Chapter 3. Operation
.
Online
No Response The module is enabled but is not
Empty
Offline
Offline /
No Response
Not Ready

MODEM-16 MODULE SUBMENUS

Figure 3-2 shows the Menus submenus for the Modem-16 Module. The following
sections describe these options.
3-4

Table 3-2. Modem-16 Module Status Menu Messages

Message
The module is enabled and is respond-
ing to the system controller's status
polls.
responding to the system controller's
status polls.
The system controller has not detected
the presence of a module in the option
slot, nor has a module been manually
enabled for this option slot.
The module is installed but has been
taken Offline by a user.
The module is installed but has been
taken Offline by a user. The module is
not responding to polls.
The module is installed and performing
startup initialization of the modems.

Figure 3-2. Menus Panel

Modem-16 Module User Manual
Modem-16 Module Submenus
Meaning Comments
This is the normal response of
the system.
This response indicates either a
problem in the system or the
module is not installed.
The module is still responding
to controller polls.
This response indicates either a
problem in the system or the
module is not installed.
The initialization of the
Modem-16 should take less
than two minutes.
61200181L1-1
