Summary of Contents for Lumens VC-A50S
- Page 1 VC-A50S PTZ Video Camera Installation Guide - English [Important] To download the latest version of Quick Start Guide, multilingual user manual, software, or driver, etc., please visit Lumens http://www.MyLumens.com...
-
Page 2: Table Of Contents
Setting Menu .................. 23 Chapter 6 Descriptions of Major Functions ..........31 I would like to switch to VC-A50S ........... 31 I would like to save the current lens position data ......31 ... - Page 3 I would like to adjust the focal length ..........32 I would like to adjust the AF speed ..........32 I would like to set the image mode ..........33 6.10 I would like to freeze images ............33 ...
-
Page 4: Copyright Information
Inc. Copying, reproducing or transmitting this file is not allowed if a license is not provided by Lumens Digital Optics Inc. unless copying this file is for the purpose of backup after purchasing this product. In order to keep improving the product, Lumens Digital Optics Inc. hereby reserves the right to make changes to product specifications without prior notice. -
Page 5: Chapter 1 Safety Instructions
Chapter 1 Safety Instructions Always follow these safety instructions when setting up and using the HD Camera: 1. Use attachments only as recommended. 2. Use the type of power source indicated on the HD Camera. If you are not sure of the type of power available, consult your distributor or local electricity company for advice. -
Page 6: Precautions
Precautions Warning: To reduce the risk of fire or electric shock, do not expose this appliance to rain or moisture. If HD Camera will not be used for an extended time, unplug it from the power socket. Note Risk of Electric Shock Please do not open it by yourself Caution: To reduce the risk of electric shock, do not remove cover (or back). -
Page 7: Kcc Warning
KCC Warning A 급 기기 이 기기는 업무용(A 급) 전자파적합기기로서 판매자 또는 사용자는 이 점을 주의하시기 바라며, 가정 외의 지역에서 (업무용 방송통신기자재) 사용하는 것을 목적으로 합니다. English - 6... -
Page 8: Chapter 2 Package Contents
Chapter 2 Package Contents Instruction for VC-A50S Remote Control installation Power Cord Power Adapter RS-422 Connector Appearance may vary depending on country/region Metal Plate A Metal Plate B M3 Screws English - 7... -
Page 9: Chapter 3 Product Overview
Chapter 3 Product Overview 3.1 Overview Front View Back View 1. Camera lens 2. Power LED indicator 3. Standby LED indicator 4. DVI output 5. Component output 6. Power input 7. IR SELECT 8. OUTPUT Switch 9. Camera Address Selectors 10. -
Page 10: Chapter 4 Instruction For Installation
Please contact the supplier for any shortage, and make sure to keep the accessories in the box intact. 4.1.3 Please choose a proper place for installation of VC-A50S in advance. Please determine an installation place according to the following requirements 4.1.1.1 Confirm the position for the object to be captured. - Page 11 4.2.2 I would like to install VC-A50S on the ceiling 4.2.2.1 Prepare for the parts and equipment required during the installation 1. Accessories of VC-A50S in the box (metal plates A, B and M3 screw x 7) 2. Screw for locking on ceiling mounted hanger x 4 3.
- Page 12 4.2.2.2 Camera Size Length x Width x Height : 174 x 186 x 182.7 mm Weight : 2.0 Kg English - 11...
- Page 13 4.2.2.3 Max. rotation dimension of camera English - 12...
- Page 14 4.2.2.4 Size Diagram 1. Metal plate B - ceiling side Metal plate B locking screw Metal plate B locking bolt M3 threaded hole M3 threaded hole M3 threaded hole Metal plate B - ceiling side English - 13...
- Page 15 2. Metal plate A - machine side Metal plate A locking screw Metal plate A - machine side English - 14...
- Page 16 3. Bottom of machine English - 15...
- Page 17 4.2.2.5 Precautions for installation 1. Before installation, please confirm the orientation of the machine relative to the object to be captured 2. It is recommended that the machine should be set at a distance of more than 1 meter away from the object to be captured. Please adjust for a best distance according to the magnification of the lens 1 meter↑...
- Page 18 3. Lock the metal plate B on ceiling mounted hanger ※Caution: (1) Please use the hanger that has obtained UL security approval (2) Please reserve the hole for the connecting wires of the camera 4. Combine the metal plate A and the metal plate B (1) Push the metal plate A up to the ceiling and then to the right to latch the metal plate B (2) Fix with 3 M3 screws...
- Page 19 4.2.2.7 How to remove 1. Remove the connecting wires from the camera 2. Uninstall the camera together with the ceiling, loosen the three screws that fix the metal plates A and B and push to the left to remove the machine 3.
-
Page 20: Connecting The Device
4.3 Connecting the device 4.3.1 Image Output Connecting to an HDTV/computer monitor (DVI) 4.3.1.1 DVI cable Monitor or HDTV Connecting to a TV (C-Video) 4.3.1.2 C-Video Cable English - 19... - Page 21 Connecting to an HDTV (3G-SDI) 4.3.1.3 SDI Cable HDTV Connection to the device for image output 4.3.1.4 Component adaptor HDTV English - 20...
- Page 22 4.3.2 Controlling VCs with the computer Connecting to one computer for connection between VCs 4.3.2.1 (RS-232 in/out) <Remark> With RS-232 in/out, at most 7 VCs can be connected. Connecting to one computer for connection between VCs 4.3.2.2 (RS-422) <Remark> Please refer to 7.2 RS-422 connection for the RS-422 connection instructions.
-
Page 23: Chapter 5 Remote Control And Setting Menu
<Remark> The below functions are listed alphabetically. Item Description ,,, Move the lens Back Light Turn on/off back light compensation Camera Select 1 ~ 3 VC-A50S select Focus- Turn on manual focus to adjust the Manual / focal length Far/Near Focus-Auto... -
Page 24: Setting Menu
5.2 Setting Menu <Remark> Press [Menu] on the remote control to enter the setting menu; the bold underlined values in the following table are defaults. Level Level Minor Level Function Descriptions Major Items Items Adjustment Values Auto Brightness Mode Shutter Pri Exposure mode setting Iris Pri Manual... - Page 25 1/180 1/150 1/125 1/120 1/100 1/100 1/90 1/75 1/60 1/50 1/30 1/25 1/15 1/12 F1.6 F2.4 F2.8 F3.4 F4.8 Iris Pri Iris setting F5.6 F6.8 10. F8 11. F9.6 12. F11 13. F14 14. Close English - 24...
- Page 26 3.4 dB 6.8 dB 10.2 dB 13.7 dB 17.1 dB 20.5 dB Manual Gain 23.9 dB Manually set the gain 27.3 dB 10. 30.7 dB 11. 34.1 dB 12. 37.5dB 13. 41dB 14. 44.4 dB 15. 47.8 dB 60/30 50/25 mode mode 1/10000...
- Page 27 1/30 1/25 1/15 1/12 F1.6 F2.4 F2.8 F3.4 F4.8 Manual Iris Manually set the aperture F5.6 F6.8 10. F8 11. F9.6 12. F11 13. F14 14. Close Bright 1~ C~28 10.2 dB 13.7 dB 17.1 dB 20.5 dB 23.9 dB 27.3 dB Max.
- Page 28 Auto Indoor Outdoor Trigger White Balance Auto White Select the color temperature Balance Mode mode Manual Outdoor Auto Sodium Lamp Auto White Sodium Lamp Balance 10. Sodium Lamp Outdoor Auto One Push ENTER One push trigger Trigger Adjustable when the white R-Gain 0~ C~255 balance mode is set to...
- Page 29 Adjustable when the image 0~ A ~14 mode is set to Custom mode 1. 1 Adjustable when the image Gamma mode is set to Custom mode 2. 2 Adjustable when the image Brightness 0~ A ~31 mode is set to Custom mode Contrast adjustment;...
- Page 30 1. Normal 2. 1 3. 2 Focus speed after AF AF speed 4. 3 triggering 5. 4 6. 5 NTSC LB NTSC CP NTSC SQ C-Video Image mode PAL LB PAL CP PAL SQ DVI/SDI Video Type Select video output type YPbPr Turn on/off the prompt Prompt...
- Page 31 1. 1920x1080/60p 2. 1920x1080/50p 3. 1920x1080/30p 4. 1920x1080/25p 5. 1920x1080/60i 6. 1920x1080/50i 7. 1280x720/60p Output Mode 8. 1280x720/50p 9. 1280x720/30p 10. 1280x720/25p 11. 1080/59.94p 12. 1080/59.94i 13. 1080/29.97p 14. 720/59.94p 15. 720/29.97p Resume the factory default Factory Reset On / Off setting Display the current setting Status...
-
Page 32: Chapter 6 Descriptions Of Major Functions
Chapter 6 Descriptions of Major Functions 6.1 I would like to switch to VC-A50S 1. Press [Camera 1 ~ 3] on the remote control to select VC-A50S. Camera 1 ~ 3 is selected with IR SELECT. 6.2 I would like to save the current lens position data 1. -
Page 33: I Would Like To Zoom In/Out Images
6.6 I would like to zoom in/out images 6.6.1 Adjust image size 1. Press [Fast +] on the remote control to zoom in images. 2. Press [Fast -] on the remote control to zoom out images. 6.6.2 Fine-tune image size 1. -
Page 34: I Would Like To Set The Image Mode
4. Press [] or [] to select [AF Sensitivity]. 5. Press [ENTER] to activate. 6. Press [] or [] to select [High / Medium / Low]. 7. Press [MENU] to exit. 6.8.2 Adjust the AF speed The focus speed upon triggering AF Sensitivity ... -
Page 35: I Would Like To Change The Camera Direction
6.12 I would like to change the camera direction 1. Press [L/R Direction Set] on the remote control to switch [L/R Direction/Disable/Normal]. 6.13 I would like to display the current status 1. Press [Info] on the remote control to display the current status information. -
Page 36: Chapter 7 Dip Switch Setting
Chapter 7 DIP Switch Setting <Note> Please turn off the machine before changing DIP switch setting. 7.1 DIP SWITCH 7.1.1 OUTPUT Swtich Output Mode Setting Output Mode Setting 1920x1080/60p 1920x1080/50p 1920x1080/30p 1920x1080/25p 1920x1080/60i 1920x1080/50i 1280x720/60p 1280x720/50p 1280x720/30p 1280x720/25p 1920x1080/59.94p 1920x1080/59.94i 1920x1080/29.97p 1280x720/59.94p 1280x720/29.97p... - Page 37 7.1.2 IR SELECT Setting 7.1.3 Camera Address Selector Setting Function Descriptions ID 0~7 Reserved 7.1.4 System Switch Setting Function Descriptions RS-232C/RS-422 selector DIP 1 OFF : RS-232C / ON : RS-422 Infrared signal output switch DIP 2 OFF : Off / ON : On Communication baud rate selector DIP 3 OFF : 9600 / ON : 38400...
-
Page 38: Rs-422 Connection
7.2 RS-422 Connection 7.2.1 RS-422 Pin Description Pin NO. Function RXD OUT - RXD OUT + TXD OUT - TXD OUT + RXD IN - RXD IN + TXD IN - TXD IN + <Note> Please connect IN+ to OUT+ when connecting to SONY products For non-SONY products, it may be necessary to connect IN+ to OUT- 7.2.2 Use RS-422 Connection 1. - Page 39 2. Peel off a section of copper wire (AWG Nos. 28 to 18) and insert it into the connector hole; then use flat screw driver to fix it 3. Insert the wired RS-422 connector back to the camera. Now the connection is completed <Note>...
-
Page 40: Chapter 8 Troubleshooting
Chapter 8 Troubleshooting This chapter describes problems you may encounter while using VC-A50S. If you have questions, please refer to related chapters and follow all the suggested solutions. If the problem still occurred, please contact our distributors or service center. - Page 41 The device cannot 1. Please consult the distributor to make sure the be controlled with firmware version is the latest one. The steps to Codec check version is as follows: 1.1 Press [MENU] on the remote control 1.2 Choose [Status] 1.3 Go to Page 5 of [System] 1.4 Make sure the firmware version is correct.
