7 Troubleshooting
7.1 Fault code output
The heater will output a fault code on the control
element if a fault occurs during heating mode.
Pressing the quick start button confirms the error
X X
display.
An error that has occurred is shown on the control
element display as Txx, Fxx or Hxx and the quick
start button flashes red. The error information is
stored in the error memory. Stored errors can be
shown in the menu under "Settings".
You will find further information in the operating
instructions.
Table of internal control element errors "Txx"
Fault code Faults
Ted Supply voltage too high
Te3 Display background illumination faulty
Te4 Defective LED status
T12 Communication error on the W-bus
Te7/Te8 -
Tea Faulty feedback signal from heater (ST)
Tec Control knob sticking
T46 Excess current/short circuit at switch output
Te0 Reduced voltage
T84 Operating voltage too low
Te1 Ambient temperature too low or too high
Teb RTC fault
Tee -
Errors relating to a connected heater
Fault code Faults
F01 to F15
Heater error (analogue)
F01 to F99
H01 to Hxx Heater error (W-bus)
UniControl
www.butlertechnik.com
Fault description
Supply voltage exceeds 36V.
-
-
-
-
Control knob pressed for longer than 10 seconds.
Current exceeds 500mA.
Supply voltage is below value set by technician.
Supply voltage is less than 8V.
Ambient temperature is outside the operating range
of -20°C to +70°C.
-
-
Fault description
See workshop manual for heater
www.butlertechnik.com
Troubleshooting
Check car electrical installation.
Contact Webasto service workshop
Check installation.
Contact Webasto service workshop
Check installation.
Contact Webasto service workshop
Check installation. Ensure that the consumer at the
switch output is not drawing more than 500mA.
Charge the battery and check car electrical instal-
lation.
The error disappears automatically when the
ambient temperature is once more within the range
of -20°C to +70°C.
In case of voltage interruption lasting more than 8
minutes: Enter day/time again.
If this error appears without voltage interruption:
Contact Webasto service workshop
Contact Webasto service workshop
Troubleshooting
Contact Webasto service workshop
