OPERATIONS MANUAL
ELECTRIC ACUTE CARE BED
Model FL20E (USA: 2501)
TECHNICAL ASSISTANCE AND PARTS
1 800 428-5025 (Canada)
E-mail (Canada only):
service@bertec.strykercorp.com
1 800 327-0770 (United States)
Manufactured by Stryker Bertec Medical Inc
72-0439 R1.3
September 2003
F15-43-E-A
Printed in Canada
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Stryker BERTEC GOBED PLUS FL20E
Summary of Contents for Stryker BERTEC GOBED PLUS FL20E
- Page 1 OPERATIONS MANUAL ELECTRIC ACUTE CARE BED Model FL20E (USA: 2501) TECHNICAL ASSISTANCE AND PARTS 1 800 428-5025 (Canada) E-mail (Canada only): service@bertec.strykercorp.com 1 800 327-0770 (United States) Manufactured by Stryker Bertec Medical Inc 72-0439 R1.3 September 2003 F15-43-E-A Printed in Canada...
-
Page 3: Table Of Contents
TABLE OF CONTENTS 1. INTRODUCTION........................4 1.1 Bed Specifications ......................4 1.2 Technical Support......................5 1.3 Warning / Caution / Note Definitions................5 1.4 Safety Tips and Guidelines..................... 5 1.5 Warranty......................... 7 Limited Warranty ......................7 To Obtain Service and/or Parts..................7 Return Authorization....................... -
Page 4: Introduction
220V∼, 50-60Hz, 2.9A -Two 250V, 6.3A Slow Blow Fuses 240V∼, 50-60Hz, 2.7A -Two 250V, 6.3A Slow Blow Fuses * Stryker Bertec pays special attention to product improvement and reserves the right to change specifications without notice. **Operating environment recommended to ensure the scale precision. -
Page 5: Technical Support
1.2 TECHNICAL SUPPORT For questions regarding this product, contact the following Technical Service department or your local representative: In Canada: In the United States: Stryker Bertec Medical Inc Stryker Medical 1 800 428-5025 1 800 327-0770 E-mail (Canada only): 6300, South Sprinkle Road service@bertec.strykercorp.com... - Page 6 • When servicing use only identical replacement parts provided by Stryker Bertec. NOTE Throughout this operations manual, the words “right” and “left” refer to the right and left sides of a...
-
Page 7: Warranty
Claims will be limited in amount to the actual replacement cost. In the event that this information is not received by Stryker Bertec within the fifteen (15) day period following the delivery of the merchandise, or the damage was not noted on the delivery notice at the time of receipt, the customer will be responsible for payment of the original invoice in full. -
Page 8: Set-Up Procedure
GOBED Operations Manual 1.7 SET-UP PROCEDURE CHECKLIST It is important to ensure that the bed is working properly before it is put into service. The following list will help ensure that each part of the bed is checked. _____ Install the foot and head boards on the bed. Insert the foot board carefully so that the board and the casing connectors fit in smoothly. -
Page 9: Cleaning And Preventative Maintenance
Introduction Chapter 1 1.8 CLEANING AND PREVENTATIVE MAINTENANCE BED CLEANING AND MATTRESS CARE Always unplug the bed power cord from the wall outlet when cleaning or servicing the bed. Do not use harsh cleaners, solvents or detergents. Do not steam clean, hose off or ultrasonically clean the bed. -
Page 10: Preventative Maintenance
GOBED Operations Manual PREVENTATIVE MAINTENANCE Annual Checklist ____ All fasteners secure. ____ Inspect for excessive wear the oil-impregnated bronze shoulder spacers found at the bed hinge points. Replace as needed. Do not lubricate these spacers. ____ Engage the “TOTAL BRAKE” pedal at both sides of the bed and ensure the brakes are applied. -
Page 11: Bed Position Pictograms
Introduction Chapter 1 1.9 BED POSITION PICTOGRAMS The following pictograms illustrate the basic positions. Not illustrated here is the Cardiac Chair position that is obtained by combining the reverse Trendelenburg and the Contour positions. VASCULAR FOWLER ELEVATION POSITION TRENDELENBURG POSITION KNEE GATCH ELEVATION REVERSE TRENDELENBURG POSITION... -
Page 12: Operation Guide
GOBED Operations Manual 2. OPERATION GUIDE 2.1 SWITCHING ON POWER The bed is equipped with a main power switch located at the head end of the bed where the power cord connects to the bed. Turn it on to activate the bed functions. When the bed power switch is turned off or in the event of a power failure, the settings of the lockout controls and the optional Weigh and/or Bed Exit calibration data are preserved. -
Page 13: Foley Bag Hook Usage
Chapter 2 Operation Guide 2.4 FOLEY BAG HOOK USAGE Foley bag hooks (see page 11, “Bed Illustration”) are found at three locations on both sides of the bed under the edges of the mattress support head, seat and foot sections. The Foley bag hooks move when the Fowler is raised or lowered. -
Page 14: Emergency Cpr Release (Optional)
GOBED Operations Manual 2.7 EMERGENCY CPR RELEASE (OPTIONAL) The CPR release is for emergency use only. When activating the CPR release, all people and equipment must be removed from the area below and around the head, thigh and foot sections of the bed or serious personal injury or equipment damage could occur. -
Page 15: Positioning Siderails
Chapter 2 Operation Guide 2.11 POSITIONING SIDERAILS The siderails have one lock position, in the upper position. They can be tucked away against the mattress support when not in use. The rail has to be removed from its tucked position by pulling it outward prior to raise it. Leave the siderails fully up and locked when the patient is unattended. -
Page 16: Head Siderail Function Guide
GOBED Operations Manual 2.13 HEAD SIDERAIL FUNCTION GUIDE Outside Siderail (Patient's Right Rail) Outside Siderail (Patient's Left Rail) Figure 2.13A A: Press to raise Fowler D: Press to lower sleep surface B: Press to lower Fowler E: Press to raise Knee Gatch C: Press to raise sleep surface F: Press to lower Knee Gatch Inside Siderail (Patient's Right Rail) -
Page 17: Foot Board Control Panel Guide
Chapter 2 Operation Guide 2.14 FOOT BOARD CONTROL PANEL GUIDE Figure 2.14 A1: Press to lock out Fowler controls at both head siderails. The Fowler padlock icon will come on. Press again to unlock. A2: Press to lock out Knee Gatch controls at both head siderails. The Knee Gatch padlock icon will come on. -
Page 18: Weigh System Control Panel Guide (Optional)
Operations Manual 2.16 WEIGH SYSTEM CONTROL PANEL GUIDE (OPTIONAL) When the bed is switched on, the scale display will show "STRYKER / SCALE V x.x" where x.x is the version of the control software. The Weigh system is intended to assist in the monitoring of the patient's weight variation. Under no circumstances should its reading be used as sole reference for medical treatment. -
Page 19: Adding Or Removing Equipment When A Patient Is On The Bed
Chapter 2 Operation Guide Adding or Removing Equipment when a Patient is on the Bed Take note of the patient's weight before proceeding with the Change Equipment mode. The patient's weight should remain the same at the end of the procedure. If it is not the case, access the Change Patient Weight mode using the MENU Up or Down keys and enter manually the previously noted patient weight. -
Page 20: Chaperone Bed Exit (Optional)
GOBED Operations Manual 2.17 CHAPERONE BED EXIT (OPTIONAL) A: Press to activate/deactivate the Bed Exit function B: Armed LED Figure 2.17 For the bed exit alarm signal to be heard in the nurse station, the bed must be equipped with the optional nurse call function and be connected to the hospital nurse call system. -
Page 21: Chaperone Bed Exit With Zone Control (Optional)
Chapter 2 Operation Guide 2.18 CHAPERONE BED EXIT WITH ZONE CONTROL (OPTIONAL) A: Press to activate/deactivate the Bed Exit function B: Zone LED's C: Press to select zone D: Zone icons (zone from left to right: less restrictive to most restrictive, see below) Figure 2.18 For the bed exit alarm signal to be heard in the nurse station, the bed must be equipped with the optional nurse call function and be connected to the hospital nurse call system. -
Page 22: Accessories
GOBED Operations Manual 3. ACCESSORIES Listed below are all the accessories that may be attached to the as well as their maximum load capacity where applicable. • Two function pendant control with hook (Product & Design) • Three function pendant control with hook (Product & Design) •...
