Reference Ets-Parameter; Setup General - MDT SCN-RT1UP.01 Technical Manual

Technical Manual
Room Temperature Controller

4 Reference ETS-Parameter

4.1 Setup general

The following settings are available:
Figure 5: General settings
The chart shows the dynamic range of the general settings:
ETS-text
Startup delaytime
Table 2: General settings
Startup delaytime
This time defines when the unit "boots up" after a restart (reset, reprogramming, bus voltage return).
This can be important if, for example, a bus reset is carried out. If there are many units on a line, all
units would start at the same time and load the bus. With a variable time, the units can thus start
differently.
The SCN-TS1UP.01 is a pure temperature sensor, which does not contain of any controller functions.
Therefore, only the menus
can be configured.
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 • Germany
9
Phone: +49-2263-880 • knx@mdt.de • www.mdt.de
[SCN-RT1xPx.01]
Dynamic range
[default value]
0 – 60 s
[0]
4.2 Temperature measurement
Comment
Time that elapses between bus
voltage return and functional start of
the device.
and 4.3 Alarm/Messages are shown and
