Sunblind Control

CHAPTER 7
Sunblind Control
The main controls for sunblinds can be found here. The center graphic displays the current sunblind
vertical position.
Icon Description
Tap to select the desired sunblind rotational angle between 0 and 180 degrees. Availability of some
rotational angles may be limited to the programmed settings.
Tap and hold the slider icon to adjust the position of the sunblinds. Alternatively, you can tap a position on
the slider to jump to that position.
Auto OFF / ON
The Auto icon toggles automatic mode ON. To turn Auto mode OFF, adjust the sunblind slider or the
rotational angle. The auto function parameters are configured using EC- gfx Program. See the EC-
gfx Program User Guide for more information.
Tap the sunblind groups icon to access the sunblind group controls.
