Setup
3. Using the and arrows, scroll through the letter list until you
find the first desired letter.
The letter list is arranged with Uppercase letters > lowercase
letters > numbers > symbols. The letters are listed in alphabetical
order and the numbers in numerical order. Most standard ASCII
characters are included.
4. Press the SELECT button or
move to the next letter. A blinking square appears in the second
letter position.
5. Repeat Steps 2 through 4 until the complete name is entered.
Note: The arrow saves the custom name. The
move forward, one space per one button press. To add a space to your
custom name, press the SELECT button or
letter.
Use the same procedure to edit a previously saved name.
VIDEO IN
VIDEO IN
SETUP INPUT SETUP
Selects the VIDEO IN parameter, which assigns one of the rear panel
video input connectors to the current input. Available selections
include NONE, HDMI 1-2, Component 1-3, S-Video 1-4, and
Composite 1-4.
The HDMI Audio & Video inputs, HDMI 1 & HDMI 2, are mutually
exclusive inputs - only one input is available at a time for each input
location. For example, while setting up the DVD input, if HDMI 2 is
selected for the Video Input, then HDMI 1 is not a selectable option
for the Digital Audio Input.
3-14
arrow to save the first letter and
arrow allows you to
arrow without choosing a
V-PROCESS
SETUP INPUT SETUP V-PROCESS
Selects the V-PROCESS parameter, which identifies the type of video
processing or conversion, if any, that is applied to the selected input
source. Explanations of the available selections are listed below.
Faroudja - Activates the Faroudja video processing feature. The video
signals can be handled in several different ways, depending upon the
input source.
• A standard-definition (480i or 576i) analog signal
(composite, S-video, or component) is digitized and sent
to the Faroudja video processor for enhancement. The
signal is available as both an analog component and an
HDMI signal.
• An analog component signal is digitized and sent to the
Faroudja video processor for enhancement. The signal is
available as both an analog component and an HDMI
signal, but not at the analog composite or S-video
monitor outputs.
• Any HDMI signal other than 1080i is sent to the Faroudja
video processor for enhancement and is available as an
output at both the HDMI and analog component
o u t p u t s . P r o g r a m m a t e r i a l t h a t c a r r i e s H D C P
(High-Bandwidth Digital Content Protection) encoding is
only available through the HDMI output.
• HDMI signals in 1080i resolution are sent directly to the
H D M I a n d a n a l o g c o m p o n e n t o u t p u t s w i t h o u t
processing. Program material that carries HDCP
encoding is only available through the HDMI output.
The Faroudja selection delivers the best image quality when a digital
video display is in use but it requires the use of a video display
capable of accepting high-resolution (480p up to 1080i) signals
through either an HDMI or component video connection.
Lexicon
FAROUDJA, CONV ONLY, BYPASS
