlock into drawer left and drawer right...
- Page 6 Assembly Instructions Step 7 Fix left drawer runner (case) to left side and fix right drawer runner (case) to right side using 4 x 10mm screw as shown. Front Step 8 Slot wine rack middle upright , wine rack bottom shelf wine rack top shelf together as shown.
- Page 7 Assembly Instructions Step 11 Connect bottom shelf to assembly completed at Step 9 using 4 x 30mm screw shown. Step 12 Fix wine rack assembly completed at Step 11 to right side using 2 x 30mm screw 2 x 50mm hex bolt Tighten hex bolts using allen key provided.
- Page 8 Assembly Instructions Step 14 Insert 4 x barrel nut into underside of top as shown. Note: ensure that the holes through the barrel nuts are aligned with the screw holes in the edge of the panel. Step 15 Connect middle shelf to right side using 2 x 50mm hex bolt...
- Page 9 Assembly Instructions Step 16 Slide bottom back panel and top back panel into slots of shelves as shown. Step 17 Connect left side exposed ends of shelves and top using 6 x 50mm hex bolt as shown.
- Page 10 Assembly Instructions Step 18 Place drawer completed at Step 6 onto its runners. Step 10 Warning! The unit is heavy. Ask someone to help you with this step. Insert 2 x castor with brake and 2 x castor into bottoms of legs as shown.
- Page 12 If you need help or have damaged or missing parts, call the Customer Helpline: 0845 640 0800 Home Retail Group, 489-499 Avebury Boulevard, Saxon Gate West, Central Milton Keynes, Bucks, MK9 2NW...
