Hygena Cubic Wood Glass TV Unit
Assembly Instructions
453/7414D
- Please keep for future reference
Dimensions
Width - 120cm
Depth - 40cm
Height - 45.3cm
Important
– Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 03456 400800
Issue 1 - 16/09/15
Advertisement
Related Manuals for HOME RETAIL GROUP Hygena 453/7414D
Summary of Contents for HOME RETAIL GROUP Hygena 453/7414D
- Page 1 Hygena Cubic Wood Glass TV Unit Assembly Instructions 453/7414D - Please keep for future reference Dimensions Width - 120cm Depth - 40cm Height - 45.3cm Important – Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 03456 400800 Issue 1 - 16/09/15...
-
Page 2: Care And Maintenance
Safety and Care Advice Important – Please read these instructions fully before starting assembly • Check you have all the • Do not stand or put weight on • We do not components and tools listed on the product, this could cause recommend the pages 2 &... - Page 3 Components - Panels Please check you have all the panels listed below Left side frame Right side panel Top panel (398 x 435 mm) (398 x 435mm) (1200 x 400 mm) Rear rail Divider Front top rail (539 x 60mm) (380 x 435mm) (1078 x 60mm) Rear panel...
-
Page 4: Tools Required
Components - Fittings If you have damaged or missing components, call the Customer Helpline: 03456 400800 Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required. - Page 5 Assembly Instructions Step 1 Screw 1 Metal dowel into the threaded hole in the Rear panel as shown. Insert Wood dowels into the indicated holes. Step 2 Firmly push Bottom panel onto the dowels , ensuring the Metal dowels wood dowels enter corresponding holes.
- Page 6 Assembly Instructions Step 3 Insert the 1 Metal cam into the hole on the Bottom panel that they are flush. Note: Longer leg of the cross on the Metal Cam must faces towards metal dowel (as shown). Then, using a Philips Screwdriver, screw the Metal cam clockwise...
- Page 7 Assembly Instructions Step 5 Insert the 4 Metal cams into the 4 holes on the panels so that they are flush. Note: Longer leg of the cross on the Metal Cams must face towards end of panels. Then, using a Philips Screwdriver, screw all Metal cams clockwise until they are...
- Page 8 Assembly Instructions Step 7 Note: Longer leg of the cross on the Insert the 4 Metal cams Metal Cams must into the 4 holes on face towards end the panels so that of panel. they are flush. Note: Longer leg of the cross on the Metal Cams must face towards end of panels.
- Page 9 Assembly Instructions Step 9 Insert the 1 Metal cam into the hole on the Rear rail so that they are flush. Note: Longer leg of the cross on the Metal Cam must faces towards metal dowel (as shown). Then, using a Philips Screwdriver, screw the Metal cam clockwise...
- Page 10 Assembly Instructions Step 11 Insert the 5 Metal cams into the 5 holes on the panels that they are flush. Note: Longer leg of the cross on the Metal Cams must face towards end of panels. Then, using a Philips Screwdriver, screw all Metal cams clockwise until they are...
- Page 11 Assembly Instructions Step 13 Insert the 2 Metal cams into the 2 holes on the Front and rear rails so that they are flush. Note: Longer leg of the cross on the Metal Cams must face towards end of rails. Then, using a Philips Screwdriver, screw all Metal cams...
- Page 12 Assembly Instructions Step 15 Insert the 8 Metal cams into the 8 holes on the side panels, dividers and rear rail so that they are flush. Note: Longer leg of the cross on the Metal Cams must face towards metal dowels. Then, using a Philips Screwdriver, screw all Metal cams...
- Page 13 Assembly Instructions Step 17 Screw Handle to the pre-drilled holes in the rear face of the Door using 12mm Screws Front Screw Hinges to the pre-drilled holes in the rear face of the Door using 14mm Screws Step 18 Locate the Door onto the Right side panel , screw...
- Page 14 Re-tighten screws. Assembly is complete. If you need help or have damaged or missing parts, call the Customer Help Line: 03456 400800 Home Retail Group plc. Avebury, 489-499 Avebury Boulevard. Milton Keynes. MK9 2NW...
