EYDON GLASS TABLE
Assembly Instructions
Before you
start, here is
some helpful
advice
1. We suggest you spend a short time reading through this leaflet and then
follow the simple step by step instructions.
2.If you follow the instructions carefully the end result should be worth the
effort.
3.Do not discard any of the packaging until you have checked that you
have all the parts and the pack of fittings.
4.Assemble this product on a carpet.
5.To ensure an easier assembly, we strongly advise that all fittings are only
finger tightened during initial assembly. Only upon completion of the
assembly should all fixing points be fully tightened.
6.We recommend a periodic check on all fixing points to make
sure they remain fully tightened.
7.Keep glue and fittings out of children's reach.
Note: It will require two people to assemble this item
After-sales telephone number for spare parts
: 0870 600 8990.
