Winchester - 3 Door 4 Drawer Wardrobe
Assembly Instructions
Dimensions
Width - 126.3cm
Depth - 52cm
Height - 184.5cm
Important
– Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline:
- Please keep for future reference
656/7035
656/6988
0870 160 1490
Issue 1 - 10/03/10
Advertisement
Related Manuals for HOME RETAIL GROUP Winchester 656/7035
Summary of Contents for HOME RETAIL GROUP Winchester 656/7035
- Page 1 Winchester - 3 Door 4 Drawer Wardrobe Assembly Instructions 656/7035 - Please keep for future reference 656/6988 Dimensions Width - 126.3cm Depth - 52cm Height - 184.5cm Important – Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 0870 160 1490 Issue 1 - 10/03/10...
-
Page 2: Care And Maintenance
Safety and Care Advice Important – Please read these instructions fully before starting assembly • Check you have all the • Do not stand or put weight on • We do not components and tools listed on the product, this could cause recommend the pages 2, 3 and 4. - Page 3 Components - Panels If you have damaged or missing components, call the Customer Helpline: 0870 160 1490 Please check you have all the panels listed below Top panel x 1 (126.3 x 52cm) Right side panel x 1 Left side panel x 1 Bottom panel x 1 (49.5 x 182.2cm) (49.5 x 182.2cm)
- Page 4 Components - Panels Please check you have all the panels listed below Large horizontal partition Small horizontal partition Small drawer back x 2 (31.3 x 10cm) shelf x 1 shelf x 1 (75 x 48.4cm) (35.7 x 48.4cm) Small drawer base x 2 Shelf x 2 Small drawer front x 2 (35.6 x 47.6cm)
-
Page 5: Tools Required
Components - Fittings Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required. Feet x 4 8/30mm Wooden dowel x 48 6/30mm Wooden dowel x 16 Nail x 50 9mm Screw x 16... - Page 6 Assembly Instructions Step 1 Attaching runners Position left runner Left side and right runner A on to the drilled holes of the left and right side panels the left side of vertical partition wall Fix through holes shown using screws Turn over the vertical partition wall attach runners A...
- Page 7 Assembly Instructions Step 3 Attaching horizontal partition shelves to the vertical partition wall Insert wooden dowels into the vertical partition wall , place horizontal partition shelves on to the screws align correctly and insert large locking nuts into the drilled holes and turn them clockwise to lock.
- Page 8 Assembly Instructions Step 5 Frame assembly Insert screws in to the frames Attaching runners Step 6 Position runners 15mm in from front edge of the left side panel Insert wooden dowels as shown, align correctly Slide top of the runners and insert large locking back.
- Page 9 Assembly Instructions Step 7 Attaching the frame Insert wooden dowels into the edge of the left and right side panels Align correctly and insert large locking nuts into left and right side panels and bottom panel , place the frame and turn locking nuts clockwise to lock.
- Page 10 Assembly Instructions Step 10 Drawer assembly Insert screws into large or small drawer front Insert wooden dowels in to large or small drawer front and place left and right drawer sides Slide large or small drawer base iinto the grooves. Place large or small drawer back onto sides.
- Page 11 Assembly Instructions Step 10 - continued Large drawers only: Position 2 drawer base supports onto the underside of the large drawers as shown. Fix using supplied screw. All drawers: Attach handles to drawer fronts using screws Step 11 Placing shelves With help, carefully stand wardrobe upright.
- Page 12 Assembly Instructions Step 14 Position 2 door hinges into left, middle mirror and right doors , fix using supplied screws. Step 15 Attaching handles to the doors Attach handles doors using screws Repeat this step with all doors Warning: The mirror door. Handle with care.
- Page 13 Assembly is complete. If you need help or have damaged or missing parts, call the Customer Helpline: 0870 160 1490 Home Retail Group Plc, 489 - 499 Avebury boulevard, Milton Keynes, MK9 2NW...
