Temperature Control - Distech Controls Allure UNITOUCH User Manual

Temperature Control

CHAPTER 5
Temperature Control
The main temperature settings can be adjusted here. Ambient temperature is displayed in the middle
of the screen.
Depending on the programming with EC- gfx Program, temperature will be displayed in either Absolute
or Relative mode. Shown below is Absolute mode.
Icon Description
Tap and hold the slider icon to adjust the temperature setpoint. Alternatively, you can tap a position on the
slider to jump to that position.
The percent humidity is indicated here (only available on models equipped with a humidity sensor).
The measured carbon dioxide level (in ppm) is indicated here (only available on models equipped with a
CO sensor).
2
The temperature setpoint and heating/cooling mode is displayed here. Depending on the chosen
programming, the setpoint offset may be displayed instead.
14 Allure UNITOUCH™
