Rocstor Y10C137-B1 User Manual

USB(3.0) Type-A to Gigabit Ethernet Network Adapter
Mac & PC Compatible – Black
Congratulations
Thank you for purchasing this premium Rocstor Product. For optimum performance and
safety, please read these instructions carefully before connecting, operating or using this
product. Please keep this manual for future reference.
Introduction
Rocstor Gigabit to USB 3.0 Ethernet Adapter allows your computer to instantly connect
to a 10/100/1000 Mbps network through a USB port - no need to open up your
computer case to add an internal Ethernet card. The adapter's compliance with USB 3.0
(5 Gbps) ensures true 10/100/1000 Mbps network speed without any compromise.
Furthermore, the adapter is compact and is USB bus-powered; requires no external
power adapter.
• Supports 10/100/1000BASE-T Networks
• USB 3.0 Type-A Interface
• Integrated 7.1" USB Cable
• LED Status Indicators
• USB Bus-Powered
• Windows, Mac, Chrome & Linux Compatible
Package Contents
Before attempting to use this unit, please check the packaging and make sure
the following items are contained in the Packaging:
• Main unit x1
• User Manual x1
Package Contents
• USB enabled computer system with available USB 3.0 port
• Windows® 8 (32/64bit), 7 (32/64), Vista(32/64), XP(32/64)
Windows® Server 2008 R2, 2003(32/64)
• Mac OS 10.6 - 10.8
• Linux Kernel 2.6.25 - 3.5.0
How to Use
User Manual
Y10C137-B1
®
Features
Upstream:
USB(3.0) Type-A Male
(Connect to host computer)
Downstream:
RJ45 Female
• Supports 10/100/1000Mbps bandwidth
for RJ45 port
Features:
Cabling Type: Ethernet 1000Base-T, Ethernet 100Base-TX, Ethernet 10Base-T
Compliant Standards: IEEE 802.3 , IEEE 802.3u , USB 1.1 , USB 2.0 , USB 3.0
Connectivity Technology: Wired
Data Link Protocol: Ethernet, Fast Ethernet, Gigabit Ethernet
Data Transfer Rate: 1 Gbps
Features: Full duplex mode , Half duplex mode , USB powered
Compatibility: Mac , PC
Speci cation
Input / Output Connector
Input
Output
Warranty
Limited Warranty
Environmental
Operating Temperature
Operating Humidity
Storage Temperature
Storage Humidity
Mechanical
Size (D-H-W)
Weight (Net)
Accessories
User Manual
How to Use
Windows
Connect the USB 3.0 Network Adapter to an available USB port. Insert the provided
CD into your DVD/CD-ROM drive. Click on the appropriate version of your windows
folder. Run the Setup.exe application from the Autoplay menu. If Autoplay is disabled
on your system, browse to your CD/DVD drive and run the application. Follow the
on-screen instructions to complete the installation.
Mac OS
Connect the USB 3.0 Network Adapter to an available USB port. Insert the provided
CD into you DVD/Cd-Rom drive. Browse to the "USB3.0 Gigabit Ethernet Driver" folder
on the CD. Open the "Mac Driver\Realtek Mac Driver" folder and run the
"RTUNICv1.0.16.pkg" application to start the install. Follow the on-screen instructions
to complete the installation.
NOTE: You may be prompted to restart once the install completes.
USB(3.0) Type-A Male x1
RJ45 X1
2 Year
0°C to + 45°C - (32°F to + 113°F)
10% to 85 % RH (no condensation)
-10°C to + 70°C - (14°F to + 158°F)
5% to 90 % RH (no condensation)
(0.6"x2.6"x0.9") - 15.2x 66 x22.8 mm
30g - (1.06oz)
English Version
