About this document

1.1

Purpose of the document

These installation instructions are part of the device and contain
all the information required to ensure correct and safe installation.
1.2

Enclosed documents

All documents are provided on the enclosed DVD and are available
from http://dealers.webasto.com.
Printed copies of the following documents are enclosed with this
unit:
■ Quick Start Guide
■ Information Sheet for Initial Start-up
1.3

Using this document

Print out these Installation Instructions as required.
X X
Read these Installation Instructions before installing the unit.
X X
Read the operating instructions before operating the unit.
X X
1.4

Use of symbols and highlighting

Texts with the symbol refer to separate documents which are
enclosed or can be requested from Webasto.
Texts with the symbol
Texts with the symbol or
damage, risk of accident or injury.
Highlight Explanation
Requirements for the following necessary action
3
Necessary action
X X
UniControl
www.butlertechnik.com
refer to technical features.
refer to possible material
www.butlertechnik.com
2

Safety

2.1 Qualifications of installation person-
nel
The installation personnel must have the following qualifications:
■ Successful completion of Webasto training
■ Corresponding qualification for working on technical systems
2.2

Regulations and legal requirements

Read and follow the operating instructions before starting up
X X
the heater.
Directives Type-approval numbers for UniControl
EMC Directive ECE R10
The regulations of these guidelines are binding in the scope of the
Directive 70/156/EEC and/or 2007/46/EC (for new vehicle models
from 29/04/2009) and should also be observed in countries in which
there are no special regulations. Failure to follow the installation
instructions will result in the invalidation of the type approval for
the heater and therefore invalidation of the general homologation
of the vehicle. For vehicles with an EU type approval, an entry is not
required in accordance with § 19 section 4 of appendix VIII b of
StVZO. Country-specific registration regulations must be complied
with.
Intended use
The control element UniControl is used to operate the Webasto
water or air heaters for cabin and engine preheating.
The control element UniControl is currently approved for connection
to certain Webasto water or air heaters.
DANGER
■ Do not operate the heater in closed rooms due to
the danger of poisoning and suffocation.
■ Always switch off the heater before refuelling.
■ The improper operation, installation or repair of
Webasto heaters and control elements can cause fire
or the leakage of deadly carbon monoxide. This can
lead to serious injury or death.
■ Webasto shall not assume liability for defects or
damage that are the result that the installation and
operating instructions as well as the instructions
contained therein being disregarded.
This liability exclusion particularly applies for:
■ installation by untrained personnel
■ improper use
■ repairs not carried out by a Webasto service
workshop
■ use of non-genuine parts
■ Conversion of the heater without permission from
Webasto
■ If faulty always replace the complete control ele-
ment.
