Summary of Contents for Furniture of America Claren CM-BK939QQ
- Page 5 Align the HB down connect bar (#12) to the HB support bars (#1), then insert 2 bolts (#F) into each side and secure using the Allen wrench. Align the upper end rail (#11) to the HB support bars (#1), then insert 2 bolts (#A) into each side and secure using the Allen wrench.
- Page 6 Align the slats according to the image on the left, and insert a bolt (#B) into each pre-drilled hole. Secure using the Allen wrench (#H). 4-1,4-2. Align each end of the support bar (#11) to the top and bottom beds, then insert a bolt (#D) into each end and secure using the Allen wrench (#H).
- Page 7 Align the ladder, then insert a bolt (#D) into each end and secure using the Allen wrench. Align the slat support legs (#13) to the holes along the center of the bottom bed, then insert the bolts (#C) from the top and secure using the Allen wrench (#H).
