  • Page 1 Operations/ Medical Maintenance Manual Stretcher Scales Option Important Information File in your For parts or technical maintenance assistance call records 800 327 0770 (option 2)

  • Page 2: Table Of Contents

    Table of Contents Introduction Specifications ................Warning / Caution / Note Definition .
  • Page 3 Table of Contents Assembly Drawings and Parts Lists (Continued) 1731 Litter Assembly ..............73−77 1231Z Litter Assembly .

  • Page 4: Introduction

    Introduction DESCRIPTION OF SYSTEM Provides a measurement of patient weight in pounds and kilograms by utilizing load cell technology. SPECIFICATIONS Optional Scale System Weight Operating Range 0 lbs. to maximum capacity of the stretcher Optional Scale System Accuracy Between 10° Trend & 10° reverse Trend*  2 lbs.

  • Page 5: Symbols

    Symbols Warning, Refer to Service/Maintenance Manual Internally Powered Mode of Operation: Continuous IPX5 Electromagnetic Interference − product conforms to IEC 60601−1−2:1993 − Class B Ref: 1070 Stretcher Scale Type: 4 x AA Battery (4 x 1.5VDC) Voltage: 6.0VDC Medical Equipment Classified by Underwriters Laboratories Inc. with Respect to Electric Shock, Fire, Mechanical and Other Specified Hazards Only in Accordance with UL 2601−1 and CAN/CSA C22.2 No.

  • Page 6: Scale System Operation

    If the system is functional, “Good” will display and the scale system is ready to use. If the malfunction is still present, the display shows “Err” again. Call Stryker technical support at 800−327−0770. For the most accurate results, weigh the patient with the litter at zero degrees of Trend.

  • Page 7: Scale System Batteries

    Scale System Operation SCALE SYSTEM BATTERIES NOTE To avoid completely draining the batteries and having the optional scale system shut down, replace the batter- ies whenever only one of the charge indicator bars on the display is black (see page 5 for an example). 1.

  • Page 8: Cleaning

    If these types of products are used to clean Stryker patient handling equipment, measures must be taken to insure the stretchers are rinsed with clean water and thoroughly dried following cleaning. Failure to properly rinse and dry the stretchers will leave a cor- rosive residue on the surface of the stretcher, possibly causing premature corrosion of critical components.

  • Page 9: Checklist

    Preventative maintenance should be performed at a minimum of annually. A preventative maintenance pro- gram should be established for all Stryker Medical equipment. Preventative maintenance may need to be performed more frequently based on the usage level of the product.

  • Page 10: Service Information

    2 and 3 of the following procedure. Do not place unprotected circuit boards on the floor. All circuit boards returned to Stryker should be shipped in the static shielding bags the new boards were shipped in. Static Protection Procedure 1.

  • Page 11: Scale Display Box Replacement

    Service Information SCALE DISPLAY BOX REPLACEMENT Required Tools: Wire Cutters 1/2” Open End Wrench Phillips Screwdriver Torque Wrench 1. Pump the litter up to full height. 2. Using wire cutters, cut all the cable ties holding the load cell cables to the litter frame. 3.

  • Page 12: Scale Display Battery Holder Replacement

    Service Information SCALE DISPLAY BATTERY HOLDER REPLACEMENT Required Tools: Utility Knife Phillips Screwdriver Static Protection Equipment Heyco Pliers 1. Properly ground yourself (see page 2. Using a utility knife, pry up a corner of the display label and remove the label from the upper display cover. 3.

  • Page 13: Load Cell Replacement

    8. Grease the ends of the new load cell using Syntec grease (Stryker part number 3000−200−700). 9. Reverse steps 1−6 to install the new load cell. Torque the two bolts holding the load cell to 20 $3 ft./lbs.
  • Page 14 7. Grease the ends of the new load cell using Syntec grease (Stryker part number 3000−200−700). 8. Reverse steps 1−5 to install the new load cell. Torque the two bolts holding the load cell to 20 $3 ft./lbs.

  • Page 15: Scale System Diagnostics

    Service Information SCALE SYSTEM DIAGNOSTICS 1. To enter diagnostic mode, hold all three buttons on the display box for at least 6 seconds until the display reads diag. Press the zero button to toggle down between the diagnostic functions listed below and press the lb / kg button to toggle up between functions.
  • Page 16 Service Information SCALE SYSTEM DIAGNOSTICS (CONTINUED) Scale Calibration: Calibrate the scale system with a known weight of approximately 200 pounds. 1. Remove all items from the stretcher except the mattress and other items used during the patient’s stay. 2. After going to the calibration menu in diagnostics, hold the zero and lb / kg buttons for two seconds to zero the stretcher.

  • Page 17: Quick Reference Replacement Parts List

    Quick Reference Replacement Parts List Display Lens Kit ............. 1070−700−011 Display Upper Housing Kit .
  • Page 18 Litter Assembly with Scale System Assembly part number 0660−330−010 (reference only)
  • Page 19 Litter Assembly with Scale System...
  • Page 20 Litter Assembly with Scale System...
  • Page 21 Litter Assembly with Scale System TOP VIEW...
  • Page 22 Litter Assembly with Scale System Item Part No. Part Name Qty. 0003−355−000 Hex Hd. Cap Screw 0003−356−000 Hex Hd. Cap Screw 0003−357−000 Hex Hd. Cap Screw 0003−358−000 Hex Hd. Cap Screw 0007−071−000 Truss Hd. Mach. Screw 0004−330−000 Socket Hd. Cap Screw 0007−058−000 Torx Screw 0013−010−000...
  • Page 23 Litter Assembly with Scale System and Zoom Assembly part number 0660−530−010 (reference only)
  • Page 24 Litter Assembly with Scale System and Zoom...
  • Page 25 Litter Assembly with Scale System and Zoom...
  • Page 26 Litter Assembly with Scale System and Zoom Communication Coil Cord from Base...
  • Page 27 Litter Assembly with Scale System and Zoom TOP VIEW...
  • Page 28 Litter Assembly with Scale System and Zoom Item Part No. Part Name Qty. 0003−355−000 Hex Hd. Cap Screw 0003−359−000 Hex Hd. Cap Screw 0007−071−000 Truss Hd. Mach. Screw 0004−330−000 Socket Hd. Cap Screw 0007−058−000 Torx Screw 0013−010−000 Ext. Tooth Lock Washer 0014−021−000 Washer 0015−027−000...

  • Page 29: 29" Zoomr Handle Assembly

    29” Zoom Handle Assembly Assembly part number 1040−050−029 (reference only) Load Cell Cable Communication Cable From Electronics Box...
  • Page 30 29” Zoom Handle Assembly Item Part No. Part Name Qty. 0023−288−000 Hex Washer Hd. Screw 0003−367−000 Hex Hd. Cap Screw 0013−019−000 Ext. Tooth Lock Washer 0013−038−000 Ext. Tooth Lock Washer 0023−305−000 Hex Washer Hd. Screw 0028−196−000 External Retaining Ring 1040−050−108 Pivot Bolt 1001−226−016 Pivot Bearing...

  • Page 31: Right Handle Grip Assembly

    1040−050−030 Right Handle Grip Assembly See Detail A WIRE ROUTING DETAIL A WIRE ROUTING SIDE 2...
  • Page 32 1040−050−030 Right Handle Grip Assembly Item Part No. Part Name Qty. 0023−302−000 Pan Hd. Thrd.−Frm. Screw 1040−050−031 Light Pipe 1040−050−032 Grip Button 1040−050−303 Right Bottom Grip 1040−050−034 Right Top Grip 1040−050−035 Right Handle Weldment 0038−111−000 Cable Tie 1040−050−801 Handle Switch Cable 1040−050−802 Handle Extension Cable 0038−523−000...

  • Page 33: Left Handle Grip Assembly

    1040−050−040 Left Handle Grip Assembly See Detail A WIRE ROUTING DETAIL A WIRE ROUTING SIDE 2...
  • Page 34 1040−050−040 Left Handle Grip Assembly Item Part No. Part Name Qty. 0023−302−000 Pan Hd. Thrd.−Frm. Screw 1040−050−031 Light Pipe 1040−050−032 Grip Button 1040−050−043 Left Bottom Grip 1040−050−044 Left Top Grip 1040−050−045 Left Handle Weldment 0038−111−000 Cable Tie 1040−050−801 Handle Switch Cable 1040−050−802 Handle Extension Cable 0038−523−000...
  • Page 35 26” Litter with Scale System & Fold−to−Head Siderails Assembly part number 1001−430−010 (reference only)
  • Page 36 26” Litter with Scale System & Fold−to−Head Siderails...
  • Page 37 26” Litter with Scale System & Fold−to−Head Siderails TOP VIEW HEAD END...
  • Page 38 26” Litter with Scale System & Fold−to−Head Siderails Item Part No. Part Name Qty. 0003−355−000 Hex Hd. Cap Screw 0003−359−000 Hex Hd. Cap Screw 0007−071−000 Truss Hd. Mach. Screw 0004−181−000 Button Hd. Cap Screw 0023−288−000 Hex Washer Hd. Screw 0007−058−000 Torx Screw 0013−010−000 Ext.
  • Page 39 26” Litter with Scale System & Fold−to−Foot Siderails Assembly part number 1001−530−010 (reference only)
  • Page 40 26” Litter with Scale System & Fold−to−Foot Siderails...
  • Page 41 26” Litter with Scale System & Fold−to−Foot Siderails TOP VIEW...
  • Page 42 26” Litter with Scale System & Fold−to−Foot Siderails Item Part No. Part Name Qty. 0003−355−000 Hex Hd. Cap Screw 0003−359−000 Hex Hd. Cap Screw 0004−330−000 Soc. Hd. Cap Screw 0007−058−000 Truss Hd. Torx Screw 0007−071−000 Truss Hd. Mach. Screw 0013−010−000 Ext.
  • Page 43 29” Litter with Scale System & Fold−to−Head Siderails Assembly part number 1501−630−010 (reference only)
  • Page 44 29” Litter with Scale System & Fold−to−Head Siderails FOOT END...
  • Page 45 29” Litter with Scale System & Fold−to−Head Siderails TOP VIEW HEAD END...
  • Page 46 29” Litter with Scale System & Fold−to−Head Siderails Item Part No. Part Name Qty. 0003−355−000 Hex Hd. Cap Screw 0003−359−000 Hex Hd. Cap Screw 0007−071−000 Truss Hd. Mach. Screw 0004−181−000 But. Hd. Cap Screw 0023−288−000 Hex Wash. Hd. Screw 0007−058−000 Truss Hd.
  • Page 47 29” Litter with Scale System & Fold−to−Foot Siderails Assembly part number 1501−730−010 (reference only)
  • Page 48 29” Litter with Scale System & Fold−to−Foot Siderails...
  • Page 49 29” Litter with Scale System & Fold−to−Foot Siderails TOP VIEW...
  • Page 50 29” Litter with Scale System & Fold−to−Foot Siderails Item Part No. Part Name Qty. 0003−355−000 Hex Hd. Cap Screw 0003−359−000 Hex Hd. Cap Screw 0004−330−000 Soc. Hd. Cap Screw 0007−058−000 Truss Hd. Torx Screw 0007−071−000 Truss Hd. Mach. Screw 0013−010−000 Ext.
  • Page 51 26” Litter Assembly with Scale System Assembly part number 1009−230−010 (reference only)
  • Page 52 26” Litter Assembly with Scale System...
  • Page 53 26” Litter Assembly with Scale System TOP VIEW HEAD END...
  • Page 54 26” Litter Assembly with Scale System Item Part No. Part Name Qty. 0003−359−000 Hex Hd. Cap Screw 0007−071−000 But. Hd. Cap Screw 0004−330−000 But. Hd. Cap Screw 0007−058−000 Truss Hd. Torx Screw 0014−021−000 Washer 0025−122−000 Rivet 0016−117−000 Stover Hex Lock Nut 0016−118−000 Stover Hex Lock Nut 0023−288−000...
  • Page 55 29” Litter Assembly with Scale System Assembly part number 1509−230−010 (reference only)
  • Page 56 29” Litter Assembly with Scale System...
  • Page 57 29” Litter Assembly with Scale System TOP VIEW HEAD END...
  • Page 58 29” Litter Assembly with Scale System Item Part No. Part Name Qty. 0003−359−000 Hex Hd. Cap Screw 0007−071−000 Truss Hd. Mach. Screw 0004−330−000 But. Hd. Cap Screw 0007−058−000 Truss Hd. Torx Screw 0013−010−000 External Tooth Lock Washer 0014−021−000 Washer 0025−122−000 Rivet 0016−117−000 Stover Hex Lock Nut...
  • Page 59 26” Litter Assembly with Scale System Assembly part number 1210−230−010 (reference only)
  • Page 60 26” Litter Assembly with Scale System HEAD END...
  • Page 61 26” Litter Assembly with Scale System...
  • Page 62 26” Litter Assembly with Scale System TOP VIEW...
  • Page 63 26” Litter Assembly with Scale System Item Part No. Part Name Qty. 0003−355−000 Hex Hd. Cap Screw 0003−356−000 Hex Hd. Cap Screw 0003−359−000 Hex Hd. Cap Screw 0007−071−000 Truss Hd. Mach. Screw 0004−330−000 Socket Hd. Cap Screw 0007−058−000 Torx Screw 0013−010−000 Ext.
  • Page 64 29” Litter Assembly with Scale System Assembly part number 1710−230−010 (reference only)
  • Page 65 29” Litter Assembly with Scale System...
  • Page 66 29” Litter Assembly with Scale System...
  • Page 67 29” Litter Assembly with Scale System TOP VIEW...
  • Page 68 29” Litter Assembly with Scale System Item Part No. Part Name Qty. 0003−355−000 Hex Hd. Cap Screw 0003−356−000 Hex Hd. Cap Screw 0003−359−000 Hex Hd. Cap Screw 0007−071−000 Truss Hd. Mach. Screw 0004−330−000 Socket Hd. Cap Screw 0007−058−000 Torx Screw 0013−010−000 Ext.
  • Page 69 26” Litter Assembly with Scale System Assembly part number 1231−124−001 (reference only)
  • Page 70 26” Litter Assembly with Scale System...
  • Page 71 26” Litter Assembly with Scale System...
  • Page 72 26” Litter Assembly with Scale System TOP VIEW...
  • Page 73 26” Litter Assembly with Scale System Item Part No. Part Name Qty. 0003−355−000 Hex Hd. Cap Screw 0003−356−000 Hex Hd. Cap Screw 0003−357−000 Hex Hd. Cap Screw 0003−359−000 Hex Hd. Cap Screw 0007−071−000 Truss Hd. Mach. Screw 0004−330−000 Socket Hd. Cap Screw 0007−058−000 Torx Screw 0013−010−000...
  • Page 74 29” Litter Assembly with Scale System Assembly part number 1731−124−001 (reference only)
  • Page 75 29” Litter Assembly with Scale System...
  • Page 76 29” Litter Assembly with Scale System...
  • Page 77 29” Litter Assembly with Scale System TOP VIEW...
  • Page 78 29” Litter Assembly with Scale System Item Part No. Part Name Qty. 0003−355−000 Hex Hd. Cap Screw 0003−356−000 Hex Hd. Cap Screw 0003−357−000 Hex Hd. Cap Screw 0003−359−000 Hex Hd. Cap Screw 0007−071−000 Truss Hd. Mach. Screw 0004−330−000 Socket Hd. Cap Screw 0007−058−000 Torx Screw 0013−010−000...
  • Page 79 26” Litter Assembly with Scale System and Zoom Assembly part number 1231−524−001 (reference only)
  • Page 80 26” Litter Assembly with Scale System and Zoom...
  • Page 81 26” Litter Assembly with Scale System and Zoom...
  • Page 82 26” Litter Assembly with Scale System and Zoom TOP VIEW...
  • Page 83 26” Litter Assembly with Scale System and Zoom Communication Coil Cord from Base...
  • Page 84 26” Litter Assembly with Scale System and Zoom Item Part No. Part Name Qty. 0003−355−000 Hex Hd. Cap Screw 0003−359−000 Hex Hd. Cap Screw 0007−071−000 Truss Hd. Mach. Screw 0004−330−000 Socket Hd. Cap Screw 0007−058−000 Torx Screw 0013−010−000 Ext. Tooth Lock Washer 0014−021−000 Washer 0015−027−000...

  • Page 85: 26" Zoomr Handle Assembly

    26” Zoom Handle Assembly Assembly part number 1040−050−026 (reference only) Load Cell Cable Communication Cable From Electronics Box...
  • Page 86 26” Zoom Handle Assembly Item Part No. Part Name Qty. 0023−288−000 Hex Washer Hd. Screw 0003−367−000 Hex Hd. Cap Screw 0013−019−000 Ext. Tooth Lock Washer 0013−038−000 Ext. Tooth Lock Washer 0023−305−000 Hex Washer Hd. Screw 0028−196−000 External Retaining Ring 1040−050−108 Pivot Bolt 1001−226−016 Pivot Bearing...
  • Page 87 29” Litter Assembly with Scale System and Zoom Assembly part number 1731−524−001 (reference only)
  • Page 88 29” Litter Assembly with Scale System and Zoom...
  • Page 89 29” Litter Assembly with Scale System and Zoom...
  • Page 90 29” Litter Assembly with Scale System and Zoom TOP VIEW...
  • Page 91 29” Litter Assembly with Scale System and Zoom Communication Coil Cord from Base...
  • Page 92 29” Litter Assembly with Scale System and Zoom Item Part No. Part Name Qty. 0003−355−000 Hex Hd. Cap Screw 0003−359−000 Hex Hd. Cap Screw 0007−071−000 Truss Hd. Mach. Screw 0004−330−000 Socket Hd. Cap Screw 0007−058−000 Torx Screw 0013−010−000 Ext. Tooth Lock Washer 0014−021−000 Washer 0015−027−000...
  • Page 93 Litter Assembly Electric Synergy− Scale Assembly part number 1550−330−010 (reference only)
  • Page 94 Litter Assembly Electric Synergy− Scale...
  • Page 95 Litter Assembly Electric Synergy− Scale...
  • Page 96 Litter Assembly Electric Synergy− Scale...
  • Page 97 Litter Assembly Electric Synergy− Scale Item Part No. Part Name Qty. 1550−30−5 Frame Assembly 938−1−401 Collar 28−72−0 Retaining Ring 1001−40−12 Footboard Receptacle 23−104−0 Self Tapping Screw 926−400−142 Corner Wheel 1001−201−30 Trend Support 1010−201−27 Bumper Extrusion 001−1−36 End Plug 1001−1−41 Tube Plug 49−1−0 Square Head Screw 1001−201−29...
  • Page 98 Litter Assembly Electric Synergy− Scale 4−135−0 Button Head Cap Screw 38−220−0 Spring 1010−26−81 Lock Hsousing Assembly LH 1010−26−80 Lock Hsousing Assembly RH 14−21−0 Washer 11−179−0 Washer 37−74−0 Plug 721−26−74 Lock Handle 21−104−0 Set Screw 11−2−0 Washer 1501−201−31 Support Tube Assembly 1501−31−13 Fowler Tube 4−183−0...
  • Page 99 Litter Assembly Electric Synergy− Scale 59−75−0 Cable Ties 59−77−0 LED Indicator 36−46−0 Label 59−100−0 Plug 1550−90−20 Label 946−1−155 Bumper 3001−300−870 Earth Ground Jumper 1001−34−25 Plug 1211−351−10 Push Handle Assembly 1501−33−24 Fowler Lever Assembly 1501−34−11 Thigh Frame Assembly 1501−34−112 Calf Frame Assembly 1501−34−23 Midsection Support Assembly 1510−234−27...

  • Page 100: 26" Lift Header Assembly

    Head End Lift Header Assembly, 26” Litter with Scales Assembly part number 1070−017−100 (reference only) Item Part No. Part Name Qty. 0004−462−000 Button Hd. Cap Screw 0028−120−000 Retaining Ring 0037−215−000 Dome Plug 1070−017−106 Lift Header Supt. Block, Tapered 1070−017−110 Head End Lift Header, 26” 0016−035−000 Nylock Nut 3001−307−057...
  • Page 101 Foot End Lift Header Assembly, 26” Litter with Scales Assembly part number 1070−017−150 (reference only) Item Part No. Part Name Qty. 0004−145−000 Button Hd. Cap Screw 0004−462−000 Button Hd. Cap Screw 0013−019−000 External Tooth Lock Washer 0016−035−000 Nylock Hex Nut 1070−017−161 Foot End Lift Header Bracket 1070−017−162...

  • Page 102: 29" Lift Header Assembly

    Head End Lift Header Assembly, 29” Litter with Scales Assembly part number 1070−017−200 (reference only) Item Part No. Part Name Qty. 0004−462−000 Button Hd. Cap Screw 0028−120−000 Retaining Ring 0037−215−000 Dome Plug 1070−017−106 Lift Header Supt. Block, Tapered 1070−017−210 Head End Lift Header, 29” 0016−035−000 Nylock Nut 3001−307−057...
  • Page 103 Foot End Lift Header Assembly, 29” Litter with Scales Assembly part number 1070−017−250 (reference only) Item Part No. Part Name Qty. 0004−145−000 Button Hd. Cap Screw 0004−462−000 Button Hd. Cap Screw 0013−019−000 External Tooth Lock Washer 0016−035−000 Nylock Hex Nut 1070−017−261 Foot End Lift Header Bracket 1070−017−262...

  • Page 104: 29" Lift Header Assembly, Electric Litter

    Head End Lift Header, 29” Electric Litter with Scales Assembly part number 1070−017−225 (reference only) Item Part No. Part Name Qty. 0004−462−000 Button Hd. Cap Screw 0028−120−000 Retaining Ring 0037−215−000 Dome Plug 1070−017−107 Header Supt. Block, Non−Tapered 1 1070−017−210 Head End Lift Header, 29” 0016−035−000 Nylock Nut 3001−307−057...
  • Page 105 Foot End Lift Header, 29” Electric Litter with Scales Assembly part number 1070−017−275 (reference only) Item Part No. Part Name Qty. 0004−145−000 Button Hd. Cap Screw 0004−462−000 Button Hd. Cap Screw 0013−019−000 External Tooth Lock Washer 0016−035−000 Nylock Hex Nut 1070−017−261 Foot Header Bracket 1070−017−263...

  • Page 106: 29" Lift Header Assembly, Electric Litter With Scales

    Head End Lift Header, 29” Electric Litter with Scales Assembly part number 1070−017−115 (reference only) Item Part No. Part Name Qty. 0004−462−000 Button Hd. Cap Screw 0028−120−000 Retaining Ring 0037−215−000 Dome Plug 1070−017−107 Lift Header Jack Non−Tapered 1070−017−120 Head End Lift Header, 29” 0016−035−000 Nylock Nut 3001−307−057...
  • Page 107 Foot End Lift Header, 29” Electric Litter with Scales Assembly part number 1070−017−170 (reference only) Item Part No. Part Name Qty. 0004−462−000 Button Hd. Cap Screw 0028−120−000 Retaining Ring 0037−215−000 Dome Plug 1070−017−106 Lift Header Supt. Block, Tapered 1070−017−110 Head End Lift Header, 26” 0016−035−000 Nylock Nut 3001−307−057...

  • Page 108: Scale Display Assembly

    1070−037−020 Scale Display Assembly...
  • Page 109 1070−037−020 Scale Display Assembly Item Part No. Part Name Qty. 0023−088−000 Pan Hd. Hi−Lo Tapping Screw 0034−104−000 Strain Relief 0034−431−000 Strain Relief 0059−782−000 Battery 1070−137−021* Upper Display Housing 1070−137−024 Display Lens 1070−037−856 Battery Holder Cable 1070−037−800 Scale PCB Board 1070−037−901 Overlay 1070−137−022 Lower Display Housing...

  • Page 110: Limited Warranty

    If requested by Stryker, products or parts for which a warranty claim is made shall be returned prepaid to Stryker’s factory. Any improper use or any alteration or repair by others in such manner as in Stryker’s judgement affects the product materially and adversely shall...

  • Page 111: Return Authorization

    Stryker will perform all service during regular business hours (9−5) * Replacement parts and labor for products under PM contract will be discounted. ** Does not include any disposable items, I.V. poles (except for Stryker HD permanent poles), mattresses, or damage re- sulting from abuse.
  • Page 112 European Representative Stryker EMEA RA/QA Director Stryker France ZAC Satolas Green Pusignan Av. De Satolas Green 69881 MEYZIEU Cedex France 3800 E. Centre Ave., Portage, MI 49002 (800) 327−0770 www.stryker.com JH 1070−009−001 REV E...
