OPERATING INSTRUCTIONS

CONTROL PANEL
1. Display: Displays current setting/program, etc.
2. Start/Pause and On/Off: Press to Start or Pause a program. Press and hold for 3 seconds to turn unit on or
off.
3. Program Selection and Cancel Button: Press to select desired wash program or press and hold for 3 seconds to
cancel the current program.
4. Half Load Button: Press to select Half Load program for upper or lower basket.
" " lights to indicate an Upper Basket Half Load, and " " lights to indicate a Lower Basket Half Load.
5. Delay Timer Button: Press to select Delay Timer.
6. Options Button: Press to select desired additional functions.
7. Options Indicator LEDs (Sanitize, Extra Fast, Extra Dry, Hi-Temp)
8. Rinse-Aid Indicator LED
OPERATING THE DISHWASHER
PREPARING TO WASH
1. Open the door of the dishwasher.
2. Place the dishes in accordance with the instructions in the user manual.
3. Make sure that the upper and lower impellers rotate freely.
4. Put an adequate amount of detergent into the detergent dispenser.
5. Check the Rinse Aid indicator light and add rinse aid if needed.
PROGRAM SELECTION
1. Press the On/Off key to turn on the dishwasher. The door should be in the Open position.
2. Refer the "Programs Table" on page 19 to determine the washing program.
3. Press program selection key until the number of the program you selected appears on the display.
• 1 – Regular
• 2 – Auto
• 3 – Intensive Plus
• 4 – Intensive
In order to start the selected program, the Start/Pause button must be pressed and the door of the dishwasher
must be closed within 4 seconds after pressing Start/Pause.
1
7 8
• 5 – Daily
• 6 – Delicate
• 7 – Super
• 8 – Rinse
16
2 3 4 5
Start / Pause Program Half Load Delay
On/Off Cancel Cancel
(Hold 3 sec.) (Hold 3 sec.) (Hold 3 sec.)
Figure 17
6 7
Hi-Temp
O Sanitize O
O Ext. Fast O Rinse Aid
Extra Dry
O
Options
Hi-Temp
(Hold 3 sec.)
8
