HOME RETAIL GROUP Matrix Desk 619/1645 Assembly Instructions Manual

Hide thumbs

page of 12

/ 12
Bookmarks

Quick Links

Download this manual

Matrix Desk

Assembly Instructions -

Dimensions

Width - 115cm

Depth - 55cm

Height - 75cm

Important -

Please read these instructions fully before starting assembly

If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800

Please keep for future reference

619/1645

619/1638

Issue 1 - 9/04/11

Need help?

Do you have a question about the Matrix Desk 619/1645 and is the answer not in the manual?

Questions and answers

Summary of Contents for HOME RETAIL GROUP Matrix Desk 619/1645

Page 1 Matrix Desk Assembly Instructions - Please keep for future reference 619/1645 619/1638 Dimensions Width - 115cm Depth - 55cm Height - 75cm Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800 Issue 1 - 9/04/11...
Page 2 Cat no.:619/1638(D) (Black Glass) • P/O No: • Imported by: • If the glass is chipped or broken, stop using the product and Home Retail Group. consult the Manufacturer or Supplier. 489-499 Avebury Boulevard. Saxon Gate West. Central Milton Keynes.
Page 3: Components - Parts
Components - Parts If you have damaged or missing components, call the Customer Helpline: 08456 400800 Please check you have all the parts listed below Glass top Glass shelf x 2 (115 x 55 cm) (53.9 x 42.5 cm) Leg x 2 (73 x 5 cm) Support (Short) x 4 (16.5 x 5cm) (Plastic cap one end only)
Page 4 Components - Fittings If you have damaged or missing components, call the Customer Helpline: 08456 400800 Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required.
Page 5 Assembly Instructions Step 1 Attaching threaded rod Warning: With help, carefully p lace glass top upside down onto a clean flat surface. Screw nuts onto the ends of threaded rods Screw threaded rods into the metal discs on the underside of glass Use spanner to fully tighten nuts...
Page 6 The desk is heavy. Lift with care. Assembly is complete. If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800 Home Retail Group. 489-499 Avebury Boulevard. Saxon Gate West. Central Milton Keynes. MK9 2NW...
Page 7 619/1638 Insert Additional Pages If Required.
Page 8 Insert Additional Pages If Required.
Page 9 (16x5cm) (8x5cm)
Page 10 Plastic cap 16pcs Metal plate threaded 6pcs...
Page 11 Screw metal plates threaded into threaded rods Insert Additional Pages If Required. Insert Additional Pages If Required. t Additi If R...
